Page 1: Quick Start Guide
® MultiModem GPRS & CDMA External Wireless Modems MTCBA-G-F1 MTCBA-G-F2 MTCBA-C Quick Start Guide... - Page 2 All rights reserved. This publication may not be reproduced, in whole or in part, without prior written permission from Multi-Tech Systems, Inc. Multi-Tech Systems, Inc. makes no representations or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.
-
Page 3: General Safety
MultiModem Introduction This guide shows you how to setup your Multi-Tech wireless MultiModem. For detailed information, product specification, troubleshooting tips, and warranty repair policies, see the User Guide, available on the MultiModem CD accompanying your wireless modem. General Safety The modem is designed and intended to be used in either fixed or mobile applications. - Page 4 ® MultiModem GPRS & CDMA Quick Start Guide • Switch OFF the MultiModem in the vicinity of gasoline or diesel-fuel pumps or before filling a vehicle with fuel. • Switch OFF the MultiModem in hospitals and any other place where medical equipment may be in use. •...
- Page 5 MultiModem • “WARNING - EXPLOSION HAZARD - Do not Disconnect Equipment Unless Power has been switched off or the area is known to be Non - Hazardous”. • “WARNING - EXPLOSION HAZARD - Do not replace the Fuse Unless Power has been switched off or the area is known to be Non - Hazardous”.
- Page 6 ® MultiModem GPRS & CDMA Quick Start Guide Maintenance of the Wireless MultiModem Your Wireless MultiModem is the product of advanced engineering, design and craftsmanship and should be treated with care. The suggestions below will help you to enjoy this product for many years. •...
-
Page 7: Package Contents
MultiModem Package Contents Basic Package one modem • two holding bridles (mounting brackets) • one fused power cable • Bundled Package all of the above, plus • one RS232 15-to-9 pin cable • one antenna • four adhesive-backed rubber feet for table-top •... - Page 8 ® MultiModem GPRS & CDMA Quick Start Guide Attaching MultiModem to a Fixed Location Typically, the MultiModem is mounted against a flat surface with two mounting screws. Drill the mounting holes at the desired location separated by 125mm (4 -15/16 inches) center-to-center.
- Page 9 MultiModem clearance under the RS232 cable. Maximum mounting screw-head thickness is 2mm. Si de Vi ew Inserting the SIM Card into the Holder The wireless MultiModem requires a SIM card (Subscriber Identity Module) to operate on a GSM network. To install the card, do the following: Using your fingernail or a small screwdriver, pry off the SIM cover.
-
Page 10: Connecting The Antenna
® MultiModem GPRS & CDMA Quick Start Guide Verify that the SIM card fits into the holder properly and then replace the cover. Connecting the Antenna Connect a suitable antenna to the SMA connector (see “Antenna/RF Specifications” in the User Guide ). Ant enna C onnect or ( SM A t ype) -
Page 11: Connecting The Serial Cable
® MultiModem GPRS & CDMA Quick Start Guide Connecting the Serial Cable Connect both ends of the serial and control cable (15-pin Sub D connector on the modem end). Ser i al & C ont r ol C onnect or To Seri al Port of PC... - Page 12 ® MultiModem GPRS & CDMA Quick Start Guide Connecting the Power Supply Cable Plug the power supply cable into the wireless MultiModem. 2a. For standard transformer power supply . • Connect the AC cord receptacle into the transformer block. • Connect the AC cord plug into the mains power outlet.
-
Page 13: Phone Number For The Wireless Modem
MultiModem Note: For automotive applications: according to the type of application, you can use permanent “+” or key-switched “+”. Connect the power supply to its source (for example, in a mobile situation, to the vehicle’s DC fuse/terminal block). Activate the DC power supply. AT Commands A complete set of AT command definitions can be found in the AT Command Reference Guides (one for GPRS and one... -
Page 14: Mobile Phonetools
® MultiModem GPRS & CDMA Quick Start Guide For CDMA point to point data, a circuit-switched data connection is used. The user can set up DUN to make a conventional V.32 modem connection to any terminating modem at the other end. The phone number specified in DUN can be one supplied by the wireless service provider or another phone number related to a different dialup modem service (e.g., a dialup modem service phone number from... - Page 15 ® MultiModem GPRS & CDMA Quick Start Guide...
- Page 16 Patents This device is covered by one or more of the following patents: 6,031,867; 6,012,113; 6,009,082; 5,905,794; 5,864,560; 5,815,567; 5,815,503; 5,812,534; 5,809,068; 5,790,532; 5,764,628; 5,764,627; 5,754,589; 5,724,356; 5,673,268; 5,673,257; 5,644,594; 5,628,030; 5,619,508; 5,617,423; 5,600,649; 5,592,586; 5,577,041; 5,574,725; 5,559,793; 5,546,448; 5,546,395; 5,535,204; 5,500,859; 5,471,470; 82001225L...
