Audiovox CDC-TO3 Installation Manual

Model CDC-TO3
Works in conjuction with Audiovox 6 Disc and 10 Disc CD Changer (except P-1000)
For use with Toyota vehicles factory radios as listed in the following vehicles:
1998-99 Avalon
1998-99 Camry
1998-99 Celica
* NOTE: CDC-TO3 does not work in conjunction with Sienna steering wheel controls.
Compatible with following Toyota factory radio models in above vehicles (model number is printed on face
panel of radio):
11801
11802
16408
16410
CAUTION:
FOLLOW THE CONNECTION SEQUENCE DESCRIBED BELOW TO ENSURE PROPER
RECOGNITION OF THE CD CHANGER BY THE FACTORY RADIO.
DO NOT FORCE CONNECTORS TOGETHER. LINE UP LOCATING TABS AND CAREFULLY
MATE CONNECTORS.
INSTALLATION INSTRUCTIONS FOR THE CDC-TO3: (See Installation Diagram)
1. Mount the CD Changer in the rear of the vehicle. Refer to the installation instructions supplied with
the CD Changer.
2. Be sure the ignition switch and the radio are in the off position.
CAUTION: If not, the radio will not recognize the changer.
3. Remove the factory radio from the dash panel.
4. Disconnect the power/speaker harness between the car and the radio.
5. Connect the CDC-TO3 to the Changer using the 5 Meter DIN Cable supplied with the CD Changer.
6. Plug the 12 Pin Connector from the CDC-TO3 into the mating socket on the rear of the factory radio.
7. Re-connect the radio power/speaker harness.
8. Reset the Changer and insert the CD magazine.
9. Re-install the radio into the dash panel.
10. Turn on the ignition and radio and perform an operation check.
OPERATION CHECK:
1. Load CD's into the CD Changer magazine and insert the magazine into the changer.
2. Start vehicle and allow CD Changer to cycle. Perform a brief functional test to verify proper
operation according to the Owner's Manual.
IMPORTANT
1998-99 Corolla
1998-99 Land Cruiser
1998-99 Paseo
16808
16810
51800
56808
© 1999 Audiovox Corporation, 150 Marcus Blvd., Hauppauge, N.Y. 11788
INSTALLATION GUIDE FOR:
CD CHANGER INTERFACE
for TOYOTA VEHICLES
1998-99 4-Runner
1998-99 RAV4
1998-99 Sienna*
A51707
A51801
A56409
AD1701
Page 1
128-5524
1998\ T-100
1998-99 Tacoma
1998-99 Tercel
AD1702
AD6401
AD6801
AD6802
