Basic Operating Instructions

Digital Camera

DMC-FH22
Model No.
Before use, please read the instructions
completely.
Please also refer to
Operating Instructions (PDF
format) recorded on the
CD-ROM containing the Operating Instructions
(supplied).
You can learn about advanced operation methods
and check the Troubleshooting.
VQT2L07
GN
H0110HM0

Advertisement

Table of Contents
loading

Related Manuals for Panasonic DMC-FH22 Lumix

Summary of Contents for Panasonic DMC-FH22 Lumix

  • Page 1: Basic Operating Instructions

    Basic Operating Instructions Digital Camera DMC-FH22 Model No. Before use, please read the instructions completely. Please also refer to Operating Instructions (PDF format) recorded on the CD-ROM containing the Operating Instructions (supplied). You can learn about advanced operation methods and check the Troubleshooting. VQT2L07 H0110HM0...

  • Page 2: Information For Your Safety

    Dear Customer, We would like to take this opportunity to thank you for purchasing this Panasonic Digital Camera. Please read these Operating Instructions carefully and keep them handy for future reference. Please note that the actual controls and components, menu items, etc.
  • Page 3 About the battery pack CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. • Do not heat or expose to fl ame. •...
  • Page 4 Cautions for Use • Always use a genuine Panasonic AC adaptor (DMW-AC5G: optional). • When using an AC adaptor, use the AC cable supplied with the AC adaptor. • Do not use any other AV cables except the supplied one.
  • Page 5 Keep the camera as far away as possible from electromagnetic equipment (such as microwave ovens, TVs, video games etc.). • If you use the camera on top of or near a TV, the pictures and sound on the camera may be disrupted by electromagnetic wave radiation. •...

  • Page 6: Table Of Contents

    Contents Information for Your Safety ..............2 Before Use Standard Accessories................7 Names of the Components ..............8 How to Use the Touch Panel ..............9 Preparation Charging the Battery ................10 About the Built-in Memory/the Card ...........12 Inserting and Removing the Card (optional)/the Battery ....13 Setting Date/Time (Clock Set) ............14 Setting the Menu ................15 Selecting the [REC] Mode ..............16...

  • Page 7: Before Use

    Before Use Standard Accessories Check that all the accessories are included before using the camera. Product numbers are correct as of January 2010. These may be subject to change. Battery Pack (Battery Pack is indicated as battery pack or battery in the text.) Charge the battery before 1 CGA-S/106C...

  • Page 8: Names Of The Components

    Before Use Names of the Components Flash Lens Self-timer Indicator AF Assist Lamp Touch Panel/LCD Monitor [REC]/[PLAYBACK] selector switch [MODE] button [DISPLAY] button [MENU] button [Q.MENU]/Delete button 10 Camera ON/OFF switch 11 Zoom lever 12 Speaker 13 Microphone 14 Shutter button 15 Intelligent auto button 12 13 14 15...

  • Page 9: How To Use The Touch Panel

    22 21 22 DC coupler cover • When using an AC adaptor, ensure that the Panasonic DC coupler (DMW-DCC4; optional) and AC adaptor (DMW-AC5G; optional) are used. How to Use the Touch Panel You can operate by directly touching the LCD Monitor (Touch Panel) with your fi...

  • Page 10: Preparation

    The only batteries suitable for use with this unit are genuine Panasonic products and batteries manufactured by other companies and certifi ed by Panasonic. (Batteries which do not support this function cannot be used.) Panasonic cannot in any way guarantee the quality, performance or safety of batteries which have been manufactured by other companies and are not genuine Panasonic products.
  • Page 11 • CIPA is an abbreviation of [Camera & Imaging Products Association]. • Temperature: 23 °C/Humidity: 50% when LCD monitor is on. • Using a Panasonic SD Memory Card (32 MB). • Starting recording 30 seconds after the camera is turned on. (When the Optical Image Stabilizer function is set to [AUTO].)

  • Page 12: About The Built-In Memory/The Card

    Cards, check your computer and other devices support this type of card. SDXC Memory Card http://panasonic.net/avc/sdcard/ (48 GB to 64 GB) information/SDXC.html • If you use cards between 4 GB and 32 GB capacity, confi rm SDHC logo on the card (indicating compliance with the SD standard).

  • Page 13: Inserting And Removing The Card (Optional)/The Battery

    Preparation Inserting and Removing the Card /the Battery (optional) • Check that this unit is turned off. • We recommend using a Panasonic card. Slide the release lever in the OPEN LOCK direction of the arrow and open the card/battery door.

  • Page 14: Setting Date/Time (Clock Set)

    Preparation Setting Date/Time (Clock Set) • The clock is not set when the camera is shipped. Turn the camera on. Touch [CLOCK SET]. Touch [e]/[r]/[w]/[q] for each item to set year, month, day, hour, minute, display sequence or time display format, and touch [SET]. 4: Cancel without setting the clock.

  • Page 15: Setting The Menu

    Preparation Setting the Menu This section describes how to select the Normal Picture Mode settings, and the same setting can be used for the [PLAYBACK] menu and [SETUP] menu as well. Example: Setting [AF MODE] from [2] to [3] in the Normal Picture Mode Press [MENU] to display the menu.

  • Page 16: Selecting The [Rec] Mode

    Preparation Selecting the [REC] Mode Intelligent Auto Mode (P17) The subjects are recorded using settings automatically selected by the camera. To select a [REC] Mode from the [REC] Modes list Turn the camera on. A [REC]/[PLAYBACK] selector switch B [MODE] button Slide the [REC]/[PLAYBACK] selector switch to [1].

  • Page 17: Basic

    Basic [REC] Mode: 4 Taking Pictures Using the Automatic Function : Intelligent Auto Mode) The camera will set the most appropriate settings to match the subject and the recording conditions so we recommend this mode for beginners or those who want to leave the settings to the camera and take pictures easily.

  • Page 18: Scene Detection

    Basic Scene Detection When the camera identifi es the optimum scene, the icon of the scene concerned is displayed in blue for 2 seconds, after which its colour changes to the usual red. 3 [i-PORTRAIT] 5 [i-NIGHT PORTRAIT] • Only when [w] is selected 4 [i-SCENERY] 1 [i-NIGHT SCENERY] 2 [i-MACRO]...

  • Page 19: Motion Picture Mode

    Basic [REC] Mode: 6 Motion Picture Mode Slide the [REC]/[PLAYBACK] selector switch to [1], and then press [MODE]. Touch [MOTION PICTURE]. Press the shutter button halfway to focus and then press it fully to start recording. A Audio recording • The available recording time B is displayed on the top right and the elapsed recording time C is displayed on the bottom right of...

  • Page 20: Playing Back Pictures ([Normal Play])

    Basic [PLAYBACK] Mode: 5 Playing Back Pictures ([NORMAL PLAY]) Slide the [REC]/[PLAYBACK] selector switch A to [5]. Forward or rewind the image by dragging the screen horizontally. Forward: drag from left to right Rewind: drag from right to left • To play back motion pictures [6], touch [9]. [PLAYBACK] Mode: 5 Deleting Pictures Once deleted, pictures cannot be recovered.

  • Page 21: Others

    Others Reading the Operating Instructions (PDF format) • You have practised the basic operations introduced in these operating instructions and want to progress to advanced operations. • You want to check the Troubleshooting. In these kinds of situations refer to Operating Instructions (PDF format) recorded on the CD-ROM containing the Operating Instructions (supplied).
  • Page 22 To uninstall the Operating Instructions (PDF format) Delete the PDF fi le from the “Program Files\Panasonic\Lumix\” folder. • When the contents in the Program Files folder cannot be displayed, click the [Show the contents of this folder] to display them.

  • Page 23: Specifi Cations

    Others Specifi cations Digital Camera: Information for your safety Power Source: DC 5.1 V Power Consumption: 1.1 W (When recording) 0.6 W (When playing back) Camera Effective pixels: 14,100,000 pixels Image sensor: 1/2.33˝ CCD Total pixels: 14,500,000 pixels Primary colour fi lter Lens: Optical 8 ×...
  • Page 24 Others Hi-speed burst Burst speed: Approx. 4.6 pictures/second Picture size: 3M (4:3), 2.5M (3:2) or 2M (16:9) is selected as the picture size. Number of recordable pictures: Approx. 15 to 100 Shutter speed: 8 seconds to 1/1,600th of a second [STARRY SKY] mode: 15 seconds, 30 seconds, 60 seconds Exposure (AE):...
  • Page 25 Approx. 140 g (excluding Memory Card and battery) Operating Temperature: 0 °C to 40 °C Operating Humidity: 10% to 80% Battery Charger (Panasonic DE-A60A): Information for your safety Input: 110 V to 240 V 50/60 Hz, 0.2 A Output: 4.2 V 0.65 A (Battery charging)
  • Page 26 VQT2L07 (ENG)
  • Page 27 (ENG) VQT2L07...
  • Page 28 • Microsoft product screen shot(s) reprinted with permission from Microsoft Corporation. • Other names, company names, and product names printed in these instructions are trademarks or registered trademarks of the companies concerned. Web Site: http://panasonic.net VQT2L07 © Panasonic Corporation 2010 H0110HM0...
