Summary of Contents for Multitech MTD-H5
- Page 1 QuickCarrier™ USB-D MTD-H5 and MTD-EV3 Best Practices...
- Page 2 QuickCarrier USB-D MTD-H5 and MTD-EV3 Best Practices S000600, Version 1.1 Copyright This publication may not be reproduced, in whole or in part, without prior expressed written permission from Multi-Tech Systems, Inc. All rights reserved. Copyright © 2014 by Multi-Tech Systems, Inc.
-
Page 3: Table Of Contents
Related Documentation ..............................4 For MTD-H5 Devices ............................... 4 For MTD-EV3 Devices ..............................4 Installing and Removing SIM Cards in an MTD-H5 .......................5 Installing a SIM Card ................................5 Removing a SIM Card ................................6 SIM cards that require a PIN to unlock SIM before use ...................... 6 Powering Devices On and Off .............................7... -
Page 4: Overview
For MTD-H5 Devices Document Description QuickCarrier USB-D MTD-H5 User Guide Provides an overview, specification, safety and regulatory information, and SIM cards and basic operations. (Part: S000551) USB Driver Installation Guide for H5 and Instructions for installing USB drivers on Linux and Windows... -
Page 5: Installing And Removing Sim Cards In An Mtd-H5
Installing and Removing SIM Cards in an MTD-H5 Installing a SIM Card Only MTD-H5 models have a SIM card. Warning: If the device is connected to a computer or power supply, disconnect it. Inserting or removing a SIM card with the device powered may harm the SIM card and the device. -
Page 6: Removing A Sim Card
AT+CPIN=XXXXX is the command to set and read the PIN used for the SIM card. Entering an invalid PIN or entering a PIN for a SIM that doesn’t require one could cause the SIM to become locked. Typically XXXX failures while trying to enter the SIM PIN may lock the SIM. QuickCarrier USB-D MTD-H5 and MTD-EV3... -
Page 7: Powering Devices On And Off
Some terminal communication scripts send AT commands to the modem. Wait 30 seconds after the OK to allow the radio to disconnect from the carrier and close out file systems. It is now safe to remove power or unplug the MTD. QuickCarrier USB-D MTD-H5 and MTD-EV3... -
Page 8: Basic Operations
Issue the following command to disconnect: AT#SGACT=1,0 Using the Host IP Stack Disconnect a Data Connection The method to disconnect depends on the type of PPP dialer that was used to establish the data connection. QuickCarrier USB-D MTD-H5 and MTD-EV3... -
Page 9: Responding To Failed Connections
If a connected call drops for any reason: Wait 30 seconds and restart the sequence again. Carrier Issues MTD-H5 Congested cellular towers may bump data devices since voice calls take priority. Idle data devices may also experience dropped connections. QuickCarrier USB-D MTD-H5 and MTD-EV3... -
Page 10: Getting Help
Getting Help Several things can affect cellular modem service. Who you contact for help depends on what issue you are having: Contact the Cellular Carrier (SIM card provide for MTD-H5 models) for the following: Issues with account configuration. ... -
Page 11: Carrier Information For Mtd-Ev3
Application should wait for a #9xx indication the process has completed before proceeding. Be aware after the HFA process is successfully completed the radio will be reset. The radio may also reset after other OMA functions. QuickCarrier USB-D MTD-H5 and MTD-EV3... -
Page 12: 9Xx Oma Unsolicited Indications
#911 PRL - Error - credential error #912 PRL - Error - unreachable server #913 PRL - Error - network error #915 PRL - Error - update failed for other reasons #DREL Data session release QuickCarrier USB-D MTD-H5 and MTD-EV3... - Page 13 AT#OMADMSVADDR=<URL> https://oma.ssprov.sprint.com/oma) AT#OMADMSVADDR? Read OMA-DM server address AT#OMADMSVPORT=<port#> Set OMA-DM server (default 443) AT#OMADMSVPORT? Read OMA-DM server Set OMA-DM proxy server port/URL (default AT#OMADMPROXY=<port#>,<URL> http://oma.ssprov.sprint.com:80) Set OMA-DL Proxy DL Server Port URL (default AT#OMADLPROXY=<port#>,<URL> http://oma.ssprov.sprint.com:80) QuickCarrier USB-D MTD-H5 and MTD-EV3...
- Page 14 SPC or MSL (currently last 6 digits MEID) AT#DCCANCEL Cancel Device Configuration (DC) Session AT#PRLCANCEL Cancel Preferred Roaming List (PRL) Session AT$PRL? Query Preferred Roaming List (PRL) ID # Cancel Firmware Update Management Object AT#FUMOCANCEL (FUMO) session. QuickCarrier USB-D MTD-H5 and MTD-EV3...
-
Page 15: Prl Updates
PRL updates for Sprint and Verizon are over the air updates. To update your PRL, issue the following commands. For Sprint AT+PRL=2 For Verizon AT+CDV*22899 Other Carrier Notes Congested cell towers may bump data devices. QuickCarrier USB-D MTD-H5 and MTD-EV3...
