- Page 1 INSTALLATION MANUAL LED TV* Please read this manual carefully before operating your set and retain it for future reference. LW76** LY76** LY96** www.lg.com...
-
Page 2: Table Of Contents
- USB Download Menu EZ-MANAGER WIZARD - Diagnostics Menu LANGUAGE & COUNTRY SELECTION - Automatically for Setup - Manually for Setup - USB LG Smart Install Utility INSTALLATION MENu INTRODUCTION LG HOTEL MODE - Hotel Mode Operation - Power On Status... -
Page 3: Location And Function Of Controls
LOCATION AND FUNCTION OF CONTROLS LOCATION ANd FuNCTION OF CONTrOLS Parts and Button B type : LY761* A type : LW76**, LY760* Screen Screen Speakers Speakers Stand Base Remote control and (Only LY760*) Intelligent sensors Remote control and Power Indicator Intelligent sensors Power Indicator... -
Page 4: Led Clock Connection
TABLE OF CONTENTS Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment. Joystick Button - This button is located below the TV screen. NOTE You can set the power indicator light to on or off by selecting General in the main menus. LEd Clock Connection (Only LW76**,... -
Page 5: Ezmanager
EZMANAGER EzMANAGEr y Image shown may differ from your TV. INTrOduCTION The Pro:Centric Platform enables you to simply install, manage and use guest-centric solutions. The default Domain “procentric.local” and IP Server Address are needed to be registered in DNS TV will contact the IP Server using the default Domain “procentric.local”... -
Page 6: Language & Country Selection
EZMANAGER LANGuAGE & COuNTrY SELECTION Confirm your location and language setting. Language ꕍ English Country ꕍ United Kingdom - Please select the Language and Country. Some countries need to select the Time zone. -
Page 7: Automatically For Setup
EZMANAGER Automatically for Setup From the TV Configuration Options screen, you can choose how to proceed with the configuration of this TV. Whether you will configure the TV for Pro:Centric operation via the wizard or use a USB memory device to configure the TV, you may first wish to set the Room Number on the TV. - If you intend to set Room Number as part of the TV configuration, use the Room Number option to assign the Room # for this TV before you continue with additional configuration. - Page 8 EZMANAGER This step automatically searches for the Pro:Centric Server. If was found the Pro:Centric data channel, select the ‘NEXT’.
- Page 9 EZMANAGER Downloading the Pro:Centric application files takes few minutes. After the installation is completed, the following screen will be displayed.
-
Page 10: Manually For Setup
EZMANAGER Manually for Setup Select a Label and/or enter the Room Number using the numeric keypad on the remotes or using the virtual keyboard on the TV screen. To continue, move and select ‘NEXT’. Please select the ‘MANuAL PrO:CENTrIC’. - Page 11 EZMANAGER Configure the appropriate Pro:Centric settings in the TV.
- Page 12 EZMANAGER Downloading the Pro:Centric application files takes few minutes. After the installation is completed, the following screen will be displayed.
-
Page 13: Usb Lg Smart Install Utility
EZMANAGER uSB LG Smart Install utility Select the ‘uSB CONFIGurATION’ → ‘TV MANAGEr’. - If you have USB Memory for “LG_DTV” or “lg_dtv” folder, this step shows the USB file list for downloading the items. - Page 14 EZMANAGER Downloading the Pro:Centric application files takes few minutes. After the installation is completed, the following screen will be displayed.
-
Page 15: Installation Menu
The abundant functions for Hotel TV linked with software installation can be projected on OSD as ‘Installation Menu’. The wide range of hotel features can be performed simply on additional window to enhance the LG hotel TV’s easy installation and convenient operation for Hotelier and System Integrators. -
Page 16: Lg Hotel Mode
TV Manager Radio Video Blank Use the button to select the LG HOTEL MOdE SETuP. Use the ‘OK’ button and then button to select Hotel Mode Operation. - When ‘Hotel Mode Operation’ is set to Yes (Work), all functions of Hotel Mode apply. -
Page 17: Volume
INSTALLATION MENU Volume - Please select ‘Yes’ or ‘No’ to set the ‘Start Volume’, ‘Maximum Volume’ and ‘Minimum Volume’ Start Volume - When the TV is turned for the first time, and to set the size of the start sound. - The default setting is “Off”. -
Page 18: Radio Video Blank
INSTALLATION MENU radio Video Blank - Set to Yes(Work) or No(Do Not Work). - Programme that is set to ‘Radio Programme’ and only has Sound should decide whether to set ‘Video Blank’ or not. - When ‘Radio Video Blank’ is set to Yes(Work), ‘Video Blank’ works only in case of Radio Programme. -
Page 19: Network
INSTALLATION MENU NETWOrK NETWORK LG Hotel Mode MAC Address 12:34:56:78:12:34 Network ꕍ Network Setting Pro:Centric IP Stream Control Wake On LAN General Media Share TV Manager Use the button to select the NETWOrK. MAC Address - Displays the MAC address (not customizable). -
Page 20: Ip Stream Control
INSTALLATION MENU IP Stream Control Audio PTS Offset - Controlling output stream timing of audio. Video PTS Offset - Controlling output stream timing of video. Wake On LAN - Sets the Wake On LAN function to Enable or Disable. Use “Magic Packet”. -
Page 21: Pro:centric
INSTALLATION MENU PrO:CENTrIC PRO:CENTRIC LG Hotel Mode ꕍ Mode Network Configuration Only WORF DISABLE Pro:Centric Room Number Setting ꕍ Media Type General Receive Data ENABLE Media Share ꕍ Data Channel Type DVB-C ꕍ Data Channel Freq(kHz) TV Manager Use the button to select the PrO:CENTrIC. -
Page 22: Receive Data
INSTALLATION MENU y P:C IP Setting - It can be set using the or number buttons. (IP a) Sets the first number in the IPv4 address. (IP b) Sets the second number in the IPv4 address. (IP c) Sets the third number in the IPv4 address. (IP d) Sets the fourth number in the IPv4 address. -
Page 23: General
INSTALLATION MENU GENErAL GENERAL LG Hotel Mode Configuration Setup Network External Speaker Set ID Setup Pro:Centric Power Saving HCEC Setup General Clock Setup Password Change Media Share PreLoaded App Lock Mode TV Manager Confi guration Setup Select rCu - It is a mode to set whether to use Select RCU or not. When ‘Select RCU’ is set to ‘Enable’, You can adjust ‘Number of RCU’... - Page 24 INSTALLATION MENU y Type of Connector: D-Sub 9-Pin Male Signal Signal requirements RX RS232 Standard RS232 specification TX RS232 Standard RS232 specification IR from TV Power ground 6, 8 Not connected Male connector on box, +5VDC 10%, max 100mV ripple viewed towards connector.
-
Page 25: External Speaker
INSTALLATION MENU 15Min Auto Off - When ‘15Min Auto Off’ is set to ‘Enable’, TV will turn off if there is no signal in 15Min. Auto Sensing - If ‘Auto Sensing’ is set to ‘To Set ’, the input is automatically switched when the input signal that you set to “ON’... -
Page 26: Set Id Setup
Ir decoding - Determines whether to decode the LG remote control. If No is selected, the TV does not decode it and sends signals only to the IR Out port. You need to run Forced Initialize below once to apply If Yes is selected, the TV decodes and changes it into a CEC Message and sends it to Command via the HDMI CEC Line. -
Page 27: Clock Setup
INSTALLATION MENU Forced Initialize - If ‘No’ is selected, a command should be sent and received between the TV and a device for proper initialization. - If ‘Yes’ is selected, initialization is implemented when a device receives a command. If initialization is not implemented, the TV remote control and local key will work. -
Page 28: Preloaded App
INSTALLATION MENU PreLoaded App If you want to use a particular app, you can choose from the menu. you can setting each apps activation. You can check or uncheck by pressing ‘OK’ button. Lock Mode - If ‘Lock Mode’ is ‘Yes’, the following features will be unavailable. Teletext Sub-Title Caption (Include MPEG4) -
Page 29: Media Share
INSTALLATION MENU MEdIA SHArE MEDIA SHARE LG Hotel Mode SmartShare DISABLE Network Screen Share DISABLE DISABLE Pro:Centric ꕍ TV Name LG SMART+ TV General SoftAP DISABLE Use Default DISABLE Media Share ꕍ Security Key 00000000 TV Manager ► You can setting Whether to use for “SmartShare”... -
Page 30: Use Default
INSTALLATION MENU use default - If you want to use default password(this password was generated randomly), you must select ‘yes’ in this item. Security Key - When guests want to use TV’s SoftAP function, they need this password. If you want to change this default password, you need to Change ‘Use Default Setting’... -
Page 31: Tv Manager
INSTALLATION MENU TV MANAGEr uSB download Menu * uSB Cloning : An Installer can quickly set up and clone multiple TV sets at a property. These cloned TVs will all have the same Master TV Setup: Public Display Mode Installation Menu settings, User A/V settings and the Channel Map. - Page 32 INSTALLATION MENU Ez download - Ez Download is a function that enables users to download the desired items all at once, such as EPK (software update file), TLL (see Send to USB descriptions for more information regarding file types), Logo Image, etc (TLX, MICOM for Pro:Centric). Splash images and EPK files should be copied into the folder named LG_DTV on the USB.
- Page 33 INSTALLATION MENU update TV Software - This feature update EPK of TV through the hex file in USB. The target file is located in \lg_dtv folder. - If there are more than two USB memory Device, It is possible to select the USB. - The download sequence is USB →...
- Page 34 INSTALLATION MENU receive From uSB(TLL) - Once the internal TV data and its channel map information is written to the USB memory card, the user can start “Receive From USB” process with the data file generated and stored in USB memory card.
-
Page 35: Diagnostics Menu
INSTALLATION MENU diagnostics Menu This diagnostic function provides current status information of the TV in XML file format using a USB device. If the user sets a signal standard level, SignalTrace checks the signal strength status of the digital channel that the user tuned to. It checks and records good and bad channel signals, and then provides the signal information to a USB storage device in XML file format.
