Page 1: User Manual
User Manual PIXPRO SP360 (PC Version) Ver. 5... -
Page 2: Before You Start
All trademarks mentioned in this manual are used for identification purposes only and are properties of their respective owners. This manual provides you with information on how to use the PIXPRO SP360 application (PC version). JK Imaging Ltd. has tried its utmost to ensure the correctness of the user manual contents, but reserves the right to modify as necessary. -
Page 3: Table Of Contents
Contents Before You Start .............................1 Contents ................................2 Connecting the Action Cam with the computer .................3 Operation Methods ............................4 Remote Viewfinder interface ............................4 View Mode ......................................5 Capture Mode ......................................5 Movie Size .......................................5 Photo Size ........................................5 Unfold Mode ......................................6 Control Area ......................................8 Playback and editing interface ..........................11 View Mode ...................................... -
Page 4: Connecting The Action Cam With The Computer
Connecting the Action Cam with the computer Installing the application Download Application "PIXPRO SP360" (for PC) installation package from the official website, and install it on your computer by following the prompts on the interface. After successful installation, this icon will appear on the desktop. Americas Europe http://kodakpixpro.com/Americas/ http://kodakpixpro.com/Europe/ support/downloads.php support/downloads.php Connection mode: 1. Wi-Fi Connections (supports remote Viewfinder, Playback & Edit): 1.1. Action Cam : Check SSID (PIXPRO-SP360_XXXX) and password (initial password: 12345678) indicated on the label in the battery compartment of the Action Cam. -
Page 5: Operation Methods
Operation Methods Remote Viewfinder interface "Remote Viewfinder" functionality is only available when connected to Wi-Fi. Once connected via Wi-fi, this interface can be used to capture photos and video. A:Setup area B:Display area Remote Viewfinder Playback & Edit 1. Original image file General Settings 2. Unfold image View Mode ● Press and hold the left mouse button to drag the image. Roll the wheel to forward and backward Capture Mode for zooming the image. -
Page 6: View Mode
View Mode Select the icon according to the direction that the Action Cam lens is facing, so the image will be displayed in the upright direction. Means the image will be displayed upright when the lens is facing forward. Means the image will be displayed upright when the lens is facing downward. Means the image will be displayed upright when the lens is facing upward. -
Page 7: Unfold Mode
Unfold Mode Select from several different viewing effects. There are 8 options : Global Front Quad Panorama Ring Magic flat Dome The image files obtained in Front square mode will be stored as square files, and those obtained in the other 7 modes are stored as Global files. The image files obtained in Front mode cannot be unfolded. Global Front Quad Panorama Ring Magic flat Dome... - Page 8 ○ Corresponding table for Movie size and Unfold mode: ( means "available", X means "not available") 1080P30 1440P30 960P50 720P60 WVGA60 ○ Global ○ ○ ○ ○ Front ○ ○ Quad ○ Panorama ○ Ring ○ Magic flat ○ Dome Corresponding table for Photo size and Unfold mode: (O means "available", X means "not available") ○ Global ○ ○ Front ○...
-
Page 9: Control Area
Control Area Calibration : Adjust video image range. This function allows adjustment of the imaging area before shooting. Follow these steps to fine tune the image area. 1. Click the "Calibration" button in the setup area and the red calibration line will appear in the display area. 2. You can use your mouse (or fingers) for adjustment: • Use the left mouse button (or one finger) to drag the image for movement. • Use the mouse wheel (or two fingers) to scale the calibration line. 3. Click the "Calibration" button again, the setting will be saved and the calibration line will disappear. - Page 10 Up / Down / Left / Right / These buttons provide functions such as moving, flipping or zooming the image. The function of each button in each mode is described below： Up / Down Left / Right Move clockwise / Global No effect No effect Move counterclockwise Front Move Up/ down Quad Panorama Zoom In/Out...
-
Page 11: Video Recording
Video recording Click the "REC" button to start video recording. Click the "STOP" button to stop video recording. If the Wi-Fi connection is interrupted during the video recording process, the Action Cam will continue to record and a "Warning!" prompt box will pop up on the computer. Click "Retry" to reconnect. Videos will be stored in the Action Cam. Remote Viewfinder Playback & Edit Remote Viewfinder Playback & Edit General Settings General Settings View Mode View Mode Capture Mode Capture Mode Movie Photo Movie Photo Movie Size Movie Size 1080P30 1440P30... -
Page 12: Playback And Editing Interface
Playback and editing interface Click the "Playback & Edit" tab to enter the interface that enables playback or editing files. A : Setup area Remote Viewfinder Playback & Edit B : Display area General Settings More 1. Index View Mode YYYY/MM/DD Name:100_0341 2. Unfold image Unfold Mode ● Press and hold the left mouse button to drag the 16:9 Global Front Front Quad image. -
Page 13: View Mode
View Mode See Page 5 for explanations. Unfold Mode There are 11 options : Global Front (4:3) Front (16:9) Quad Panorama Ring Magic flat Dome See Page 6 for visual representations of the first 9 options. Extraction Throw-out Extraction Throw-out mode, click the icon below the index view to show the preview, and click the icon below the preview to show the index view. -
Page 14: Control Area
Control Area Calibration : See Page 8 for explanations. Up / Down / Left / Right / Up / Down Left / Right Extraction Zoom In/Out Move Up/ down Move to the left/right Throw-out For other details, see Page 9 for explanations. Center : See Page 9 for explanations. -
Page 15: Control Bar
Control bar ●Action Cam (Wi-Fi Connection) Movie: Download Photo: Download When connected to Wi-Fi, the Action Cam cannot play the movie directly. You will need to download the movie onto your computer before playing. ●Action Cam (USB Connection) or PC Disk 00:09:10 01:03:00 Movie: Save as Photo: Save as Features of buttons on the control bar:... - Page 16 ⑦ . Video progress bar 00:09:10 01:03:00 The video can be quickly jumped to a particular frame by sliding the slider below the progress bar. The starting and ending points of video capture can be selected by sliding the two sliders above the progress bar. ⑧ . Screenshot Capture the current frame before video playback or when paused. ⑨...
-
Page 17: Youtube Sharing
YouTube sharing Round film can be converted into the format compatible with YouTube (Viewing angle can be adjusted by mouse while playing on YouTube). 1. Move the two sliders above the progress bar to select a time frame, click 2. Select the direction of the camera body while recording, check if the image direction is correct via the preview on the right side of the interface, click “Convert”. -
Page 18: Setting
Setting Power Off : When the Action Cam is connected to the computer, if the Action Cam is not operated within a certain period of time, the Action Cam will automatically shut down. There are 3 options : 5min 10min 1. -
Page 19: About Version
About Version Click "About Version XX" to enter the About Interface. 1. View the current version of software. 2. Click the "Software version UP", and enter the downloading interface. 3. Click on the official website on the interface and you can go to the website for more information. About Version 1.0 About PC Software for xxxxxxx v0.00 Software version UP 2015 by JK Imaging Ltd. All Rights Reserved. For More Information www.kodakpixpro.com... - Page 20 © 2014 by JK Imaging Ltd. All Rights Reserved. JK Imaging Ltd., 17239 South Main Street, Gardena, CA 90248, USA JK Imaging Europe, 71 Clarendon road, Watford, WD17 1DS, UK www.kodakpixpro.com...
