Pro-Form Endurance s9 PETL99714.0 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Model No. PETL99714.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 08457 089 009
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
c/o HI Group PLC
Express Way
CASTLEFORD
WF10 5QJ
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
www.iconeurope.com

Advertisement

Table of Contents
loading

Related Manuals for Pro-Form Endurance s9 PETL99714.0

Summary of Contents for Pro-Form Endurance s9 PETL99714.0

  • Page 1 Model No. PETL99714.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. c/o HI Group PLC Express Way CASTLEFORD...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 DANGER: 21. Do not attempt to move the treadmill until it Always unplug the power is properly assembled. (See ASSEMBLY on cord immediately after use, before clean- page 7 and HOW TO FOLD AND MOVE ing the treadmill, and before performing the THE TREADMILL on page 21.) You must be maintenance and adjustment procedures able to safely lift 45 lbs.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new PROFORM reading this manual, please see the front cover of this ® ENDURANCE S9 treadmill. The ENDURANCE S9 manual. To help us assist you, note the product model treadmill provides an impressive selection of features number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing •...
  • Page 8 2. Make sure that the power cord is unplugged. Wire Press a Base Cap (74) into each side of the Base (94). Identify the Right Upright (90). Have a second person hold the Right Upright near the Base (94). See the inset drawing. Tie the wire tie in the Right Upright (90) securely around the end of the Wire Upright Wire (81).
  • Page 9 4. Hold the Right Upright (90) against the Base (94). Be careful not to pinch the wires. Partially tighten three 3/8" x 4" Screws (7) with three 3/8" Star Washers (13) into the Right Upright and the Base; do not fully tighten the Screws yet.
  • Page 10 6. Identify the Right Handrail (84). Attach the Right Handrail (84) to the Right Upright (90) with two 5/16" x 2 1/4" Screws (28) and two 5/16" Star Washers (11). Make sure not to pinch the Upright Wire (81). Start both Screws, and then tighten them.
  • Page 11 8. With the help of a second person, hold the con- sole assembly near the Right Handrail (84) and Console the Left Handrail (not shown). Assembly See the inset drawing. Connect the Upright Wire (81) to the console wire. The connectors should slide together easily and snap into place.
  • Page 12 10. Attach the console assembly with two 5/16" x 1 1/4" Screws (5), two 5/16" x 1 3/4" Screws (9), Console and four 5/16" Star Washers (11). Start all four Assembly Screws, and then tighten them. 11. Attach the Right and Left Handrail Covers (31, 87) with six #8 x 3/4"...
  • Page 13 12. Slide the Right and Left Handrail Grips (8, 79) onto the Right and Left Handrail Covers (not shown). Attach the Handrail Grips with two #8 x 3/4" Screws (4). Be careful not to overtighten the Screws. 13. Firmly tighten all six 3/8" x 4" Screws (7). Then, slide the Left and Right Base Covers (82, 83) downward.
  • Page 14 14 . Note: If it is assembled on a smooth surface, the treadmill may roll forward during this step. Raise the Frame (56) to the upright position. Brackets Have a second person hold the Frame until step 16 is completed. Orient the Latch Crossbar (98) as shown.
  • Page 15 16. Attach the upper end of the Storage Latch (99) to the bracket on the Latch Crossbar (98) with a 5/16" x 2 1/4" Shoulder Bolt (62) and a 5/16" Nut (63). Lower the Frame (56) (see HOW TO LOWER THE TREADMILL FOR USE on page 21).

  • Page 16: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill.
  • Page 17 CONSOLE DIAGRAM FEATURES OF THE CONSOLE To turn on the power, see page 18. To use the manual mode, see page 18. To use an onboard The treadmill console offers an impressive array of workout, see page 19. To use the information mode, see page 20.
  • Page 18 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 19 5. Follow your progress with the displays. 7. Turn on the fan if desired. Incline/Calories display—This display will show The fan features multiple the incline setting for several seconds, each time speed settings. Press the fan the incline changes. This display will also show the buttons repeatedly to select a approximate amount of calories you have burned.
  • Page 20 Each workout is divided into segments. One speed To select the information mode, hold down the Stop setting and one incline setting are programmed for button while inserting the key into the console and then each segment. Note: The same speed setting and/ release the Stop button.

  • Page 21: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 22: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regularly clean the treadmill and keep the walking a. Check the power switch (see drawing c at the left). belt clean and dry. First, press the power switch into If the switch has tripped, wait for five minutes and the off position and unplug the power cord.
  • Page 23 Next, locate the Reed Switch (52) and the Magnet b. If the walking belt is overtightened, treadmill per- (50) on the left side of the Pulley (49). Turn the formance may decrease and the walking belt may Pulley until the Magnet is aligned with the Reed become damaged.
  • Page 24 SYMPTOM: The walking belt is not centered SYMPTOM: The walking belt slips when walked on between the foot rails a. First, remove the key and UNPLUG THE POWER IMPORTANT: If the walking belt rubs against the CORD. Using the hex key, turn both idler roller foot rails, the walking belt may become damaged.

  • Page 25: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 26: Part List

    PART LIST Model No. PETL99714.0 R1213A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Cable Tie 1/4" x 1/2" Screw Drive Roller/Pulley Base Pad Magnet #8 x 3/4" Screw Reed Switch Clip 5/16" x 1 1/4" Screw Reed Switch 5/16"...
  • Page 27 Key No. Qty. Description Key No. Qty. Description Left Pulse Cover Filter Right Pulse Bar Receptacle Right Pulse Cover Base Pad Spacer Latch Crossbar Ferrite Box Storage Latch Motor Isolator Latch Spacer – User’s Manual Motor Bushing Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.

  • Page 28: Exploded Drawing

    EXPLODED DRAWING A Model No. PETL99714.0 R1213A...
  • Page 29 EXPLODED DRAWING B Model No. PETL99714.0 R1213A...
  • Page 30 EXPLODED DRAWING C Model No. PETL99714.0 R1213A...
  • Page 31 EXPLODED DRAWING D Model No. PETL99714.0 R1213A...

  • Page 32: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
