Cub Cadet CC2025 Parts List

60
61
59
66
70
49
57
Item Part No. Description
1 753-04015 Cylinder
2 753-04016 Cylinder Base Gasket
3 791-181706 Bolt
4 791-181707 Insulator
5 791-181708 Insulator Gasket
6 791-181709 Carburetor Gasket
7 791-181710 Screw and Washer
8 753-1176 Muffler Assembly (includes 9 & 10)
9 753-1177 Muffler
10 791-181713 Screw
11 791-181714 Muffler Gasket
12 791-181715 Muffler Plate
13 791-181716 Screw
14 791-181717 Crankcase Service Assembly
(includes 15-20 & 25)
15 791-181718 Crankcase Gasket
16 791-181719 Bearing
17 791-181720 Oil Seal
18 791-181721 Oil Seal
19 791-181722 Snap Ring
20 791-181723 Screw
21 753-04018 Piston
22 791-182014 Ring
23 791-182015 Piston Pin
24 791-181727 Snap Ring
25 753-04019 Crankshaft
26 791-181729 Key
27 791-181730 Clutch
28 791-181074 Clutch Washer
29 791-181731 Spacer
30 791-181732 Flywheel Assembly
31 791-181733 Module Assembly (includes 32 & 33)
32 791-181734 Spacer
33 753-1181 Screw
34 791-181777 Recoil Assembly (includes 35-41)
35 791-181737 Recoil Case
36 791-181738 Recoil Pulley
37 791-181739 Recoil Spring
38 791-181740 Screw
39 791-181741 Washer
40 791-181742 Rope
64 71
31
58
65
33
32
62
5
63
47
13
7
12
50
55
52
54
6
48
51
53
49
56
27
28
29
30
10
9
11
3
1
8
2
22
24
21
4
23
24
16
14
26
17
25
45
18
19
20
14
15
Item Part No.
41 791-181079
42 791-182118
43 791-181745
44 791-181746
45 791-181747
46 791-181716
47 791-181748
48 753-04389
49 791-181750
50 791-181751
51 791-181752
52 791-181753
53 791-181754
54 791-181755
55 791-181756
56 791-181757
57 791-181758
58 753-1178
59 791-181760
60 791-181761
61 791-181762
62 753-1179
63 791-181716
64 791-181762
65 791-181765
66 791-182188
67 791-181766
68 791-182612
69 791-181768
70 791-181769
71 791-182157
* 791-181696
* 791-181701
* 791-181702
* 791-181703
* not shown
ENGINE PARTS - CC2025
2-CYCLE GAS TRIMMER
PPN 41ADC25C010
38 39
36
37
40
41
42
68
44
43
16
Description
Pull Handle
Pulley Assembly (includes 43-45)
Ratchet
Spring
Retaining Ring
Screw
Throttle Bracket
Carburetor (includes Primer Bulb)
Screw
O-Ring
Air Cleaner Assembly (includes 52-57)
Sleeve
Choke Plate
Choke Lever
Screw
Air Filter
Air Cleaner Cover
Clutch Housing Assembly
Bolt
Nut
Screw
Engine Cover
Screw
Screw
Spark Plug
Screw
Fuel Tank (68-69 includes fuel lines)
Fuel Cap Assembly
Screw
Lead Wire Assemby
Grommet
Spark Arrestor
Primer Bulb
Carburetor Repair Kit
Gasket/Diaphragm Repair Kit
35
34
46
67
69
Issued 9/03
