INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
CERTIFIED UNDER U.S. ENVIRONMENTAL PROTECTION AGENCY (E.P.A.) JULY 1990 AND THE OREGON DEPARTMENT OF ENVIRONMENTAL QUALITY (D.E.Q.) PARTICULATE
EMISSION STANDARDS BY E.E.M.C. THESE STOVES HAVE BEEN TESTED AND LISTED BY WARNOCK HERSEY LTD. TO STANDARDS: CSA B366.2 , ULCS627, ULC S628, UL 1482.
MODEL 1100 HAS BEEN TESTED AND LISTED FOR INSTALLATION IN MOBILE HOMES.
INSTALLATION AND OPERATION INSTRUCTIONS FOR
HI-TECH LISTED SOLID FUEL BURNING STOVES AND INSERTS
FREE STANDING MODELS
INSERT MODELS
Follow the installation directions. This unit can be very hot when burning. Combustible materials
such as firewood, wet clothing, etc. placed too close can catch fire. Children and pets must be
kept from touching the unit when it is hot. The chimney must be sound and free of cracks. Before
installing your unit, contact the local building or fire authority and follow their guidelines.
Operate only with door tightly closed. Burn wood directly on firebricks. Do not use a grate or
elevate the fire. At least 14 square inches (90 sq.cm.) of outside air must be admitted to the room
or directly to the unit through a 4 inch (10cm.) diameter pipe. This unit is designed to burn natural
wood only. Higher efficiencies and lower emissions generally result when burning air dried sea-
soned hardwoods, as compared to softwoods or to green or freshly cut hardwoods. Do not start a
fire with chemicals or fluids such as gasoline, engine oil, etc. Do not burn treated wood, coal,
charcoal, coloured paper, cardboard, solvents or garbage which tend to produce more pollution
than wood. Do not let the unit become hot enough for any part to glow red.
KEEP THE STOVE TOP TEMPERATURE BELOW 700°F (371°C). Attempts to achieve heat output rates
that exceed design specifications can result in steel distortion and damage.
Fax: (705)722-6031
EPA 1100, 1100L, 1100C, 1400, 1400L & 1900
EPI 1101, 1401
If this unit is not properly installed, a house fire may result.
FOR YOUR SAFETY
Wolf Steel Ltd., 24 Napoleon Rd.,
Barrie, ON., Canada L4M 4Y8 (705)721-1212
www.napoleonfireplaces.com
R-2000
WARNING:
Email: ask@napoleon.on.ca
W415-0360 / 11.05.02
1
Advertisement
Chapters
Table of Contents
Related Manuals for Napoleon EPA 1100
Summary of Contents for Napoleon EPA 1100
- Page 1 Do not let the unit become hot enough for any part to glow red. KEEP THE STOVE TOP TEMPERATURE BELOW 700°F (371°C). Attempts to achieve heat output rates that exceed design specifications can result in steel distortion and damage.
- Page 2 NAPOLEON wood fireplaces are manufactured under the strict Standard of the World Recognized NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen who take great pride in their work. The complete fireplace is thoroughly inspected by a qualified technician before packaging to ensure that you, the customer, receives the quality product that you expect from NAPOLEON.
-
Page 3: Specifications
2-4 INTRODUCTION Warranty General Information Care of Plated & Enamelled Parts Care of Glass 5-6 INSTALLATION Installing the Legs Alcove Installation Stove Installation Chimney Connection Adding Chimney Sections Outside Air 6-7 MOBILE HOME INSTALLATION Venting Outside Air 7-8 FIREPLACE INSERT... -
Page 4: Hours
If the glass should ever crack while the fire is burning, do not open the door until the fire is out and do not operate the stove again until the glass has been replaced with a new 5mm thick plate of ceramic glass, available from your Napo- leon / Wolf Steel Ltd. -
Page 5: Stove Installation
4. Use four of the nuts and washers removed above to install the legs as illustrated in FIGURES 2a & 2b. 5. Lift the stove up and gently set down on all four legs. Do not pivot unit up on its legs, as this could result in damage to the legs. -
Page 6: Mobile Home Installation
The chimney and pipe must extend at least 8 feet above the stove and 3 feet above the highest point of the roof. Install a rain cap at the top which will not impede the smoke exhaust. The chimney must be sup- ported at the ceiling or roof so that its weight does not rest on the stove. -
Page 7: Fireplace Insert
Na- poleon EPA certified freestanding stoves and in particu- lar that of the EPA 1100 and 1400. External modifica- tions have been made to allow its installation as a "func- tional fireplace insert" with a heat circulating blower sys- tem and a means of enclosing the solid fuel burning fire- place cavity for greater heating efficiency. -
Page 8: Optional Fan Installation
Use of the fan increases the output of heat. STOVE MODELS: Provisions have been made on the stove to install an optional blower kit (EP62-1) that comes complete with a variable speed switch to turn the blower on and off, as well as adjusting the blower speed. - Page 9 1101 FAN SERVICE OR REPLACEMENT 1. Turn off all electrical power to the insert. Remove the glass door and set aside in a safe place. 2. Remove the top right side bricks from inside the firebox, 4-#7's and 2- #2's. Then remove the rest of the side and back bricks from the right side of the 1101 insert.
-
Page 10: Finishing
SIZES 1-1/4" x 4"-1/2 x 9" 1-1/4" x 3" x 9" 1-1/4" x 4-1/2" x 4-1/2" 1-1/4" x 4-1/2" x 9" 1-1/4" x 2-1/2" x 4-1/2" 1-1/4" x 1-1/2" x 4-1/2" 1-1/4" x 4-1/2" x 9" (light weight) 1-1/4" x 2-1/4" x 9" 1-1/4"... - Page 11 To start, a brisk fire is required. Place loosely crum- pled paper on the floor of the stove and cover with dry kindling. Open the draft control fully by pulling the lever forward. Light the paper and leave the door slightly ajar (one inch) until all kindling is burning.
-
Page 12: Achieving Proper Draft
You can safely fill the firebox with wood to the top of the door and will get best burns if you keep the stove pipe temperatures between 250 degrees Fahrenheit (120 degrees Celsius) and 450 degrees Fahrenheit (270 de- grees Celsius). -
Page 13: Maintenance
If accumulation is excessive, disconnect the stove and clean both the chimney and the stove. You may want to call a professional chimney sweep to clean them. Both have to be cleaned at least once a year or as often as necessary. -
Page 14: Wood Pile Maintenance
Ideal lengths of wood are approximately 12" for EPA 1100, 1100C, 1100L and 1101, 16 1/2" for EPA 1400, 1400L and 1401, and 21"... -
Page 15: Ordering Procedures
ORDERING PROCEDURES Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally all parts can be ordered through your Napoleon dealer or distributor. When ordering replacement parts always give the following information: 1. Model & Serial Number of fireplace 2. - Page 16 W415-0360 / 11.05.02...
