Connections

CONNECTING THE OPTIONAL WIRELESS RECEIVING

To connect the rear speakers by wireless, you have to purchase the wireless receiving module and TX card from
your Samsung retailer.
When you have Purchased the Wireless Receiving Module (SWA-4000)
This product (HT-BD1250) should be connected only with SWA-4000.
Rear Speaker (L)
WIRELESS RECEIVER MODULE
1. Connect the front, center and Subwoofer speakers to the
Blu-Ray Home Theater, referring to page 21.
2. With the Blu-Ray Home Theater turned off, insert the TX card
into the TX Card Connection(WIRELESS) on the back
of the main unit.
•
Hold the TX card so that the slanted side faces to the left
and insert the card into the port.
•
The TX card enables communication between the main
unit and the wireless receiver.
3. Connect the left and right rear speakers to the wireless
receiving module.
4. Plug the power cord of the wireless receiving module
in the wall outlet.
22
Center Speaker
Front Speaker (R)
Rear Speaker (R)
Front Speaker (L)
Subwoofer
TX card
Slanted side face left
