Figure 750
CSA INTERNATIONAL
Project 1932582
ASSEMBLY & OPERATING INSTRUCTIONS
Model: 720-0578
FOR PROPANE GAS USE ONLY
This instructions manual contains important information necessary for the proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling and using the appliance
Follow all warnings and instructions when using the appliance
Keep this manual for future reference
FOR OUTDOOR USE ONLY
G09Y07P-2
1
