Yamaha DVX-S301 Service Manual

Dvd home theater sound system
Hide thumbs Also See for DVX-S301:

Advertisement

DVD HOME THEATER SOUND SYSTEM
DVR-S300/
This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already
known and understood by the users, and have therefore not been restated.
WARNING:
IMPORTANT:
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and
service departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable
and specifications are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist, please
contact the distributor's Service Division.
WARNING:
IMPORTANT:
I CONTENTS
TO SERVICE PERSONNEL ...................................... 2~3
LOCALE MANAGEMENT INFORMATION ................... 4
FRONT PANELS ........................................................ 6~7
REMOTE CONTROL ...................................................... 8
REAR PANELS ........................................................ 8~12
SPECIFICATIONS / 参考仕様 ................................ 13~15
INTERNAL VIEW ......................................................... 16
REPAIR NOTES / 修理上の留意点 .............................. 17
DVR-S300 トレードモード ........................................ 18
分解手順 ............................................................... 19~21
分解手順 ............................................................... 22~23
1 0 0 9 6 5
本资料由OKXIA视听皮带资源库www.okxia.cn提供
Failure to follow appropriate service and safety procedures when servicing this product may result in personal
injury, destruction of expensive components, and failure of the product to perform as specified. For these reasons,
we advise all YAMAHA product owners that any service required should be performed by an authorized
YAMAHA Retailer or the appointed service representative.
The presentation or sale of this manual to any individual or firm does not constitute authorization, certification or
recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form.
Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).
Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.
2005
This manual is copyrighted by YAMAHA and may not be copied or
redistributed either in print or electronically without permission.
DVX-S301/DVX-S302
NX-P301/NX-P302
SERVICE MANUAL
SERVICE MANUAL
SERVICE MANUAL
IMPORTANT NOTICE
DVR-S300 BLOCK DIAGRAM .................................... 25
NX-SW301 BLOCK DIAGRAM .............................. 26~27
DVR-S300 WIRING DIAGRAM .................................... 28
NX-SW301 WIRING DIAGRAM ................................... 29
DVR-S300 PRINTED CIRCUIT BOARD ............... 30~37
NX-SW301 PRINTED CIRCUIT BOARD ............... 38~41
DVR-S300 SCHEMATIC DIAGRAM ...................... 42~55
NX-SW301 SCHEMATIC DIAGRAM ..................... 56~60
NX-SW301 PARTS LIST ........................................ 61~63
DVR-S300 EXPLODED VIEW ............................... 64~65
NX-P301 EXPLODED VIEW .................................. 66~67
NX-P302 EXPLODED VIEW ........................................ 68
All rights reserved.
P.O.Box 1, Hamamatsu, Japan
'05.08
