Installation instructions
DishDrawer®
DD24S models
Important!
SAVE THESE INSTRUCTIONS
The models shown in this document may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go to our
website www.fisherpaykel.com or contact your local Fisher & Paykel dealer.

SAFETY AND WARNINGS

1
Electrical hazard
Before installing the DishDrawer®, remove the house fuse or open the circuit
breaker.
If permanently connecting the DishDrawer®, be sure the power is isolated and
the DishDrawer® unplugged.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of a malfunction or breakdown,
grounding will reduce the risk of electric shock by providing a path of least
resistance for electric current. This appliance is equipped with a cord having
an equipment-grounding conductor and a grounding plug. The plug must be
plugged into an appropriate outlet that is installed and grounded in accordance
with all local codes and ordinances. WARNING - Improper connection of the
equipment-grounding conductor can result in a risk of electric shock. Check with
a quali ed electrician or service representative if you are in doubt as to whether
the appliance is properly grounded.
If the DishDrawer is installed as a permanently connected appliance:
GROUNDING INSTRUCTIONS - This appliance must be connected to a grounded
metal, permanent wiring system, or an equipment-groounding conductor must
be run with the circuit conductors and connected to the equipment-grounding
terminal or lead on the appliance.
Do not modify the power supply plug provided with the appliance - if it will not
t the outlet, have a proper outlet installed by a quali ed electrician. Do not use
an extension cord, adapter plug or multiple outlet box.
Failure to follow this advice may result in electrical shock or death.
Cut hazard
Take care - panel edges are sharp.
Failure to use caution could result in injury or cuts.
WARNING!
WARNING!

Important safety instructions!

Installation of this DishDrawer® requires basic mechanical and electrical skills.
Be sure to leave these Instructions with the Customer.
Installation must comply with your local building and electricity regulations.
At the completion of the DishDrawer® installation, the Installer must perform
Final Check List.
Remove all packaging materials supplied with the DishDrawer®.
This DishDrawer® is manufactured for indoor use only.
Ensure all water connections are turned OFF. It is the responsibility of the plumber and
electrician to ensure that each installation complies with all Codes and Regulations.
The DishDrawer® MUST be installed to allow for future removal from the enclosure if service is required.
The switched power outlet must be outside the DishDrawer® cavity so that it is accessible after
installation.
Care should be taken when the appliance is installed or removed to reduce the likelihood of damage to
the power supply cord.
If the DishDrawer® is to be relocated from one installation to another it must be kept upright to avoid
damage from water spillage.
Make sure only new hoses are used for connection (supplied with DishDrawer®). Old hoses should not
be reused.
Failure to install the DishDrawer® correctly could invalidate any warranty or liability claims.
If the product is installed in a motor vehicle, boat or similar mobile facility, you must bring the vehicle,
boat or mobile facility containing the product to the service shop at your expense or pay the service
technician's travel to the location of the product.
US CA

Advertisement

Table of Contents
loading

Summary of Contents for Fisher & Paykel DishDrawer DD24S

  • Page 1: Safety And Warnings

    Installation instructions DishDrawer® US CA DD24S models Important! SAVE THESE INSTRUCTIONS The models shown in this document may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go to our website www.fisherpaykel.com or contact your local Fisher &...
  • Page 2 Installation diagrams for illustration purposes only Installation diagrams for illustration purposes only Product dimensions Cabinetry dimensions (inches (mm)) (inches (mm)) overall height* of product inside height of cavity 16 ¼ ” 16 ¼ ” 16 ¼ ” (409) (409) (409) (412) (412) (412)
  • Page 3: Parts Supplied

    PARTS SUPPLIED Clamp (1) Edge Protector (1) Drain hose Drain hose Wire clip (1) Top mounting Phillips Washer (1) Moisture protection (if service hole support (1) joiner (1) brackets (2) 16 mm tape (1) screws (7) (to prevent moisture partition is metal) damage) If the Drain hose(s) supplied are not long enough to reach your services, you must use a Drain Hose Extension Kit P/N 525798 which will extend the drain hose(s) by 11’...
  • Page 4: Optionally Hard Wiring The Product

    OPTIONALLY HARD WIRING THE PRODUCT Remove the access cover ” (30 mm) 30 mm Remove Power supply Ensure the drawer is removed and then rotated counter- Access cover clockwise to prevent kinked hoses. Remove knock-out for cable clamp. Fit suitable cable clamp for the conduit and terminate Ensure the drawer clips the wiring as shown.
  • Page 5: Route The Hoses And Move Into The Cavity

    ROUTE THE HOSES AND MOVE INTO THE CAVITY If top mounting brackets are being used, ensure they’re securely tted before sliding optional product into cavity (x2) Ensure hoses and cord are not kinked or twisted. Tie together to avoid kinking. REMOVE THE DRAWER AND SECURE THE PRODUCT The product has three pairs of mounting brackets: a pair of...
  • Page 6 REFIT THE DRAWER Ensure the drawer clips on both sides are reset. Before re tting the drawer , ensure the hoses are not twisted and the latches at the rear of each drawer runner are facing forward. Ensure the drawer is now rotated clockwise back.
  • Page 7 PLUMBING AND DRAINAGE OPTIONS DishDrawer® with Waste Disposal DishDrawer® using Air Break DishDrawer® and Standpipe with Drain Hose Joiner Ø 1 1/2” (38 mm) If space is limited for xing, push If space is limited for xing, push hose through drain hose support hose through drain hose support to required height to required height...
  • Page 8 Excessive water remaining above the lter plate, after the rinse cycle Check all parts are installed. Ensure product is level, securely fastened to the cabinetry and opens and closes Check for kinked drain hoses or blocked waste connection, high loop not freely.
