Muratec MFX-2000 Specifications

A fax,copi e r and pri n ter
i n every department?
Every working day, more and more otherwise
productive minutes slip away as your employees
wait for the copier, or wait for the fax. But you
can't afford to give every department its own
copier and fax. Or ... can you?
As a matter of fact, now you can. Because,
now, there's the Muratec MFX-2000 – a superb
fax and digital copier. Its cover ("platen top")
opens to let you easily fax or copy from books,
ledgers or other three-dimensional objects.
And, still better yet, it optionally also becomes
a high-quality PC or LAN † printer.
MFX - 2 000
S P E C I F I C A T I O N S
Yes.
F E A T U R E S High-volume plain-paper printing of fax messages and copies
• Uses ordinary paper in letter, legal or 11
• Standard capacity of 600 sheets (two 300-sheet cassettes)
• Accepts one or two optional cassettes to boost capacity to
• Multipurpose single-sheet tray
Platen-top (cover) or automatic feeding of originals
• Platen top lets you fax or copy easily from books, ledgers and
• 50-page automatic document feeder for flat sheets
High-reliability digital copying
• Scan-once/print-many method requires fewer moving parts
• 9.6-second first-copy-out time (FCOT)
• Reduction/enlargement – 50%–200%
• Up to 99 copies per original
• Sorting and stacking
Muratec TriAccess
Large graphical display for easy operation
50-page automatic document feeder
• Stacks transmitted and printed documents in original order
Substantial memory, standard or optional***
• Standard capacity, 238 pages
• Expandable to 558 pages
High-speed operation
• 14.4 Kbps modem
• 1.4-second quick scan
• 15-ppm laser print engine
• 6-second transmission speed
Broadcasting – up to 197 locations
Relay broadcasting – initiation and "hub" activity
Batch transmissions
• Saves up to 40 documents in up to 5 "batch boxes"
Muratec America, Inc. • 6400 International Parkway, Suite 1500 • Plano, TX 75093. For more information on Muratec products and services,
call (972) 364-3300 or visit our Web site at www.muratec.com • MK3069
Type High-speed facsimile transmitter and receiver for home and office use
Phone Line Normal Public Switched Telephone (PSTN) line or equivalent
Modem 14,400 bps with fallback to 12,000, 9,600, 7,200, 4,800 and 2,400 bps per ITU-T, v.29 and v.27 ter.
Compatability ITU-T Group 3
Transmission Speed 6 seconds per page*
Copier Type Digital; scan-once/print-many
First-Copy-Out Time 9.6 seconds
Feeder Capacity (20-pound bond) 50 letter-sized sheets
Resolution (in lpi, horizontal vertical): Normal, 203 98; fine, 203 196; superfine, 203 392;
Muratec-proprietary, 305 x 293
Grayscale 64-level
Printing Width 11.7 ADF, letter-sized sheets) * Based on transmission of
ITU-T Test Document 1 to a
Scanning Width 11.6 ADF, letter-sized sheets) Muratec fax. Your transmission
times will vary, but your
Scanning Method Flatbed CCD
Muratec fax machine always
will provide the fastest
Printing Method Dry, electrophotographic (laser) process
transmission speeds possible
Consumables Yield Drum cartridge, 21,000-30,000 pages; toner cartridge, 5,500-7,000 pages.** under ITU-T guidelines and
phone line conditions.
Recording Paper Standard: two 300-sheet cassettes, letter-, legal- or tabloid-sized sheets; optional third and fourth
Capacity 300-sheet cassettes provide total possible capacity of 1,200 sheets ** Based on letter-sized
sheets and 4% document cover-
Acceptable
(width x height): ADF, single sheet – 12.0" x 35.4" maximum, 4.7" x 3.9" minimum; ADF, two or more sheets – age. In each case, lower figure is
for two-page printing cycle,
Document Size 11.7" x 16.5" maximum, 4.7" x 3.9" minimum; platen-top , 11.7" x 16.5" maximum, 4.7" x 3.9" minimum
while higher figure is for
continuous printing.
Weight 111.1 pounds
Dimensions (width depth height): 22.9 24.2 20.6
*** Based on ITU-T Test
Document 1 stored at
Power 120v ± 10%, 50–60 Hz
normal resolution.
ITU-T superfine transmission, Error Correction Mode (ECM)
17 sizes
Automatic reduction of oversized fax documents
Smoothing and 64-level grayscale
Security and control features
either 900 or 1,200 sheets
• Passcode protection for a variety of operations
• SecureMail ™ for confidential documents
• Junk fax barrier
• Security transmission
other three-dimensional objects
• Closed network operation
• Departmental coding
192-number autodialer As an E
NERGY
partner, Muratec America,
• 72 one-touch numbers, 120 speed-dial numbers
Inc., has determined
that the F-95 meets the
• 70 delayed dialing commands
E NERGY S TAR
• 32 call groups
energy efficiency.
• EasyDial alphanumeric directory dialing
Eight programmable multi-function keys
™ provides maximum access to machine
Journals, reports and displays
User-controlled confirmation stamp † Check with your
authorized Muratec dealer
Page numbering
about availability.
E S ® compliance for energy efficiency
NERGY TAR
Muratec, the Muratec logo
Optional second phone line (33.6 Kbps modem) and all Muratec product and
feature names are trademarks
• Gives you two fax machines in one device
of Muratec America, Inc.
• Allows simultaneous reception and transmission Windows is a registered
trademark of Microsoft
Optional Centronics ® parallel port and GDI software
Corporation. Centronics is a
registered trademark of
for PC printing
Centronics Corporation. E
• Works with Microsoft ® Windows ®
S TAR and the Energy Star logo
• Up to 400 dpi quality are registered marks of the
United States Environmental
• Standalone or LAN † options
Protection Agency.
Optional stand for greater convenience
All the information in this
• Allows easy storage of consumables
document is subject to change
• Lets you move the unit easily if necessary without notice.
© 1997 Muratec America, Inc.
S ®
TAR
guidelines for
NERGY
Muratec
MFX - 2 000
