Sony Trinitron KV-HR36M90 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

HISTORY
Model Name : KV-HR36M90
SERVICE MANUAL
Part No.
: 9-965-XXX-01
When clicking an item, it's detail is displayed.
Change of
Date
SUPP./CORR.
Description of SUP/COR
main text
2003.09
NEW
–

Advertisement

Table of Contents
loading

Related Manuals for Sony Trinitron KV-HR36M90

Summary of Contents for Sony Trinitron KV-HR36M90

  • Page 1 HISTORY Model Name : KV-HR36M90 SERVICE MANUAL Part No. : 9-965-XXX-01 When clicking an item, it’s detail is displayed. Change of Date SUPP./CORR. Description of SUP/COR main text 2003.09 –...

  • Page 2: Service Manual

    SERVICE MANUAL AX-1 CHASSIS MODEL COMMANDER DEST. CHASSIS NO. MODEL COMMANDER DEST. CHASSIS NO. –––––– –––––––––––– ––––– ––––––––––– –––––– –––––––––––– ––––– ––––––––––– KV-HR36M90 RM-1007 Chinese SCC-M13A-A VIDEO MODE DRC-MF PALETTE V CENTER HD/DVD JUMP PROG OPTION RESET RM-1007 KV-HR36M90 TRINITRON COLOR TV...

  • Page 3: Specifications

    KV-HR36M90 RM-1007 Specifications KV-HR36M90 Power requirements 220–240 V AC, 50/60 Hz Power consumption (W) Indicated on the rear of the TV. Television system B/G, I, D/K, M Color system PAL, PAL 60, SECAM, NTSC4.43, NTSC3.58 Available language for English, Farsi, French Teletext Stereo/Bilingual system NICAM Stereo/Bilingual D/K, I, B/G;...
  • Page 4 THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESECOMPONENTS WITH SONY PARTS WHOSE PART NUM- BERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLE- MENTS PUBLISHED BY SONY. CIRCUIT ADJUSTMENTS THAT ARE CRITICAL TO SAFEOPERATION ARE IDENTIFIED IN THIS MANUAL.

  • Page 5: Table Of Contents

    KV-HR36M90 RM-1007 TABLE OF CONTENTS Section Title Page Section Title Page –––––– –––– –––– –––––– –––– –––– 5. SAFETY RELATED ADJUSTMENTS 1. SELF DIAGNOSIS FUNCTION ........5 5-1. +B MAX VOLTAGE CONFIRMATION ....56 2. DISASSEMBLY 5-2. HV REGULATION CIRCUIT ADJUSTMENT ..56 5-3.

  • Page 6: Self Diagnosis Function

    KV-HR36M90 RM-1007 SECTION 1 SELF DIAGNOSIS FUNCTION Summary of Self-Diagnosis Function • This device includes a self-diagnosis function. • In case of abnormalities, the 1 indicator automatically blinks. It is possible to predict the abnormality location by the number of blinks. The Instruction Manual describes blinking of the 1 indicator. •...
  • Page 7 KV-HR36M90 RM-1007 Blinking count display of 1 indicator < FRONT PANEL > * One blink is not used for self-diagnosis. •EXAMPLE <Diagnosis Items> <Number of Blinks> L(MONO) AUTO PROG PROG MENU • +B overcurrent 2 times • +B overvoltage 3 times •...
  • Page 8 KV-HR36M90 RM-1007 After the self-diagnosis operation • The results display is not automatically cleared. In case of repairs and after repairs, check the self-diagnosis screen and be sure to return the results display to “ 0 ”. • If the results display is not returned to “ 0 ” it will not be possible to judge a new malfunction after completing repairs. <Method of Clearing Results Display>...
  • Page 9 KV-HR36M90 RM-1007 +B OCP If the IC701 Pin 44 (+B OCP DET) is high 2 seconds, turn AC-RELAY low (P-OFF) and make STANDBY LED blinks twice. +B OVP If the IC701 Pin 45 (+B OVP DET) is high 2 seconds, turn AC-RELAY low (P-OFF) and make STANDBY LED blinks three times.

  • Page 10: Disassembly

    KV-HR36M90 RM-1007 SECTION 2 DISASSEMBLY 2-1. REAR COVER ASSEMBLY 2-3. SERVICE POSITION 1 Four screws (+BVTP 4x16) 2 Rear cover assembly Turn the chassis assembly 1 Three screws in the arrow direction, and (+BVTP 4x16) stand it its right side on the bottom.

  • Page 11: Bm And Mg Boards

    KV-HR36M90 RM-1007 2-5. UG BOARD 6 Connectors (CN1501) 1 Screw 7 UG board (+BVTP 3x12) 5 U bracket 4 Power cord 2 Screw (+PSW 3x8) 1 Five screws (+BVTP 3x12) 2-6. BM AND MG BOARDS 1 Screw (+PSW3x8) MG board CN0301 3 BM bracket CN0004...

  • Page 12: D Board

    KV-HR36M90 RM-1007 2-8. D BOARD 2-9. SF BOARD 1 Connectors 1 Connectors CN5012 CN5019 CN3804 CN3803 2 Screw CN3807 (+BVTP 3x12) CN3805 CN3806 CN5003 2 Three screws CN3808 CN5017 CN5010 (+BVTP 3x12) CN6400 CN3809 D board SF board 2-10. H3, H4, H5 AND HMG BOARDS 7 Connectors 4 Connectors CN1001,...

  • Page 13: Harness Arrangement

    KV-HR36M90 RM-1007 2-11. HARNESS ARRANGEMENT CN9001 CN6100 CN6013 CN6101 CN6005 CN6000 CN6006 COIL,NA ROTATION CN0301 CN9009 CN9002 CN9001 CN9104, 9101 CN3806-3809 CN5010 – 12 –...

  • Page 14: Removal Of Anode-Cap

    KV-HR36M90 RM-1007 2-12. REMOVAL OF ANODE-CAP NOTE : After removing the anode, short circuit the anode of the picture tube and the anode cap to the metal chassis, CRT shield or carbon paint on the CRT. • REMOVING PROCEDURES 1 Turn up one side of the rubber cap in the direction indicated by the arrow a. 2 Using a thumb pull up the rubber cap firmly in the direction indicated by the arrow b.

  • Page 15: Crt

    KV-HR36M90 RM-1007 2-13. CRT NOTE: After removing the anode, short circuit the anode of the picture tube and the anode cap to the metal chassis, CRT shield or carbon paint on the CRT. 1 Rear cover assembly 0 DGC holder 5 Chassis assembly 3 Speaker box assembly !¡...

  • Page 16: Service Mode

    KV-HR36M90 RM-1007 SECTION 3 SERVICE MODE 3-1. METHOD OF SETTING THE SERVICE ADJUSTMENT 3-4. ADJUSTING BUTTONS AND INDICATOR MODE SERVICE MODE PROCEDURE VIDEO 1. Standby mode. (Power off) n 5 n (+) n on the Remote Commander. MODE DRC-MF (Press each button within a second.) PALETTE V CENTER 3-2.

  • Page 17: Service Mode List

    KV-HR36M90 RM-1007 3-5.SERVICE MODE LIST LUMA Functionality Range Standards Name BROF GAMM GAMS 0-15 RGAM 0-15 GGAM 0-15 BGAM 0-15 APED DCTR 0-15 ABLM Standards *1 RF / CV / YC / COMP Dynamic CV/YC Name 480_60I 480_60I 576_50I 480_60I 480_60I 576_50I 480_60I...
  • Page 18 KV-HR36M90 RM-1007 COLOR Functionality Range Standards Name CLOF HUOF RDRV 0-63 GDRV 0-63 BDRV 0-63 RCUT 0-63 GCUT 0-63 BCUT 0-63 SBRT 0-63 DCOL WBSW SBOF RDOF 0-63 GDOF 0-63 BDOF 0-63 RCOF 0-63 GCOF 0-63 BCOF 0-63 AXIS R-YR 0-15 R-YB 0-15...
  • Page 19 KV-HR36M90 RM-1007 Standards *2 Name COOL WARM MIDCOOL WBSW SBOF RDOF GDOF BDOF RCOF GCOF BCOF Standards *3 Name AXIS0 AXIS1 AXIS2 AXIS3 R-YR R-YB G-YR G-YB – 18 –...
  • Page 20 KV-HR36M90 RM-1007 CLTY Functionality Range Standards Name SYSM UVML VMCR VMLM VMF0 VMDL 0-15 SHOF SHF0 PROV F1LV LTLV LTMD CTLV MIDE 0-63 VMLV 0-15 Standards *1 Dynamic CV/YC Comp Name 480_60I 480_60I 576_50I 480_60I 480_60I 576_50I 480_60I 576_50I 480_60P 76_50P 720_60P 720_50P...
  • Page 21 KV-HR36M90 RM-1007 Hi-Fine CV/YC Name 480_60I 480_60I 576_50I 480_60I 480_60I 576_50I 480_60I 576_50I 480_60P 576_50P 720_60P 720_50P 1080_60I 1080_50I NTSC NTSC SYSM UVML VMCR VMLM VMF0 VMDL SHOF SHF0 PROV F1LV LTLV LTMD CTLV MIDE Hi-Fine Name Twin 480_60I 576_50I 480_60P 576_50P 720_60P...
  • Page 22 KV-HR36M90 RM-1007 MIDE Functionality Range Standards Name 0-63 MHLY MHLC MVLY MVLC MHYR MHYL MHYE MHYO MHCR MHCL MHCE MHCO MVYR MVYL MVYE MVCR MVCL MVCE Standards *1 Name MHLY MHLC MVLY MVLC MHYR MHYL MHYE MHYO MHCR MHCL MHCE MHCO MVYR MVYL...
  • Page 23 KV-HR36M90 RM-1007 Name MHLY MHLC MVLY MVLC MHYR MHYL MHYE MHYO MHCR MHCL MHCE MHCO MVYR MVYL MVYE MVCR MVCL MVCE – 22 –...
  • Page 24 KV-HR36M90 RM-1007 CCPM Functionality Range Standards Name REFC YLEV 0-255 CLEV 0-255 SHUE 0-15 SHUO YCDL 0-15 FUP2 SHF0 PROV SHPC SSHP 0-15 CBPF CBPA SFIL SSTC AFCG AFLG AFCM AFLC AFHC CDM1 CDM2 CDM3 CLPP 0-63 BGPS 0-15 APED DCTR YTRP CTRP...
  • Page 25 KV-HR36M90 RM-1007 Standards *3 Dynamic CV/YC Name 480_60I 480_60I 576_50I 480_60I 480_60I 576_50I 480_60I 576_50I 480_60P 576_50P 720_60P 720_50P 1080_60I 1080_50I NTSC NTSC FUP2 SHF0 PROV SHPC SSHP Dynamic Twin Name Movie(Hi- 480_60I 576_50I 480_60P 576_50P 720_60P 720_50P 1080_60I 1080_50I Index Full Popup...
  • Page 26 KV-HR36M90 RM-1007 Standards *4 PAL_OTH Name NTSC PAL_DKI NTSC NTSC (GR: OFF) CBPF CBPA Standards *5 Name Comp Digital SFIL SSTC Standards *6 Name CV/YC Other AFLG AFCM AFLC AFHC CDM1 CDM2 CDM3 Standards *7 VIDEO4/O Name VIDEO1 VIDEO2 VIDEO3 ther BGPS Standards *8...
  • Page 27 KV-HR36M90 RM-1007 Hi-Fine ersonal Name 60Hz 50Hz 60Hz 50Hz Other Other Other Other VECR VECL VECN VEGA Standards *15 Name Other BPT1 Only At Auto Color System Mode BPT2 Only At Auto Color System Mode Standards *16 Name YC/Other KLEV APCG –...
  • Page 28 KV-HR36M90 RM-1007 COMB Functionality Standards *1 Range Standards Name NTSC Name 0-31 Standard NonStandard Standard NonStandard TESS No Address 0-31 SCTP SCTP CYBP CYBP Y2BP Y2BP C2LE C2LE DTCN DTCN VEDL VEDL NCDT NCDT 0-15 0-15 0-15 CHED CHED CVED CVED YFLT YFLT...
  • Page 29 KV-HR36M90 RM-1007 YCTM(CXA2163) Functionality Range Standards Name YLEV 0-63 CLEV 0-63 SCON 0-15 SCOL 0-15 YDLY 0-15 SHAP 0-15 SHF0 PREO BPF0 BPFQ FLSW CBOF 0-15 CROF 0-15 SR-Y 0-15 SB-Y 0-15 Standards *1 Name Other SCON SCOL YDLY SHAP YCTS(CXA2163) Functionality Range...
  • Page 30 KV-HR36M90 RM-1007 YCTC(CXA2163) Functionality Range Standards Name SDTS BELS BLF0 SVID SGPP SIDS CDMD AFCG Functionality Range Standards Name TCOF AKBO RGBL YLMT BLKB 0-15 CBOF 0-63 CROF 0-63 SPIC 0-15 SCOL 0-63 SHUE 0-63 ABLT 0-15 Standards *1 A nalog Name Twin RF/CV/YC Comp-480i 480p/576p...
  • Page 31 KV-HR36M90 RM-1007 DEF1 Functionality Range Standards Name VPOS 0-63 VSIZ 0-63 VLIN 0-15 VSCO 0-15 VCEN 0-63 VPIN 0-31 NSCO 0-63 HTPZ 0-31 ZOOM APSW ASPT 0-63 SCRL 0-63 UVLN 0-15 LVLN 0-15 VPSO 0-15 Standards *1 WideZoom Other 3 VSCO Standards *2 Vcomp Other...
  • Page 32 KV-HR36M90 RM-1007 DEF2 Functionality Range Standards Name HCNT 0-63 HPOS 0-63 HSIZ 0-63 SLIN 0-15 MPIN 0-15 0-63 0-63 0-63 PPHA 0-63 VANG 0-63 LANG 0-63 VBOW 0-63 LBOW 0-63 UXCG LXCG UXCP LXCP XCPP PPHO 0-15 PINO -4/+3 UCPO -4/+3 LCPO -4/+3...
  • Page 33 KV-HR36M90 RM-1007 DEF3 Functionality Range Standards Name HBLK LBLK 0-63 RBLK 0-63 VBLK TBLK 0-15 BBLK 0-15 AFCM JUMP VDJP AKBT 0-31 Standards *1 1 LBLK 2 RBLK Standards *2 Zoom Other WideZoom 3 VBLK Standards *3 Full 4:3VComp/Normal 50Hz 60Hz 50Hz 60Hz...
  • Page 34 KV-HR36M90 RM-1007 DEF4 Functionality Range Standards Name QPDC 0-63 QPDV 0-63 QPDP 0-15 QPAM 0-63 QPAV 0-63 QPAP 0-15 COPY Standards *1 Vcomp/Norm Other 0 QPDC 1 QPDV 2 QPDP 3 QPAM 4 QPAV 5 QPAP DEF5 Functionality Range Standards Name EWDC AGCS...
  • Page 35 KV-HR36M90 RM-1007 MID2 Functionality Range Standards Name BCOL 0-15 MSYS Standards *1 Single(N Favorite TWIN Freeze Index ormal) /PAP 0 BCOL MID3 Functionality Range Standards Name MHPH -8/+7 SHPH -8/+7 Standards *1 Comp 50Hz 60Hz 50Hz 60Hz 50Hz 60Hz 480_60I 576_50I 480_60P 576_50P 720_60P 720_50P 1080_60I 1080_50I Other...
  • Page 36 KV-HR36M90 RM-1007 Functionality Range Standards Name NYLP NYPH 0-31 NYLM 0-15 NCLP NCPH 0-31 NCLM 0-15 Standards *1 RNR=OFF Name CV/YC omponent 50Hz 60Hz 50Hz 60Hz 480_60I 576_50I 480_60P 576_50P 720_60P 720_50P 1080_60I 1080_50I NYLP NYPH NYLM NCLP NCPH NCLM RNR=HIGH Name CV/YC...
  • Page 37 KV-HR36M90 RM-1007 Functionality Range Standards Name BLEV Standards *1 BNR:OFF Name RF/CV/YC/Comp/RGB 480_60I 576_50I 480_60P 576_50P 720_60P 720_50P 1080_60I 1080_50I Other BLEV NoiseReducer BnrFormatInputPack 2Byte BNR:HIGH Name RF/CV/YC/Comp/RGB 480_60I 576_50I 480_60P 576_50P 720_60P 720_50P 1080_60I 1080_50I Other BLEV – 36 –...
  • Page 38 KV-HR36M90 RM-1007 SNNR Functionality Range Standards Name MODE SNNR HYST 0-15 WSLT 0-255 SSSN 0-15 F2SN SCSN VGSN YNSN 0-15 CNSN 0-15 PYSN 0-31 LYSN 0-15 PCSN 0-31 LCSN 0-15 7SHP 0-63 7YF1 7LTI 7CTI 7VML 0-15 7VMC MIDD 0-63 CCLV 0-15 CCBP...
  • Page 39 KV-HR36M90 RM-1007 Functionality Range Standards Name COPC COPL TESW ENSW NSSW EWSW LTEU -128/+127 LTEC -128/+127 LTED -128/+127 RTEU -128/+127 RTEC -128/+127 RTED -128/+127 NSTE -128/+127 LENU -128/+127 LENC -128/+127 LEND -128/+127 RENU -128/+127 RENC -128/+127 REND -128/+127 NSEN -128/+127 LNSU -128/+127 LNSC...
  • Page 40 KV-HR36M90 RM-1007 Functionality Range Standards Name SUBV 0-15 BASS 0-15 TREB 0-15 BBEL 0-31 BBEH 0-31 AGCL 0-15 Standards *1 TruSurro Simulated 0 SUBV Standards *2 Personal (BBE:off) ersonal (BBE:Low) Personal (BBE:High) Others Others Others TruSurro TruSurro TruSurro TruSurro TruSurro TruSurro Simulated Simulated...
  • Page 41 KV-HR36M90 RM-1007 MSMO Functionality Range Standards Name MSPF MIXU STD1 LVDS BGLV 0-255 DPAC OSDP Functionality Range Standards Name LEVL 0-15 FFLV 0-15 ASEL Functionality Range Standards Name 0-15 0-15 0-15 VID1 0-15 VID2 0-15 VID3 0-15 VID4 0-15 YUV1 0-15 YUV2 0-15...
  • Page 42 KV-HR36M90 RM-1007 DRCV Functionality Range Standards Name MFVR ISEL ORES 0-255 ONCT 0-255 FMAT FMTH FSEL CDLY LMIT LMLV LMSL VDLY VDPR WPLL CRCT Standards *1 Dynamic tandard Name BS/CV/YC Component BS/CV/YC Component ORES ONCT Hi-Fine ersonal Name BS/CV/YC Component BS/CV/YC Component ORES...
  • Page 43 KV-HR36M90 RM-1007 Functionality Range Standards Function Remarks Name OSD V Position OSD H Position OSD ODD/EVEN Field Window Setup #1 OSD ODD/EVEN Field Window Setup #2 OSD V Position (Offset) Wide/50/60/100/120/HD/Twin/Favorite/Index Standards *1 Functionality FULL50 FULL60 FULL100 FULL120 WDZM50 WDZM60 WDZM100 Name Functionality...
  • Page 44 KV-HR36M90 RM-1007 TEXT Functionality Range Standards unction Remarks Name Teletext Horizontal Display Position Teletext Vertical Display Position Teletext H-sync Active Edge Shift Teletext V-sync Active Edge Shift Teletext H-sync Polarity Configuration Teletext V-sync Polarity Configuration Teletext Field Polarity Configuration Teletext Fastext/TOP Force Mode Teletext RGB Brightness Teletext National Option Table Configuration Teletext Twisted Character Set Configuration...
  • Page 45 KV-HR36M90 RM-1007 Functionality Range Standards Function Remarks Name CLAR User DRC Palette Initial number Clarity REAL User DRC Palette Initial Number Reality Standards *1 Functionality DRC Palette (TV Custom1) DRC Palette (TV Custom2) DRC Palette (TV Custom3) DRC Palette (Video Custom1) DRC Palette (Video Custom2) Name Dynamic...
  • Page 46 KV-HR36M90 RM-1007 Functionality Range Standards Function emarks Name APC Switch TV System Selection under searching with Auto TV System Auto FM switch Disable Blueback function Speed CH Search Selection CH Selection for Shipping Condition NTSC Only NTSC Only Cable/Air Selection for Shipping Condition Disable Menu-operation Guide Enable Noise Reduction in Video Mode Lower Blue Back Intensity...
  • Page 47 KV-HR36M90 RM-1007 Functionality Range Standards Function Remarks Name Optional Bits 0 Optional Bits 1 Optional Bits 2 Optional Bits 3 Optional Bits 4 Functionality Range Standards Function Remarks Name Service Command – 46 –...

  • Page 48: Set-Up Adjustments

    KV-HR36M90 RM-1007 SECTION 4 SET-UP ADJUSTMENTS • The following adjustments should be made when a complete Perform the adjustments in the following order : realignment is required or a new picture tube is installed. 1. Beam Landing • These adjustments should be performed with rated power 2.

  • Page 49: Convergence Adjustment

    KV-HR36M90 RM-1007 4-3. CONVERGENCE ADJUSTMENT Preparation : • Before starting this adjustment, adjust the focus, horizontal size and vertical size. • Set the Picture Mode to “STANDARD”. • Cross hatch / Dot pattern. 4-3-1. Horizontal and Vertical Static Convergence Fig. 4-2 Center dot Blue V.
  • Page 50 KV-HR36M90 RM-1007 4 BMC (Hexapole) Magnet. V . STAT If the red, green and blue dots are not balanced or aligned, then use the BMC magnet to adjust in the manner described below. H. STAT VR 5 Y separation axis correction magnet adjustment. 1.

  • Page 51: G2 (Screen) Adjustment

    KV-HR36M90 RM-1007 4-3-2. Dynamic Convergence Adjustment 4-4. G2 (SCREEN) ADJUSTMENT Preparation: 1. G2 (SCREEN) ADJUSTMENT • Before starting this adjustment, adjust the horizontal static 1) Set to zoom mode and the PICTURE and BRIGHTNESS to convergence and the vertical static convergence normal and to the service mode.

  • Page 52: Neck Assy Twist Adjustment

    KV-HR36M90 RM-1007 4-6. NECK ASSY TWIST ADJUSTMENT 4-7. SFC COARSE ADJUSTMENT (1) Receive dot/hatch pattern. Summary: (2) Turn FOCUS VR fully counter-clockwise. Move the marker to the position as shown in the figure and (3) Confirm the dot shape at the screen center. (Fig. 4-5) adjust the convergence or the landing at its position.
  • Page 53 KV-HR36M90 RM-1007 4-7-1. Landing Adjustment Ityems 2, 3 In case of no lack of uniformity, it is no need to adjust. 1. Set to the service mode. 2. Select the category “LAND”. The cross hatch and the marker appear on the screen Ityem 4-2) 3.

  • Page 54: Sfc Fine Adjustment

    KV-HR36M90 RM-1007 4-7-2. Convergence Adjustment The adjusting ranges according to its position selected. It is adjustable from the selected point to the center. Left: Left to center Upper: Upper to center Upper left: Upper left to center In case of 1 step inner from each edges: Marker position to center, it cannot be adjusting on the outside of the marker.

  • Page 55: P&P Sub Contrast Adjustment (Video)

    KV-HR36M90 RM-1007 4-8-2. Convergence 4-10. P & P SUB-HUE AND SUB-COLOR ADJUSTMENT (VIDEO) (NTSC/PAL) Fine mode 1. Receive the signal. Adjustable at each point. TV terminal (sub) : Color-bar (white-75%, No setup) VIDEO terminal (main) : Color-bar (white-75%, No setup) 2.

  • Page 56: White Balance Adjustment

    KV-HR36M90 RM-1007 4-11. WHITE BALANCE ADJUSTMENT 4-13. PICTURE DISTORTION ADJUSTMENT Note: In this adjustment use the monoscope signal. (1).VIDEO MODE : AV PRO Adjust in the service mode “DEF1” and “DEF2”. PICTURE : Maximum COLOR : Minimum 0 (VPOS)-DEF1 1 (VSIZ)-DEF1 Color Temp.: High DRC-MF : Progressive...

  • Page 57: Safety Related Adjustments

    KV-HR36M90 RM-1007 SECTION 5 SAFETY RELATED ADJUSTMENTS [ D BOARD] 5-4. IK PROTECTOR CIRCUIT CHECK (D BOARD) 5-1. +B MAX VOLTAGE CONFIRMATION When replacing the following components marked with / on the schematic diagram, always check IK protector circuit. 1. Supply 242 ± VAC to variable autotransformer. D8004 2.

  • Page 58: Diagrams

    KV-HR36M90 RM-1007 SECTION 6 DIAGRAMS 6-1. BLOCK DIAGRAM (1) – 58 – – 57 –...
  • Page 59 KV-HR36M90 RM-1007 BLOCK DIAGRAM (2) TO D BOARD TO D BOARD TO MG BOARD TO BM BOARD TO MG BOARD CN5004 CN5005 CN0001 CN3001 CN0002 CN2015(2/2) :B TO B VIDEO MT_CV MT_VIDEO M_SDAT M_SDAT M_SCLK M_SCLK ST_CV ST_VIDEO AUDIO L/R L_MUTE L_MUTE ST L...

  • Page 60: Block Diagram (2)

    KV-HR36M90 RM-1007 BLOCK DIAGRAM (3) CN6006 AC IN AC IN CN6000 CN6000 TO H4 BOARD RECT + RECT + CN1054 CN6005 RECT RECT AC OUT D6508 AC OUT STBY 7V CN2015(1/2) CN5019 TO H4 BOARD IC6100 D6005 MAIN 9V 135V 135V D6113 5V REG...

  • Page 61: Block Diagram (3)

    KV-HR36M90 RM-1007 BLOCK DIAGRAM (4) IC8002 T8001 DRIVE Q8014 TO CRT(V901) IC8004 CONVERTER BUFFER L8002 Q8011 Q8021 Q8028 Q8034 Q8035 HV PROT SOFT START D8015 Q8013 CONVERTER BS9V TO C BOARD PH8003 Q5600 CN9009 B HV FEED BACK DF OUT +15V D8022 VSENSE...

  • Page 62: Block Diagram (4)

    KV-HR36M90 RM-1007 BLOCK DIAGRAM (5) IC3105 +2.5V REG. Q3113 Q3109 BIAS BIAS IC3101 CN3001 IC3104 AD CONV. PINT OP AMP. MS3.3V_DET Q3112 Q3101 ,Q3102 FF SW BUFFER IC3201 IC3301 IC3303 FFSW FL3101 CN3401 LINE W -128 VIDEO DRC MF L.P.F DRC_LW VIDEO AIN1...

  • Page 63: Block Diagram (5)

    KV-HR36M90 RM-1007 BLOCK DIAGRAM (6) IC4000 IC4100 CN4000 ACDET VVS_OUT VCLK IC4200 VCK_OUT SDRAM MS_SCLK RESER_VED VHS_OUT ,A11 4,6,7 ,126 (A4,A6,A7,A10,A11) SDRAM1 -UY7 10,11 ,133 -A12 -76,78 ,B10 B5-B10 ,150 27-32 VUV0 -VUV7 VUV0 -B12 C9,C10 C6-C11 -159 50-55 SDRAM2 MSAU_L_OUT -168 MSAU_R_OUT...

  • Page 64: Block Diagram (6)

    KV-HR36M90 RM-1007 BLOCK DIAGRAM (7) IC3807 IC3802 LCC OUT CN3809 LCLT CN1054 LCLT LCC COIL LCRT D3805 D3806 LCRT S1051 TO A BOARD CN3808 CN6006 Q3802 CN1055 LCLT BUFF CN3803 LCLT LCC COIL IK_MIX LCRT PF_SDAT LCRT TO A BOARD PF_SCLK CN6005 TO MG BOARD...

  • Page 65: Block Diagram (7)

    KV-HR36M90 RM-1007 BLOCK DIAGRAM (8) – 71 – – 72 –...

  • Page 66: Block Diagram (9)

    KV-HR36M90 RM-1007 BLOCK DIAGRAM (9) VIDEO OUT CN9001 Q9003 Q9009 IC9001 Q9007 R OUT IK BUFFER Q9004 Q9010 IC9002 G OUT Q9015 TO D(2/2)BOARD IK BUFFER T8001 CN9009 Q9005 Q9011 IC9003 B OUT Q9015 TO MG BOARD CN0401 IK BUFFER TO D BOARD Q9001 BUFFER...

  • Page 67: Block Diagram (11)

    KV-HR36M90 RM-1007 BLOCK DIAGRAM (10) (1/2) V_PIN + V_PIN – (2/2) V_PIN V_SIN (2/2) D9108 D9107 (1/2) IC9103 (1/2) PWM OUT DQP AMP IC9102 (2/2) IC9101 (2/2) BUFFER PWM OUT (1/2) – 74 –...

  • Page 68: Block Diagram (11)

    KV-HR36M90 RM-1007 BLOCK DIAGRAM (11) J9301 CN9302 R IN L IN -SSW IN -S1 IN Y IN 4 IN C IN TO UJ BOARD V IN CN1501 (MONO) CN9303 J9302 HP SW HP L HP R TO MG BOARD CN0301 FRONT VIDEO INPUT HEADPHONE JACK IC7201...
  • Page 69 KV-HR36M90 RM-1007 MEMO – 76 –...

  • Page 70: Circuit Boards Location

    KV-HR36M90 RM-1007 6-2. CIRCUIT BOARDS LOCATION Terminal name of semiconductors in silk screen printed circuit ( Note: The symbol display is on the component slde. Device Printed symbol Terminal name Circuit Collector Transistor The components identified by shading and mark Base Emitter are critical for safety.
  • Page 71 KV-HR36M90 RM-1007 CN6009 CN6102 CN6012 CN6011 CN6010 CN6015 CN6100 CN6101 :MINI FOR CHECK :MINI(LOCK) :MINI(LOCK) CN6000 H µ L6002 C6125 C6126 TO D(3/3)BOARD RECT+ T6101 D6113 R6120 KBP153G CN6400 AC TRANSFORMER RECT- 1/10W C6127 R6117 JW6006 ST7V JW6035 :CHIP 10MM C6013 STBY 7V C6002...
  • Page 72 KV-HR36M90 RM-1007 CN2019 TU2000 TU2001 BTF-WG442 BTF-LG434 MAIN TU SUB-TU R2085 R2102 R2101 IC2002 R2115 R2066 S80843CLUA- C2091 1/10W 1364T2G C2092 C2090 :CHIP RESET R2057 R2084 R2114 470p 1 2 3 B:1608 R2099 C2076 C2077 :CHIP R2108 C2089 1/10W :CHIP C2029 R2063 6.3V...
  • Page 73 KV-HR36M90 RM-1007 TO D(3/3)BOARD TO D(3/3)BOARD TO MJ(1/3)BOARD TO BM(1/4)BOARD TO MJ(1/3)BOARD CN5004 CN5005 CN101 CN3001 CN102 3.53.43.73.7 4.2 3.9 2.12.72.50.9 5 0.1 0 3.5 3.73.7 3.9 1.3 0.2 0.3 0 4.5 4.4 3.43.4 1.70.9 0.40.2 0.20.8 2.7 2.9 3.4 1 JW2002 CN2015 :B TO B...
  • Page 74 KV-HR36M90 RM-1007 CN3402 TO HMJ BOARD CN201 9V-1 R3023 :1608 9V-2 C3032 CN3001 R3481 R3482 :1608 :1608 :1608 F:1608 TO A(3/3)BOARD CN2004 C3036 C3035 FL3000 C3039 CKD510JB1A105ST F:1608 :AL-CP F:1608 MAIN_9V C3412 FB3401 0.01 FB3402 BLM11A121PT BLM11A121PT B:1608 3.3V 3.3V FL3003 FL3401 CKD510JB1A105ST...
  • Page 75 KV-HR36M90 RM-1007 C3186 100p CH:CHIP L3101 C3100 H µ 1000p RB3101 :CHIP B:1608 10k*4 FB3101 BK2125HM601 C3101 1000p R3187 R3191 B:1608 C3102 R3101 R3181 R3182 47 1/10W :CHIP :AL-CP RB3114 RB3115 RB3116 RB3117 10k*4 10k*4 10k*4 10k*4 1/10W 1/10W :CHIP :CHIP R3102 X3101...
  • Page 76 KV-HR36M90 RM-1007 TO(2/4)(4/4) MAIN_CCP RB3201 RB3202 47*4 47*4 L3205 3.3V C3201 H µ 0.01 3.3V :CHIP B:1608 IC3202 FL3201 MSM56V16160F-8T C3202 C3203 CKD510JB1A105ST 16M-SDRAM 0.01 6.3V B:1608 :AL-CP 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 C3205 0.01 C3204...
  • Page 77 KV-HR36M90 RM-1007 IC3310 PQ70XZ01ZP C3304 Q3301 R3302 R3303 2.5V REG 0.01 FL3304 MSD601 1/10W C3354 CKD510JB1A105ST 3.3V 1/10W 1 2 3 4 5 C3392 BUFF B:1608 Y_CL L3317 FL3306 :CHIP :CHIP 0.01 C3305 3.3V 0.01 H µ C3308 CKD510JB1A105ST C3398 C3306 Y_CL B:1608...
  • Page 78 KV-HR36M90 RM-1007 – 93 – – 94 –...
  • Page 79 KV-HR36M90 RM-1007 – 95 – – 96 –...
  • Page 80 KV-HR36M90 RM-1007 – 97 – – 98 –...
  • Page 81 KV-HR36M90 RM-1007 (P2-9I) – 99 – – 100 –...
  • Page 82 KV-HR36M90 RM-1007 – 101 – – 102 –...
  • Page 83 KV-HR36M90 RM-1007 – 103 – – 104 –...
  • Page 84 KV-HR36M90 RM-1007 – 106 – – 105 –...
  • Page 85 KV-HR36M90 RM-1007 – 107 – – 108 –...
  • Page 86 KV-HR36M90 RM-1007 – 109 – – 110 –...
  • Page 87 KV-HR36M90 RM-1007 3.3V FB4000 BK1608TS601 C4011 3.3V R4012 F:CHIP R4013 4.7k 4.7k R4016 :CHIP TO(2/3)(3/3) :CHIP 22 :CHIP R4062 Q4003 TO(2/3)(3/3) DTA144EE-TL TO(3/3) CLK66M_RE 1/16W BUS CTL R4017 MUTE :CHIP R4079 C4032 R4015 Q4004 R4063 1/16W 2SC4617TL-QR IC4001 6.3V :CHIP :CHIP TO(2/3)(3/3) 1/16W...
  • Page 88 KV-HR36M90 RM-1007 1.8V FB4100 BK1608TS601 MS2(2/3) C4125 C4128 F:CHIP F:CHIP TO(1/3)(3/3) TO(1/3)(3/3) 1.8V (CPU) BUS CTL FB4101 BLM21P331SG C4126 C4129 SDRAM-6 3.3V F:CHIP F:CHIP TO(3/3) 3.3V SDRAM-7 FB4102 3.3V WDT ENB BK1608TS601 TO(1/3) R4125 VDD3.3V C4127 C4130 :CHIP VDD1.8V TO(1/3)(3/3) VDD1.8V-2 F:CHIP F:CHIP...
  • Page 89 KV-HR36M90 RM-1007 3.3V 3.3V TO(1/3)(2/3) L4200 FB4202 µ BK1608TS601 IC4201 MS_SEL CY27027ZCT R4205 C4200 :CHIP TO(1/3) AUDCLK CLK12M TO(1/3) R4206 F:CHIP C4220 MSSEL R4204 JL4204 VD CTL R4200 :CHIP IC4203 ASICCLK CLK66M_RE JL4200 F:CHIP C4221 :CHIP MBM29LV160BE- CLK54M VIDCLK CPUCLK CLK66M_RO TO(2/3) 3.3V...
  • Page 90 KV-HR36M90 RM-1007 (LANDING) – 117 – – 118 –...
  • Page 91 KV-HR36M90 RM-1007 – 119 – – 120 –...
  • Page 92 KV-HR36M90 RM-1007 – 122 – – 121 –...
  • Page 93 KV-HR36M90 RM-1007 – 124 – – 123 –...
  • Page 94 KV-HR36M90 RM-1007 6-4. PRINTED WIRING BOARDS [ POWER SUPPLY, TUNER, AUDIO OUTPUT, RELAY BOARD ] • A BOARD SEMICONDUCTOR LOCATION DIODE IC2000 IC2001 D2001 IC2002 D2004 IC6100 D2005 IC6200 D6000 IC6201 D6005 IC6202 D6108 C-10 IC6203 D6109 C-10 D6110 B-10 TRANSISTOR D6112 D6113...
  • Page 95 KV-HR36M90 RM-1007 [ LVDS, DRC-MF, A/D CONVERTER, MID ] < Component side > < Conductor side > • BM BOARD SEMICONDUCTOR LOCATION Q3110 Q3111 COMPONENT CONDUCTOR Q3112 SIDE SIDE Q3113 IC3101 Q3201 IC3102 Q3202 IC3103 Q3203 IC3104 Q3204 IC3105 Q3301 IC3106 Q3302 IC3201...
  • Page 96 KV-HR36M90 RM-1007 [ RGB DRIVE ] – 129 – – 130 –...
  • Page 97 KV-HR36M90 RM-1007 • D BOARD SEMICONDUCTOR LOCATION Q5402 D5201 D6510 DIODE Q5403 D5202 D6511 Q5404 D5203 D6601 IC3101 Q5405 D5204 D6602 IC5101 Q5406 G-10 D5205 G-10 D6604 IC5201 Q5522 D5206 D6607 IC5401 Q5600 D5207 D6608 IC5402 Q5602 C-10 D5209 D6800 IC5403 G-10 Q5604...
  • Page 98 KV-HR36M90 RM-1007 [ H OUT/V OUT, HV REG, POWER SUPPLY ] – 133 – – 134 –...
  • Page 99 KV-HR36M90 RM-1007 [ MEMORY STICK INTERFACE ] [ CONTROL SWITCHES ] < Comporent side > < Conductor side > – 135 – – 136 –...
  • Page 100 KV-HR36M90 RM-1007 [ POWER SWITCH, REMOTE CONTROL SENSOR, INDICATORS ] [ VIDEO 4 IN, PHONES ] < Comporent side > < Conductor side > – 137 – – 138 –...
  • Page 101 KV-HR36M90 RM-1007 [ MASTER/RF MICRO, AUDIO PROCESSOR, COMPONENNT-I/F ] < Component side > • MG BOARD SEMICONDUCTOR LOCATION IC0008 Q0016 Q0054 Q0067 Q0415 Q0424 TRANSISTOR Q0306 IC0050 Q0416 Q0425 Q0020 Q0056 Q0068 Q0401 COMPONENT CONDUCTOR COMPONENT CONDUCTOR SIDE SIDE IC0051 Q0021 Q0057 Q0069...
  • Page 102 KV-HR36M90 RM-1007 < Conductor side > D0008 D0056 D0406 Q0434 DIODE D0009 D0057 D0407 Q0435 COMPONENT CONDUCTOR D0010 D0058 D0501 SIDE SIDE Q0436 D0052 D0059 D0502 Q0437 D0001 D0053 D0403 Q0438 D0002 D0054 D0404 Q0439 D0003 D0055 D0405 Q0440 D0007 –...
  • Page 103 KV-HR36M90 RM-1007 [ MEMORY STICK INTERFACE, UPU, RAM ] < Conductor side > < Component side > • MS2 BOARD SEMICONDUCTOR LOCATION Q4005 IC4203 Q4006 IC4204 COMPONENT CONDUCTOR Q4007 IC4205 SIDE SIDE IC4000 IC4206 DIODE IC4207 IC4001 COMPONENT CONDUCTOR SIDE SIDE IC4002 TRANSISTOR...
  • Page 104 KV-HR36M90 RM-1007 [ LANDING ] < Comporent side > – 145 – – 146 –...
  • Page 105 KV-HR36M90 RM-1007 < Conductor side > – 147 – – 148 –...
  • Page 106 KV-HR36M90 RM-1007 [ REAR INPUT/OUTPUT, SUB COMB FILTER ] < Component side > • UG BOARD SEMICONDUCTOR LOCATION Q1801 Q1802 COMPONENT CONDUCTOR Q1803 SIDE SIDE IC1501 DIODE IC1502 COMPONENT CONDUCTOR SIDE SIDE IC1701 D1501 IC1703 D1502 IC1801 D1503 IC1802 D1507 TRANSISTOR D1508 COMPONENT CONDUCTOR...
  • Page 107 KV-HR36M90 RM-1007 < Conductor side > – 151 – – 152 –...
  • Page 108 KV-HR36M90 RM-1007 [ VM ] – 153 –...
  • Page 109 KV-HR36M90 RM-1007 6-5. WAVEFORMS •A (2/3) BOARD WAVEFORMS 0.6Vp-p ( H ) 2.5Vp-p ( H ) •A (3/3) BOARD WAVEFORMS 0.5Vp-p ( H ) 0.5Vp-p ( H ) 0.6Vp-p ( H ) 1.5Vp-p ( H ) 1.5Vp-p ( H ) 5.8Vp-p ( H ) 2.1Vp-p ( H ) 0.64Vp-p ( V )

  • Page 110: Semiconductors

    KV-HR36M90 RM-1007 6-6. SEMICONDUCTORS AK4352VT-E2 LA6510 SN74CBTLV1G125DCKR 2SA1208S-TP DTC144ESA TC7SET02FU(TE85R) 2SC2362K-G TC7SET08FU(TE85L) LETTER SIDE TOP VIEW 16pin 5pin BA18BC0FP UPC29M05T-E2 MM1096AFF STK391-120 MN24C02-WMN6T(A) NJM2903M NJM2903M-TE2 2SA1776TV2Q HN1B01FU-TE85R NJM2904M NJM2904M-TE2 NJM4558E(TE2) NJM4558M-TE2 NJM4560M-TE2 TC7W04FU-TE12R MARKING SIDE VIEW BA9759F-E2 TC7W66FU(TE12R) STV9379A MARKING SIDE VIEW TC7WH74FK 18pin IRF614-005...
  • Page 111 KV-HR36M90 RM-1007 D1NL40-TA2 F10P04Q YG911S2R D4SBL20MF3 D4SBS6 CATHODE – ANODE – FMQ-G5FMS D1NS4 D2L20U MTZJ-T-77-15B RB441Q-40T77 RD10ESB2 RD15ES-B1 CATHODE RD3.0ES-B2 RD3.3ES-B2 ANODE RD5.1ES-B1 RD5.1ESB2 HN1D03FU CATHODE ANODE D5LC20U-4012 MARKING SIDE VIEW KBP153G-A2 – ANODE CATHODE MM3Z15VT1 MM3Z27VT1 DAN202K MM3Z3V0T1 DAN202K-T-146 MM3Z3V9ST1 MM3Z4V7ST1 MM3Z9V1ST1...

  • Page 112: Exploded Views

    KV-HR36M90 RM-1007 SECTION 7 EXPLODED VIEWS NOTE: • Items with no part number and no • Items marked " " are not stocked since description are not stocked because they they are seldom required for routine The components identified by shading and are seldom required for routine service service.

  • Page 113: Super Woofer Block

    KV-HR36M90 RM-1007 7-2. SUPER WOOFER BLOCK REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * X-4041-794-1 SP JOINT ASSY 1-825-576-11 LOUDSPEAKER (16cm) 4-374-745-11 CUSHION (A) * 4-087-460-01 3D BOX, TOP 4-058-870-01 SCREW, (4X16) W (+) P TAPPING * 4-087-461-01 3D BOX, BOTTOM 4-064-929-02...

  • Page 114: Crt Section

    KV-HR36M90 RM-1007 7-3. CRT SECTION The components identified by shading and mark are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK 4-095-583-02 SUPPORTER, CRT (36) 108 * A-1405-955-A C BOARD, COMPLETE 102 0 1-456-529-11 COIL, LANDING CORRECTION 109 * A-1405-956-A W BOARD, COMPLETE...

  • Page 115: Bezel Section

    KV-HR36M90 RM-1007 7-4. BEZEL SECTION REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK X-4041-796-1 CABINET ASSY 4-093-613-01 PANEL, MS 4-042-593-01 SPRING, COMPRESSION 4-302-404-03 SCREW (WASHER HEAD) (+P 4X16) 1-825-575-11 LOUDSPEAKER (5cm) 4-099-850-01 BUTTON, POWER 154 * 4-095-581-01 BOARD, BOTTOM (36) 156 * 4-087-798-01 BRACKET, SPEAKER...

  • Page 116: Electrical Parts List

    KV-HR36M90 RM-1007 SECTION 8 ELECTRICAL PARTS LIST • The components identified by in this manual • CAPACITORS have been carefully factory-selected for each set PF : µµ F The components identified by shading and in order to satisfy regulations regarding X-ray mark are critial for safety.
  • Page 117 KV-HR36M90 The components identified by shading and mark are criti- RM-1007 cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– C6007 1-161-964-91 CERAMIC 0.0047µF 250V...
  • Page 118 KV-HR36M90 The components identified by shading and mark are criti- RM-1007 cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– IC6201 8-759-474-09 IC SI-8050S-LF1101 JR6507 1-216-864-11 SHORT CHIP IC6202 8-759-659-28 IC SI-8033S...
  • Page 119 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– < RESISTOR > R2081 1-216-809-11 METAL CHIP 1/10W R2082 1-216-857-11 METAL CHIP 1/10W R2000 1-216-855-11 METAL CHIP 680K 1/10W R2083 1-216-847-11 METAL CHIP 150K...
  • Page 120 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– R6230 1-216-833-11 METAL CHIP 1/10W R6231 1-216-821-11 METAL CHIP 1/10W C3124 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V R6232 1-249-377-11 CARBON 0.47 1/4W C3125 1-162-970-11 CERAMIC CHIP...
  • Page 121 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– C3201 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V C3202 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V C3322 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V C3203 1-126-206-11 ELECT CHIP...
  • Page 122 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– C3395 1-124-779-00 ELECT CHIP 10µF 20% 16V FL3201 1-234-177-21 FERRITE 0µH C3396 1-124-779-00 ELECT CHIP 10µF 20% 16V FL3301 1-781-923-21 FILTER, LOW PASS (SMD) FL3302 1-234-177-21 FERRITE 0µH...
  • Page 123 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– L3402 1-419-370-21 INDUCTOR 0µH R3049 1-543-949-22 FERRITE 0µH L3403 1-419-370-21 INDUCTOR 0µH R3050 1-543-949-22 FERRITE 0µH L3404 1-419-370-21 INDUCTOR 0µH R3051 1-543-949-22 FERRITE 0µH...
  • Page 124 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– R3281 1-218-847-11 METAL CHIP 0.5% 1/10W R3162 1-216-864-11 SHORT CHIP R3282 1-218-873-11 METAL CHIP 0.5% 1/10W R3163 1-218-851-11 METAL CHIP 1.5K 0.5% 1/10W R3302 1-216-801-11 METAL CHIP...
  • Page 125 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– R3466 1-218-833-11 METAL CHIP 0.5% 1/10W R3385 1-211-985-11 METAL CHIP 0.5% 1/10W R3467 1-218-833-11 METAL CHIP 0.5% 1/10W R3386 1-211-987-11 METAL CHIP 0.5% 1/10W R3387 1-211-985-11 METAL CHIP...
  • Page 126 KV-HR36M90 The components identified by shading and mark are criti- RM-1007 cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– RB3404 1-233-575-11 RES, CHIP NETWORK IC9001 8-759-680-01 IC TDA6120Q/N2/S1 IC9002 8-759-680-01 IC TDA6120Q/N2/S1...
  • Page 127 The components identified by KV-HR36M90 shading and mark are criti- RM-1007 cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– R9039 1-216-025-11 RES-CHIP 1/10W C5203 1-126-964-11 ELECT...
  • Page 128 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– C8046 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V C6409 1-126-947-11 ELECT 47µF 20% 25V C8048 1-130-495-00 MYLAR 0.1µF C6411 1-100-613-81 CERAMIC 470pF C8063 1-135-945-22 FILM 10000pF...
  • Page 129 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– IC5652 8-759-981-61 IC NJM2901M D6504 8-719-510-13 DIODE D10SC4MR IC6400 6-703-355-01 IC MCZ3001DA D6508 8-719-062-40 DIODE D4SBL20µF3 IC6501 8-759-518-68 IC PQ12RF21 D6509 8-719-052-90 DIODE D1NL40-TA2 D6510 8-719-052-37 DIODE F10P04Q IC6503 6-704-264-01 IC EK1135...
  • Page 130 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– L6504 1-412-525-31 INDUCTOR 10µH < RESISTOR > L6505 1-406-668-21 INDUCTOR 330µH L6505 1-406-668-61 INDUCTOR 330µH R5001 1-243-602-21 METAL OXIDE R5002 1-243-602-21 METAL OXIDE L6508 1-412-525-31 INDUCTOR 10µH...
  • Page 131 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– R5247 1-216-829-11 METAL CHIP 4.7K 1/10W R5635 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R5249 1-216-837-11 METAL CHIP 1/10W R5636 1-249-377-11 CARBON 0.47 1/4W...
  • Page 132 • The components identified by in this manual have The components identified by KV-HR36M90 been carefully factory-selected for each set in order to shading and mark are criti- RM-1007 satisfy regulations regarding X-ray radiation. Should cal for safety. replacement be required, replace only with the value Replace only with part number specified.
  • Page 133 KV-HR36M90 The components identified by shading and mark are criti- RM-1007 cal for safety. H3 H4 Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– –––––––––––––...
  • Page 134 KV-HR36M90 RM-1007 HMG MG REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– D9302 8-719-977-28 DIODE DTZ10B D9303 8-719-977-28 DIODE DTZ10B D7206 8-719-024-77 DIODE HN1D03FU-TE85R D9304 8-719-977-28 DIODE DTZ10B D7207 6-500-182-01 DIODE L1503CB/ID D7208 8-719-024-77 DIODE HN1D03FU-TE85R D7209 8-719-024-77 DIODE HN1D03FU-TE85R...
  • Page 135 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– C0028 1-162-919-11 CERAMIC CHIP 22pF C0319 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V C0029 1-162-910-11 CERAMIC CHIP 0.25pF 50V C0320 1-136-165-00 FILM 0.1µF C0321 1-136-165-00 FILM...
  • Page 136 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– C0438 1-164-156-11 CERAMIC CHIP 0.1µF D0406 8-719-081-97 DIODE MMDL914T1 D0407 8-719-081-97 DIODE MMDL914T1 C0439 1-164-156-11 CERAMIC CHIP 0.1µF C0441 1-126-933-11 ELECT 100µF 20% 16V...
  • Page 137 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– JR1024 1-216-864-11 SHORT CHIP JR1025 1-216-864-11 SHORT CHIP Q0408 8-729-010-25 TRANSISTOR MSD601-RT1 Q0409 8-729-122-63 TRANSISTOR 2SA1226 JR1026 1-216-864-11 SHORT CHIP Q0415 8-729-010-05 TRANSISTOR MSB709-RT1 JR1027 1-216-864-11 SHORT CHIP Q0416 8-729-010-05 TRANSISTOR MSB709-RT1...
  • Page 138 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– R0147 1-216-797-11 METAL CHIP 1/10W R0059 1-216-809-11 METAL CHIP 1/10W R0148 1-216-809-11 METAL CHIP 1/10W R0061 1-216-833-11 METAL CHIP 1/10W R0149 1-216-809-11 METAL CHIP 1/10W...
  • Page 139 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– R0432 1-216-821-11 METAL CHIP 1/10W R0250 1-216-853-11 METAL CHIP 470K 1/10W R0433 1-216-809-11 METAL CHIP 1/10W R0301 1-216-834-11 METAL CHIP 1/10W R0434 1-216-809-11 METAL CHIP 1/10W...
  • Page 140 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– C4017 1-107-820-11 CERAMIC CHIP 0.1µF R0513 1-216-809-11 METAL CHIP 1/10W C4018 1-107-820-11 CERAMIC CHIP 0.1µF R0514 1-216-845-11 METAL CHIP 100K 1/10W R0515 1-216-845-11 METAL CHIP...
  • Page 141 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– C4209 1-107-820-11 CERAMIC CHIP 0.1µF C4210 1-107-820-11 CERAMIC CHIP 0.1µF < TRANSISTOR > C4211 1-107-820-11 CERAMIC CHIP 0.1µF C4212 1-119-667-11 CERAMIC CHIP 22µF Q4001 8-729-013-28 TRANSISTOR HN1B01FU-TE85R...
  • Page 142 KV-HR36M90 RM-1007 MS2 SF REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– R4057 1-218-933-11 RES-CHIP 1/16W RB4014 1-234-370-21 RES, NETWORK 22X4 (1005) R4058 1-208-707-11 METAL CHIP 0.5% 1/16W R4059 1-219-598-11 METAL CHIP 0.5% 1/16W RB4015 1-234-370-21 RES, NETWORK 22X4 (1005)
  • Page 143 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– C3829 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V C3830 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V < IC > C3831 1-126-935-11 ELECT 470µF 20% 10V C3832 1-107-826-11 CERAMIC CHIP...
  • Page 144 KV-HR36M90 RM-1007 SF UG REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– R3867 1-216-829-11 METAL CHIP 4.7K 1/10W A-1302-463-A UG BOARD, COMPLETE ******************** R3868 1-216-829-11 METAL CHIP 4.7K 1/10W R3869 1-218-878-11 METAL CHIP 0.5% 1/10W...
  • Page 145 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– C1579 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V C1811 1-126-935-11 ELECT 470µF 20% 10V C1580 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V C1812 1-126-947-11 ELECT 47µF...
  • Page 146 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– Q1504 8-729-010-05 TRANSISTOR MSB709-RT1 < FERRITE BEAD > Q1505 8-729-010-05 TRANSISTOR MSB709-RT1 FB1701 1-469-179-21 FERRITE 0µH Q1506 8-729-010-05 TRANSISTOR MSB709-RT1 FB1702 1-469-179-21 FERRITE 0µH Q1507 8-729-010-05 TRANSISTOR MSB709-RT1...
  • Page 147 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– R1538 1-216-808-11 METAL CHIP 1/10W R1606 1-216-821-11 METAL CHIP 1/10W R1539 1-216-845-11 METAL CHIP 100K 1/10W R1607 1-216-821-11 METAL CHIP 1/10W R1540 1-216-845-11 METAL CHIP 100K...
  • Page 148 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– R1725 1-216-809-11 METAL CHIP 1/10W R1726 1-216-809-11 METAL CHIP 1/10W A-1405-956-A W BOARD, COMPLETE ******************* R1730 1-216-817-11 METAL CHIP 1/10W R1736 1-216-817-11 METAL CHIP 1/10W...
  • Page 149 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– < DIODE > R9103 1-216-819-11 METAL CHIP 1/10W R9104 1-216-820-11 METAL CHIP 1/10W D9102 8-719-081-97 DIODE MMDL914T1 R9105 1-216-837-11 METAL CHIP 1/10W D9104 8-719-062-51 DIODE 1PS226-115 D9106 8-719-060-90 DIODE S2L60F...
  • Page 150 KV-HR36M90 RM-1007 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK –––––––– ––––––––– ––––––––––––– ––––––––– –––––––– ––––––––– ––––––––––––– ––––––––– R9176 1-216-833-11 METAL CHIP 1/10W R9177 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W 4-100-558-01 BOARD, TOP R9178 1-216-834-11 METAL CHIP 1/10W 4-392-003-01 BAND, HOLD R9179 1-218-895-11 METAL CHIP...
  • Page 151 KV-HR36M90 RM-1007 English Sony EMCS Corporation 2003IR02-1 9-965-XXX-01 ©2003.9 Ichinomiya TEC – 214 –...

Table of Contents
