Napoleon GDI-44N Installation And Operation Instructions Manual

Gas-fired direct vent insert for vented gas fireplace
Hide thumbs Also See for GDI-44N:
Table of Contents

Advertisement

Quick Links

INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS
GAS-FIRED DIRECT VENT INSERT
INSTALLATION AND OPERATION INSTRUCTIONS FOR:
WARNING: If the information in these instructions is not followed exactly, a fire
or explosion may result causing property damage, personal injury or death.
Do not store or use gasoline or other flammable vapours and liquids in the
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your
building.
Installation and service must be performed by a qualified installer, service
R-2000
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 4Y8 Canada • (705)721-1212 • fax(705)722-6031
VENTED GAS FIREPLACE
NATURAL GAS MODELS
PROPANE GAS MODELS
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI / CSA METHODS
FOR YOUR SAFETY
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
agency or the gas supplier.
www.napoleonfireplaces.com • ask@napoleon.on.ca
GDI-44N
GDI-44P
• Immediately call your gas supplier
from a neighbour's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
1
W415-0314 / C / 01.15.04
