- Page 1 ® MultiModem GPRS USB Wireless Modem MTCBA-G-U User Guide...
- Page 2 Europe, Asia, Africa: support@multitech.co.uk U.S., Canada, all others: support@multitech.com Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Copyright and Technical Support By Phone +(33) 1-64 61 09 81 +(44) 118 959 7774 (800) 972-2439 or +(763) 717-5863...
-
Page 3: Table Of Contents
Chapter 5 – Reference Information...32 Wireless Modem Reference Information ...32 Appendix A – Warranty and Repairs ...33 Appendix B - Waste Electrical and Electronic Equipment (WEEE) Statement ...35 Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Contents Table of Contents... -
Page 4: Chapter 1 - Product Description And Specifications
• Packet data up to 85K bps • Embedded TCP/IP stack • Circuit-switched data (GSM) up to 14.4K bps transparent and non- transparent Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 1 – Product Description and Specifications... -
Page 5: Application Overview
Using the embedded Internet protocols and the wireless connection to an IP network, it sends and receives data over the Internet. It can also serve a single web page in response to a web browser request. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 2 – Installation... -
Page 6: Safety
Therefore, keep it in a safe place at all times and out of the reach of children. Try to remember your Unlock and PIN codes. Become familiar with and use the security features to block unauthorized use and theft. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 2 – Installation... -
Page 7: Package Contents
Part to be Supplied by Your Wireless Service Provider Subscriber Identity Module (SIM) configuration chip. The SIM contains information specific to your wireless account and its features. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Bundled Package (multiple units) Each individual package in the bundle includes... -
Page 8: Specifications
Impedance VSWR Typical Radiated Gain Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide 4.3" L x 2.4" W x 0.94" H; 4.2 oz. (11 cm x 6.1 cm x 2.4 cm; 119 g) Antenna Connection type: SMA jack... -
Page 9: Interfaces
Power. Indicates presence of DC power when lit. AT Command Reference Guides AT commands for the GPRS USB wireless modem are published in a separate GPRS AT Commands Reference Guide included on the MultiModem CD and posted on the Multi-Tech web site. -
Page 10: Chapter 2 - Activation And Installation
Using your fingernail or a small wedging tool (e.g., a small screwdriver), pry off the SIM cover. Insert the SIM card into the holder. Verify that the SIM card fits into the holder properly and then replace the cover. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Installation Chapter 2 – Activation and Installation... -
Page 11: Step 3 - Connect The Antenna And Usb Cable
Connect one end of the USB cable to the modem and the other end to the PC. Step 4 – Handset Connection (Optional) If you intend to use a phone handset, connect it to the MultiModem now. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem... -
Page 12: Step 5 - Attach The Modem To A Flat Surface (Optional)
Slide the mounting brackets into the corresponding slots on the backside of the MultiModem chassis. Attach the MultiModem with two screws to the mounting surface at the desired location on the equipment. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem... -
Page 13: Step 6 - Install The Modem Driver
The Found New Hardware Wizard screen now displays the TUSB3410 Serial Port device. This is the first of three New Hardware Wizards that will appear. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem... - Page 14 USB driver is now complete. The second Found New Hardware wizard will start automatically to associate the PC port with the USB driver. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...
- Page 15 (floppy, CR-ROM…). Click Next. A second Windows Logo Testing screen may appear depending on operating system settings. This screen pertains to the MTS GPRS USB – Serial Port. Click Continue Anyway. The Completing the Found New Hardware Wizard screen appears.
- Page 16 The Completing the Found New Hardware Wizard screen appears. Click Finish. With the modem .inf file successfully installed, the entire software installation procedure for the Wireless USB MultiModem is complete. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...
-
Page 17: Installing The Modem Driver In Windows 2000
Click on Search for a suitable driver for my device (recommended) Click Next. The Locate Driver Files screen appears. Click in the Optional search locations: on CD-ROM drive option. Click Next. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem... - Page 18 Installation of the USB driver is now complete. The second Found New Hardware wizard will start automatically to associate the PC port with the USB driver. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...
- Page 19 USB driver has been made. Click Finish. The third Found New Hardware Wizard will start automatically to install the modem INF file. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...
- Page 20 The Completing the Found New Hardware Wizard screen appears. Click Finish. With the modem .inf file successfully installed, the entire software installation procedure for the Wireless USB MultiModem is complete. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...
-
Page 21: Chapter 3 - Using Your Wireless Modem
The software version displays. For example: 651_09gg... • Type ATI6 Displays modem data features. For example: data rates, data modes, fax classes. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Modem Network Registration Verification Chapter 2 – Activation and Installation... -
Page 22: Establishing A Voice Call
Disconnect: Type: +++ Wait about one second to see an OK response. Then type: ATH Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem (Operation not allowed) • The phone number you are calling is entered between the displayed brackets. -
Page 23: Using Short Message Services (Sms)
Note: The x represents an index location. The n stands for the type of messages to delete. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem "REC UNREAD" Shows received unread messages. -
Page 24: Sms Examples
(set to Phase 2) +CSMS: 1,1,1 at+cnmi=2,2,0,0,0 (set to receive SMS and route directly to TE) +CMT: "+17632273726",,"06/03/17,13:59:18+00" (message received and directly routed to TE) TEST2 Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem... - Page 25 (set to Phase 2+) +CSMS: 1,1,1 at+cnmi=2,2,0,0,0 (set to receive SMS and route directly to TE) +CMT: "+17632273726",,"06/03/17,14:01:17+00" (message received and directly routed to TE) TEST3 at+cnma (acknowledge that message has been received) Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide...
-
Page 26: Internet Access
For <APN>, type in the correct APN for your account. For example: AT+CGDCONT=1,”IP”,”ISP.CINGULAR” Click OK to close the modem Properties window. Then click OK to close the Phone and Modem Options window. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem... - Page 27 Scroll up and click on Disconnect. Your should now be disconnect from the Internet. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem Important: Make sure that Use...
-
Page 28: Mobile Phonetools
PC and use it for making Internet connections, voice calls, SMS messaging, and email. This program allows you to use your wireless modem hooked up to your PC as if it were a cell phone. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide... -
Page 29: Chapter 4 - Troubleshooting And Frequently Asked Questions
(esp. for voice communication) Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 4 – Troubleshooting and Frequently Asked Questions Action In communications program, verify that modem parameters have been set to the values shown here:... -
Page 30: Frequently Asked Questions
• In PDU mode using 7-bit, the modem still supports 160 characters, but in 8-bit the modem will support only 70 characters. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 4 – Troubleshooting and Frequently Asked Questions... - Page 31 Here is an example of how to send an SMS message to an email account: AT+CMGS=”0000” > email@multitech.com My message goes here. <ctrl +Z> Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 4 – Troubleshooting and Frequently Asked Questions...
-
Page 32: Chapter 5 - Reference Information
GSM 07.01,GSM 07.02, GSM 07.05, GSM 07.07. ETSI contact: ETSI Secretariat F-06921 Sophia Antipolis Cedex, France e-mail: secretariat@etsi.fr Service: The AT commands manual is available on the Multi-Tech web site: http://www.multitech.com Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 5 – Reference Information... -
Page 33: Appendix A - Warranty And Repairs
(800) 328-9717 or (763) 717-5631, or email mtsrepair@multitech.com. Repairs for damages caused by lightning storms, water, power surges, incorrect installation, physical abuse, or user- caused damages are billed on a time-plus-materials basis. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide... - Page 34 SupplyNet, Inc. 614 Corporate Way Valley Cottage, NY 10989 Phone: 800 826-0279 Fax: 914 267-2420 Email: info@thesupplynet.com Internet: http://www.thesupplynet.com Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Appendix A – Warranty and Repairs support@multitech.com. mtsrepair@multitech.com. mtsrepair@multitech.com. When calling the...
-
Page 35: Appendix B - Waste Electrical And Electronic Equipment (Weee) Statement
For more information about where you can drop off your waste equipment for recycling, please contact your local city office, your household waste disposal service or where you purchased the product. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide...
