Philips HR1858/90 Service Manual

Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
Features:
- Unique micro-mesh filter
- Extra large Feeding Tube
- 2 L pulp container
- Easy-to-clean
- 2 speed control
- Rubber feet for extra stability
- Easy and convenient cord storage
Accessories (included):
- Juice Jug (1,5 L)
- Cleaning Brush
Safety
- Safety locking system with 2 clamps.
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Power
- Voltage / frequency
- Juice Jug capacity
- Pulp Container capacity
- Cord length
- SAP coding
Published by Philips Consumer Lifestyle
10/07
: 700 W
: 220 - 240 V / 50 - 60 Hz
: 1,5 Litre
: 2,0 Litre
: 120 cm
: HR1858/90
Printed in the Netherlands
- Product size:
Length
Width
Height
- Weight
Materials used:
- Clamps
- Feeding Tube ring
- Filter
- Housing
- Juice Collector
- Juice Jug Lid
- Juice Jug
- Juicer Lid
- Pulp Container
- Pusher
- Spout
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- No specific issues.
REPAIR INSTRUCTION
- No specific issues.
OPTIONAL (accessories)
- No specific issues.
© Copyright reserved
Juicer
HR1858/90
: 300 mm
: 195 mm
: 400 mm
: 3500 g
: POM
: ABS
: Stainless Steel
: POM
: ABS
: PP
: SAN
: SAN
: PP
: ABS
: Stainless Steel
Subject to modification
