Recoil start and electric start 7hp pony rear-tine tiller
Hide thumbs Also See for 12211:
Table of Contents

Advertisement

Quick Links

SAFETY FIRST!
Before operating this equipment, read this
Owner's Manual and the separate manual
supplied by the engine manufacturer.
Models
12211 – Recoil Start
12212 – Electric Start
OWNER'S MANUAL
7HP PONY
REAR-TINE TILLER
Safety
•
Assembly
•

Features and Controls

•
Operation
•
Maintenance
•

Parts List

•
(Recoil Start Model shown)
GARDEN WAY INCORPORATED
®
