User guide
NA
English,1
Español, #
AW 129
Français, 49
WASHING MACHINE
Contents
Description, 2
Your safety and that of your family
Warnings about installation
Unpacking, Installation, 5-6-7-8-9
Unpacking and levelling
Water and Electric connections
and Option Modifiers, 10-11
Washing Options
Programs, 12
Before washing
and Washcare Tips, 14-15-16-17-18
Typical wash loads and laundry preparation
Washcare tips and understanding fabric care labels (symbols)
Switching off the water or electricity supply
Cleaning the detergent dispenser drawer
Troubleshooting, 20-21
Service, 22
Warranties, 23
Ariston Statement of Warranties
NA
Advertisement
Table of Contents
Related Manuals for Ariston AW129NA
Summary of Contents for Ariston AW129NA
-
Page 1: Table Of Contents
Switching off the water or electricity supply Cleaning the machine Cleaning the door bowl Checking the water inlet hose Drum maintenance Cleaning the detergent dispenser drawer Troubleshooting, 20-21 Service, 22 Before calling for Assistance Warranties, 23 Ariston Statement of Warranties... -
Page 2: Na Sp F Description
Description Control panel Varies by Model) • Dispenser drawer Please record the Model number • and Serial number of your machine Interlocking door located behind the door for future and release lever reference. Hot and Cold water inlet points Drainage hose Power cord Front adjustable feet Hooked end support... -
Page 3: Important Safety Instructions
Important Safety Instructions INTRODUCTION Congratulations on your new Ariston washing machine. This is a highly sophisticated engineered product that will give you many years of satisfaction. Please spend a few moments reading the Owner Manual. This will show you ways to best utilize your valuable purchase... -
Page 4: Technical Details
RECESSED, CLOSET AND ALCOVE Te c h n ic a l d e ta ils INSTALLATION (Instructions) M o d e l A W 1 2 9 The machine may be installed in a recessed area, closet or alcove. 2 3 .4 " ( 5 9 .5 c m ) w id e The installation spacing is in inches and is the minimum D im e n s io n s... -
Page 5: Unpacking Your Machine
Unpacking ! Keep this instruction book on hand in order to refer to it when necessary. Take it you when you move, and should you sell this appliance or pass it on to an other party, make sure that this booklet is supplied along with the appliance so that the new owner may be informed about warnings and suggestions on how the works. -
Page 6: Remove The Shipping Bolts
Remove the Shipping Bolts IMPORTANT: Location Read these instructions to remove the 2 shipping bolts (see Description for location). Situated on one Where you install your machine will affect its performance: either side of the rear panel, BOTH shipping bolts MUST be For your safety and to comply with electrical removed before use. -
Page 7: Water Connection
Installation Water Connection Drainage Connection Standpipe Diameter/Capacity. Needs a 1 minimum Caution diameter standpipe with a minimum carry-away capacity of 1. The washing machine must only be operated 7 gallons per minute. with cold and hot (max. 140°F//60°C) tap water. Top of Standpipe. - Page 8 Installation Floor Standpipe Drain Sink Drainpipe Method Top of standpipe must Entry into the sink drain be at least 25 inches (62 system must be above the cm) high and no higher trap (see fig. aside ). than 34 inches (86 cm) When routing the drain from the bottom of the hose through cabinets or...
-
Page 9: Electrical Connection
Electrical connection Final installation checklist Machine Voltage/Amperage - 120V, 60 Hz, 11 Amp. • Instructions and Installalion Kit have been removed from the tub. Connection - 3-prong plug with 6’ cord is provided with the machine. Circuit/Protector - 3-wire single phase, 120V, 60 Hz, AC, •... -
Page 10: Washing Machine Description
Washing machine description Control panel AW 129 (NA) Warning: To reduce the risk of fire, electric shock, or injury, read the IMPORTANT SAFETY INSTRUCTIONS, before operating this appliance STATUS START/ ON-OFF OPTION Program listing INDICATOR CANCEL Button Buttons Lights Button Detergent dispenser PROGRAM selector dial... -
Page 11: Option Modifiers
Program and Option Modifiers Option modifiers Superwash: Use this option to select a more intensive wash and time program for the cotton (Sanitary, Heavy cotton, Regular cotton) and synthetics-permanent press (Heavy synthetics, Regular Synthetics). Pre-wash Button: For heavily soiled loads, push this button to add an extra wash to any wash program (except 4-7-10-11 programs). Easy Iron Button (Rinse Hold): This option reduces the amount of creasing on fabrics, making them easier to iron. -
Page 12: Permanent Press
Program and Options Modifiers AW 129 (NA) Program Pre-wash Detergent Fabric Options Length of Type of fabric Description Load Dial N. (Option) for wash softener the cycle and degree of wash cycle (min.) without of soil Options COTTON HEAVY DUTY White Colourfast items Pre-Wash Wash cycle... -
Page 13: Detergent Dispenser And Tips
Detergents tips and laundry Detergent dispenser Detergent tips Dispense a correct amount of detergent so to get Do not put any items into the drawer, other than detergents designed to be released from the drawer, as better washings they may cause damage or blockage. Warning AVOID RISK OF POISONING KEEPING DETERGENTS AND ADDITIVES OUT OF... -
Page 14: Starting A Wash Program
Starting a wash Program Laundry preparation Sorting Clothes should be sorted from separate items which Fasten all hooks, zippers and buttons. could damage other garments. Sort items into loads Turn knit garments wrong side according to similar colors, fabrics, garment out to reduce the tendency of knits to “pill”. -
Page 15: Useful Tips
Washcare tips and Starting Useful tips Never use your washing machine to wash... torn, fraying or How much does it weigh? non-hemmed linen. If it is absolutely neccessary, place it 1 sheet 1 1/4 lb (400-550 gr.) in a bag for protection. Do not wash colored linen with 1 pillow case 4 oz. -
Page 16: Operating The Washing Machine
Operating the washing machine On-Off / Selecting a program A typical wash load 1. Switch the machine on by pressing the On/Off button. Two wexampes of maximum load for different types of fabric: 2. Load your laundry into the machine and shut the door. COTTON 2 Bath Towels 3. -
Page 17: Stain Removal Chart
Stain Removal Chart Cream, Ice Cream or Milk Blood Sponge stain with cool water or soak stain in cool water Rinse or soak fresh stain in cold water. Work detergent for 30 minutes or longer. If stain remains, work a into any remaining stain. - Page 18 Grease or Oil Perfume Rinse in cold water. Rub undiluted liquid detergent or Scrape away excess. Rub detergent paste or a general a detergent paste into stain. Rinse. If stain remains, purpose liquid household cleaner into stain, rinse with bleach. hot water.
-
Page 19: Care And Maintenance
Care and Maintenance Switching off the water and Cleaning electricity supplies Cleaning the exterior Use a damp cloth or silicon polish to clean the exterior • Turn off the water tap after every wash. This limits surfaces of the appliance. wear and tear on the machine’s water supply and prevents leaks. -
Page 20: Troubleshooting
Troubleshooting From time to time your machine may not operate as it should. Before calling for Assistance (see “Service-Assistance”), make sure that the problem cannot be resolved easily using the following list. Malfunction: Possible causes / Solutions: The washing machine will not switch on. •... - Page 21 There is too much foam. • The detergent is not designed for machine washing (the packaging should state that the product is “for washing by machine”, “for washing by hand or machine” or similar). • Too much detergent was used. •...
-
Page 22: Service
Service Before calling for Assistance: • Check whether you can solve the problem on your own (see page 20); • Restart the programme to check whether the problem has been solved; • If this is not the case, contact an authorised Technical Service Centre on the telephone number provided on the guarantee certificate. -
Page 23: Warranties
Lifetime Limited Warranty against Stainless Steel Rust Through from the date of installation* Ariston wll replace your clothes washer, free of charge, with the same model or a current model that is equivalent or better in functionality if the washer drum should rust though under conditions of normal home use, labor, shipping, and installation charges excluded.
