12. Slide the Right and Left Handrail Grips (109,
79) onto the Right and Left Handrail Covers
(not shown). Attach the Handrail Grips with two
#8 x 3/4" Screws (4); do not overtighten the
Screws.
13. Raise the Frame (56) to the upright position.
Have a second person hold the Frame until
step 15 is completed.
Remove the two 5/16" x 3/4" Screws (31) from
the Latch Crossbar (41).
Orient the Latch Crossbar (41) as shown. Make
sure that the "This side toward belt" sticker
(F) is facing the treadmill. Attach the Latch
Crossbar to the brackets on the Frame (56) with
the two 5/16" x 3/4" Screws (31) that you just
removed and two 5/16" Star Washers (11).
12
79
4
13
11
31
56
13
4
109
Brackets
F
41
11
31
