ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES
IMPORTANT — This Document is customer property and is to remain with this unit. Please return to service information
pack upon completion of work.
These instructions do not cover all variations in
systems nor provide for every possible contingency to
be met in connection with installation. All phases of
this installation must comply with NATIONAL, STATE
AND LOCAL CODES. Should further information be
desired or should particular problems arise which are not
covered sufficiently for the purchaser's purposes, the matter
should be referred to your installing dealer or local distributor.
A. GENERAL
WARNING
!
This information is intended for use by individuals posses-
sing adequate backgrounds of electrical and mechanical
experience. Any attempt to repair a central air conditioning
product may result in personal injury and or property
damage. The manufacturer or seller cannot be responsible
for the interpretation of this information, nor can it assume
any liability in connection with its use.
NOTICE:
Trane has always recommended installing Trane approved
matched indoor and outdoor systems.
The benefits of installing approved matched systems are
maximum efficiency, optimum performance and best
overall system reliability.
Check for transportation damage after unit is uncrated.
Report promptly, to the carrier, any damage found to the unit.
To determine the electrical power requirements of the unit,
refer to the nameplate of the unit. The electrical power
available must agree with that listed on the nameplate.
®
The Weathertron
Heat Pump has been designed and
manufactured to withstand and operate in severe winter
conditions. However, there are precautionary steps which
should be taken at the time of installation which will help
assure the efficient operation of the unit. It is recom-
mended that these precautions be taken for units
being installed in areas where snow accumulation and
prolonged below freezing temperatures occur.
1. Units should be elevated 3 to 12 inches above the pad or
rooftop, depending on local weather. This additional
height will allow better drainage of snow and ice (melted
during defrost cycle) prior to its refreezing. This should
prevent a build-up of ice around the unit which occurs
when unit is not elevated. Insure that drain holes in
unit base pan are not obstructed preventing
draining of defrost water.
Installer's Guide
Heat Pumps
2TWR3
1
2. If possible, avoid locations that are likely to accumulate
snow drifts. If not possible, a snow drift barrier should be
installed around the unit to prevent a build-up of snow
on the sides of the unit and should be of sufficient
distance from the unit to prevent restriction of airflow to
and from the unit. Also allow for proper maintenance
space. The barrier should be constructed of materials
which will blend in with the building design.
3. Avoid locating the unit where condensation and freezing
of defrost vapor may annoy the customer. For instance,
installing the unit under a bedroom, kitchen, or picture
window may be annoying to the customer since conden-
sate and fog will occur during the defrost cycle.
4. Avoid locating the unit under the eaves or other over-
head structures as sizeable icicles may form and the unit
may be damaged by these falling icicles.
B. LOCATION AND PREPARATION
OF THE UNIT
1. When removing unit from the pallet, notice the tabs on
the basepan. Remove tabs by cutting with a sharp tool as
shown on page 2, Figure 2, and slide unit off of pallet.
2. The unit should be set on a level support pad at least
as large as the unit base pan, such as a concrete slab.
If this is not the application used please refer to
application bulletin "Trane XR-APG**-EN" (* denotes
latest revision number).
3. The support pad must NOT be in direct contact with any
structure. Unit must be positioned a minimum of 12"
5 FT. ABOVE UNIT — UNRESTRICTED
18-BC59D1-1

Advertisement

Table of Contents
loading

Summary of Contents for Trane 2TWR3

  • Page 1 If not possible, a snow drift barrier should be NOTICE: installed around the unit to prevent a build-up of snow Trane has always recommended installing Trane approved on the sides of the unit and should be of sufficient matched indoor and outdoor systems.
  • Page 2: Installing Refrigerant Lines

    Installer’s Guide NOTE: BASEPAN TAB REMOVAL Large diameter tubing will be very difficult to rebend once it has been shaped. 3. Determine the best starting point for routing the refriger- ant tubing — INSIDE OR OUTSIDE THE STRUCTURE. 4. Provide a pull-thru hole of sufficient size to allow both liquid and gas lines.
  • Page 3 Installer’s Guide GAS LINE SERVICE VALVE GAS LINE BALL SERVICE VALVE 1/4 TURN ONLY COUNTERCLOCKWISE FOR FULL OPEN POSITION VALVE STEM UNIT SIDE OF VALVE PRESSURE TAP PORT GAS LINE CONNECTION other leak-checking methods to see that all field joints are leak-free! If not, release pressure;...
  • Page 4: Electrical Connections

    Installer’s Guide 10. Replace liquid service pressure tap port cap and valve the heat pump system. By measuring the change in delta-T, stem cap. These caps MUST BE REPLACED to we can determine the need for defrost. The coil sensor also prevent leaks.
  • Page 5: Troubleshooting

    Installer’s Guide page 8. To obtain proper performance, all units must be M. TROUBLESHOOTING operated and charge adjustments made in accordance with TROUBLESHOOTING CHART — WHAT TO CHECK procedures found in the Service Facts. I. ELECTRIC HEATERS SYSTEM FAULTS Electric heaters, if used, are to be installed in the air han- dling device according to the instructions accompanying the air handler and the heaters.
  • Page 6: Subcooling Charging In Cooling Above 55°F Od Ambient

    The Trane company has always recommended installing R-22 SUBCOOLING CHARGING TABLE Trane approved matched indoor and outdoor systems. DESIGN SUBCOOLING VALUES (°F) All 13 SEER Trane split systems are ARI rated with only LIQUID TXV indoor systems. TEMP. The benefits of installing approved indoor and outdoor split (°F)
  • Page 7 Installer’s Guide 2TWR3 OUTLINE DRAWING NOTE: ALL DIMENSIONS ARE IN MM (INCHES). MODELS BASE FIG. 2TWR3018A 832 (32-3/4) 724 (28-1/2) 651 (25-5/8) 137 (5-3/8) 65 (2-5/8) 210 (8-1/4) 57 (2-1/4) 457 (18) 2TWR3024A 832 (32-3/4) 724 (28-1/2) 651 (25-5/8) 5/16...
  • Page 8: Mounting Hole Location

    7. Indoor coil drain line drains freely. Pour water into drain pan .............. [ ] Trane A business of Trane has a policy of continuous product and product data improvement and it reserves the right to change American Standard Companies www.trane.com design and specifications without notice.
