Front view
Focus switch (Close-up/Normal)
Microphone
Lens
IR
receiver,
for
optional
remote
control
Download the Extended user guide
www.kodak.com/go/playtouchsupport
Jack for external
microphone, headphones
Video Recording LED
A/V Out
HDMI Out
Micro USB, for battery
charging only
USB Release
USB arm, for video and
picture transfer
www.kodak.com/go/manuals
1
Advertisement
Table of Contents
Related Manuals for Kodak PlayTouch
Summary of Contents for Kodak PlayTouch
-
Page 1: Front View
Front view Focus switch (Close-up/Normal) Microphone Lens receiver, optional remote control Download the Extended user guide www.kodak.com/go/playtouchsupport Jack for external microphone, headphones Video Recording LED A/V Out HDMI Out Micro USB, for battery charging only USB Release USB arm, for video and picture transfer www.kodak.com/go/manuals... -
Page 2: Accessing The Usb Arm
Accessing the USB arm Download the Extended user guide Open the door. Pull down the USB arm. www.kodak.com/go/manuals www.kodak.com/go/easysharecenter Slide the USB lock. -
Page 3: Back View, Touchscreen Gestures
Back view, touchscreen gestures Tap (or tap and hold) Download the Extended user guide www.kodak.com/go/playtouchsupport Power button Battery compartment, SD/SDHC Card slot Speaker Battery charging light Record/OK button Strap post Tripod socket Drag Swipe www.kodak.com/go/manuals... -
Page 4: Understanding The Status Icons
Understanding the status icons Download the Extended user guide www.kodak.com/go/manuals www.kodak.com/go/easysharecenter... -
Page 5: Charging The Battery
Insert the Li-Ion battery. Charge whenever necessary. Turn off the camera, then connect it. KODAK Camera USB Cable, Micro B / 5-Pin Do not plug this cable into a computer. Your adapter may differ. See other charging solutions www.kodak.com/go/playtouchsupport Notched... - Page 6 Charge using an external charger A charger may be an optional accessory and differ from the one pictured. www.kodak.com/go/easysharecenter...
-
Page 7: Inserting An Sd Or Sdhc Card
CAUTION: A card can only be inserted one way; forcing it may cause damage. Inserting or removing a card while the camera is on may cause damage. www.kodak.com/go/playtouchsupport 1 Turn off the camera. 2 Insert the card until it clicks. -
Page 8: Turning On The Camera
(To change your language or date/time in the future, see page To set the language: 1 Drag up/down to view your language. (For more information on using touchscreen gestures, page 2 Tap your language. www.kodak.com/go/easysharecenter 14.) - Page 9 To set the date: 1 Tap to scroll through month, date, year. (Tap/hold to scroll quickly.) 2 Tap MDY to change the date format. 3 The time screen is below the date screen. Drag up to view and set the time. (For more...
-
Page 10: Recording Videos, Taking Pictures
■ choose an effect. ■ Apply an LCD Glare Shield filter (see page NOTE: To apply a filter, the feature must be turned on in the Settings menu (see page (see page 14). www.kodak.com/go/easysharecenter see page 13). (see 15). 14). -
Page 11: Reviewing Videos/Pictures
■ Use the editing features View videos/pictures as thumbnails and select them for ■ sharing. (See the Extended user guide www.kodak.com/go/manuals.) Plug in headphones, then tap Headphone. ■ Access the Volume controls; tap the volume icon ■ NOTE: To switch to recording mode, press the Record/OK button. -
Page 12: Downloading Software
When you connect the camera to the computer, you can download ARCSOFT MEDIAIMPRESSION for KODAK Software (for WINDOWS OS-based computers), the KODAK Camera Setup App (for WINDOWS and MAC OS), or both. NOTE: If running MAC OS, you can also use the APPLE iLIFE suite of products. -
Page 13: Doing More With Your Camera
■ E-mail addresses (all or none) Microphone Choose the sensitivity of the internal or external Gain microphone (if one is connected). Sounds and Turn camera sounds and video recording light on/off. www.kodak.com/go/playtouchsupport , then tap a setting. larger file sizes. - Page 14 Face Show/hide face detect brackets. Detection Brackets Video Output NTSC—Used in North America and Japan; most common format. PAL—Used in Europe and China. Date and Set the date and time. (See Time Language Choose your language. page 15.) www.kodak.com/go/easysharecenter page...
-
Page 15: Applying An Lcd Glare Shield Filter
Normal ■ High Contrast ■ Black and White ■ After the description fades, the Glare Shield remains. www.kodak.com/go/playtouchsupport Doing more with your camera (see page 1 Tap the Settings icon then tap LCD Glare Shield. 2 Tap Filters On. 14). -
Page 16: Hdmi Cable
We recommend that you plug the camera into a power outlet (see page ■ Ensure that the TV menu settings are correct for an HDMI or AV connection. For stereo playback, use the HDMI cable and stereo ■ speakers on your TV or receiver. HDMI Cable www.kodak.com/go/easysharecenter AV Cable... -
Page 17: Editing Videos
4 Tap Save, then follow the prompts to Save (to replace the current video) or Save As (to save it as a new video). www.kodak.com/go/playtouchsupport Doing more with your camera 1 Tap the Review icon 2 Tap the Edit icon Trim Video. -
Page 18: Extracting A Single Video Frame
It’s never been easier to share videos and pictures on your favorite social networking sites. IMPORTANT: To use the camera social networking features, you need to download KODAK Software 1 Tap the Review icon 2 Tap or swipe the left/right side of the LCD to find a video/picture. -
Page 19: Marking Videos/Pictures For Emailing
Add a new email address 1 Tap the icon. 2 Tap Sharing Settings. 3 Tap Manage Email. 4 Tap New Email. Tap each letter. When finished, tap Save. www.kodak.com/go/playtouchsupport Doing more with your camera Add a new email (see (see... -
Page 20: Getting Help
Do not use the USB cable. Use the USB arm page video/pictures to the computer. ■ Videos are Use ARCSOFT MEDIAIMPRESSION for KODAK Software for video playback choppy or jumpy on a ■ Ensure that the computer system requirements are met. Go to www.arcsoft.com/support. - Page 21 ■ Ensure that the camera infrared receiver (above the lens) and the remote control have an remote control. unobstructed path. ■ Try a different angle or move closer. www.kodak.com/go/playtouchsupport (see page 14). 14). 14). Getting help 16). (see (see...
-
Page 22: Getting Help On The Web
See online demos Register your camera Get help using ARCSOFT Software Get help installing software and transferring videos/pictures to the computer (see page (see page 15). www.kodak.com/go/support www.kodak.com/go/playtouchsupport www.kodak.com/go/stepbystep www.kodak.com/go/playtouchaccessories www.kodak.com/go/playtouchdownloads www.kodak.com/go/howto www.kodak.com/go/register www.arcsoft.com/support www.kodak.com/go/support www.kodak.com/go/easysharecenter 10) or LCD and click... - Page 23 If the LCD breaks, do not touch the glass or liquid. Contact Kodak customer support. ■ The use of an accessory that is not recommended by Kodak may cause fire, electric shock, or injury. For approved accessories, go to www.kodak.com/go/playtouchaccessories.
- Page 24 Kodak will, at its option, refund the purchase price paid for the product provided the product has been returned to Kodak along with proof of the purchase price paid. Repair, replacement, or refund of the purchase price are the sole remedies under the warranty. If replacement parts are used in making repairs, those parts may be remanufactured, or may contain remanufactured materials.
- Page 25 The limitations and exclusions of liability set forth herein apply to both Kodak and its suppliers.
- Page 26 Appendix Canadian DOC statement DOC Class B Compliance—This Class B digital apparatus complies with Canadian ICES-003. Observation des normes-Classe B—Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Korean Li-Ion Regulatory www.kodak.com/go/easysharecenter...
- Page 27 Eastman Kodak Company Rochester, New York 14650 Kodak, 2010 All screen images are simulated. Kodak and Playtouch are trademarks of Eastman Kodak Company. HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. 4H7218_en...
