Prior to using the Iridium Extreme® PTT device, you must ensure that you and any
users of your device read and understand this User Manual including the safety
warnings and information. Failure to do so could result in serious injury or death.
© 2014 Iridium Satellite LLC. All rights reserved. Iridium, Iridium Extreme® and the Iridium
logo are registered trademarks of Iridium Satellite LLC and its affiliates. All other trademarks,
service marks and logos are the property of their respective holders, which have not endorsed,
sponsored or otherwise affiliated with Iridium. Information is subject to change without notice.
Version: HPTTUG1401
Iridium
Extreme
PTT
User Manual
web:
www.iridium.com
email:
info@iridium.com
toll free:
+1.866.947.4348
phone:
+1.480.752.5155
®

Advertisement

Table of Contents
loading

Related Manuals for Iridium extreme ptt

Summary of Contents for Iridium extreme ptt

  • Page 1 +1.480.752.5155 Prior to using the Iridium Extreme® PTT device, you must ensure that you and any users of your device read and understand this User Manual including the safety warnings and information. Failure to do so could result in serious injury or death.
  • Page 2 This Iridium Extreme® PTT product package contains the following: • Iridium Extreme® PTT User Manual • GEOS Emergency Services Brochure Written materials are also available online at www.iridium.com or by calling 1.480.752.5155 (Direct); 1.866.497.4348 (Toll Free North America). Iridium Extreme® PTT User Manual...
  • Page 3 User Manual. Iridium reserves the right to revise this User Manual or withdraw it at any time without prior notice. No warranty of any kind is made with regard to this User Manual, including but not limited to the implied warranties of merchantability and fitness for a particular purpose.
  • Page 4 Iridium harmless with respect to any claims or actions by third parties related to your improper use of copyrighted materials and to pay all costs, damages, fines and other amounts incurred by Iridium, or on its behalf, in the defense of any such claims or actions. Export Compliance The Iridium Extreme®...

  • Page 5: Table Of Contents

    Using the Security Menu ..................189 Phone Mode Troubleshooting ................200 4: Push-to-Talk Mode Operation ............205 Introduction .......................205 Tips for Efficient Operation ...................206 Device Overview .......................207 Indicators ........................208 Getting Started in PTT Mode................209 Using PTT Mode ......................210 Iridium Extreme® PTT User Manual...
  • Page 6 Push-to-Talk Mode Troubleshooting ..............232 5: Certification and Compliance Information ........233 6: Limited Warranty Including Exclusions, Disclaimers, Limitations of Liability and Conditions of Use; Warranty Claim Process, Privacy and Data Security, and Software License ........235 Iridium Extreme® PTT User Manual...

  • Page 7: 1: Introduction And Important Safety Information

    Privacy and Data Security, and the Software License, are all located in Section 6. The instructions in this User Manual are divided into three sections common to the Iridium Extreme® PTT device and unique to each mode of operation: Iridium Extreme® PTT User Manual...

  • Page 8: Important Safety Information

    Important Safety Information WARNING Prior to using the Iridium Extreme® PTT, you must ensure that you and any users of your device read and understand this User Manual including the safety warnings and information. Failure to do so could result in serious injury or death...
  • Page 9 Harmful noise. Exposure to Radio Frequency Signals Your Iridium Extreme® PTT device is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. Your Iridium Extreme® PTT device is designed to comply with local regulatory requirements in your country concerning the exposure of human beings to RF frequency.
  • Page 10 Specific Absorption Rate Data This Iridium Extreme® PTT meets international standards for exposure to radio waves. Your satellite phone is designed and manufactured not to exceed limits for exposure to radio frequency (RF) energy. These limits are part of comprehensive guidelines and established permitted levels of RF energy for the general population.
  • Page 11 Do not disassemble, crush, puncture, shred or otherwise attempt to change the form of the battery. Do not let the Iridium Extreme® PTT device or battery come in contact with water. Water can lead to corrosion of the circuits.
  • Page 12 Important: Use only Iridium original products for safety and quality assurance. Iridium’s warranty does not cover damage caused by use of non- Iridium batteries. Important: Follow these guidelines when charging your battery: • Keep the battery at room temperature. Never expose batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when charging.
  • Page 13 Caller location identification is not automatically transmitted on the Iridium system. Iridium does not guarantee network availability at all times due to satellite unavailability, terrain,weather, or other conditions that may prevent an emergency call from being placed.
  • Page 14 • Give full attention to driving – driving safely is your first responsibility. • Use hands-free phone operation, if available. • Pull off the road and park safely before making or answering a call. Iridium Extreme® PTT User Manual...
  • Page 15 For optimal performance and to be sure that exposure to RF energy does not exceed guidelines set forth in the relevant standards discussed in “Exposure to Radio Frequency Signals” on p. 3 and “Specific Absorption Rate Data” on p. 4 always follow the instructions and precautions. Iridium Extreme® PTT User Manual...
  • Page 16 Product Operation If you wear the satellite phone on your body, always place it in an Iridium leather case or other approved accessory. Refer to www.iridium.com. Using accessories not supplied by Iridium may cause your satellite phone to exceed RF energy exposure guidelines.
  • Page 17 Airline regulations prohibit using your phone while in the air. Check and comply with the policy of your airline regarding the use of your phone while the aircraft is on the ground. Switch OFF your phone before boarding an aircraft. Iridium Extreme® PTT User Manual...
  • Page 18 If glass breaks do not touch or attempt to remove. Stop using the phone until the glass is replaced by a qualified service center. Iridium Extreme® PTT User Manual...
  • Page 19 If you continue to have discomfort during or after such use, stop use and see a physician. Iridium Extreme® PTT User Manual...
  • Page 20 Renseignements importants sur la sécurité AVERTISSEMENT Avant d’utiliser le téléphone Iridium Extreme® PTT, vous devez vous assurer que tous les utilisateurs de l’appareil, incluant vous-même, compreniez bien le présent manuel de l’utilisateur, y compris les avertissements et instructions de sécurité. Le non-respect de ces procédures pourrait entraîner des blessures...
  • Page 21 Ne pas jeter votre batterie au feu. Bruit nuisible. Exposition aux signaux radioélectriques Votre téléphone satellite Iridium Extreme® PTT est un émetteur-récepteur à faible puissance. Lorsqu’il est sous tension, il reçoit et émet des signaux radioélectriques (HF). Votre téléphone satellite Iridium Extreme® est conçu de façon à...
  • Page 22 Données de taux d’absorption spécifique Ce téléphone satellite Iridium Extreme® PTT satisfait aux normes internationals relatives à l’exposition aux ondes radioélectriques. Votre téléphone satellite est conçu et fabriqué pour ne pas dépasser les limites d’exposition à l’énergie radioélectrique (HF). Ces limites font partie des directives exhaustives et des niveaux admissibles établis...
  • Page 23 CONÇUS POUR SE TROUVER DANS LES LIMITES DE CES DIRECTIVES. Batteries Toutes les batteries peuvent occasionner des blessures graves ou des dégâts matériels, surtout si elles ne sont pas manipulées correctement ou si elles sont utilisées alors qu’elles sont endommagées. Iridium Extreme® PTT User Manual...
  • Page 24 Ne démontez pas, n’écrasez pas, ne perforez pas ou ne broyez pas les batteries, ou ne modifiez en aucune façon leur forme. Ne permettez pas à l’appareil Iridium Extreme® PTT ou à la batterie d’entrer en contact avec de l’eau. L’eau peut entraîner la corrosion des circuits de l’appareil.
  • Page 25 Appel d’urgence Afin de faire des appels d’urgence, vous devez être en mode téléphone pour accéder au service de téléphonie Iridium. Si vous essayez de faire un appel d’urgence en mode PTT, vous serez invité à passer en mode téléphone pour recomposer et faites votre appel. De plus, si vous essayez de lancer un SOS en mode PTT, vous serez invité...
  • Page 26 L’identification de la position de l’appelant n’est pas automatiquement transmise sur le système Iridium. Iridium ne peut garantir la disponibilité en tout temps du réseau; parfois, le réseau peut ne pas être disponible en raison de la disponibilité des satellites, du terrain, des conditions météorologiques, ou d’autres conditions qui peuvent empêcher d’acheminer un appel d’urgence.
  • Page 27 Respectez les instructions suivantes lorsque vous utilisez votre téléphone en conduisant. • Portez votre attention sur la route; conduire en toute sécurité doit être votre principal souci. • Utilisez le mode téléphone mains libres, s’il est pris en charge. Iridium Extreme® PTT User Manual...
  • Page 28 S’ils ne sont pas protégés adéquatement, la plupart des appareils électroniques sont sujets aux interférences par l’énergie électromagnétique HF de sources externes. Dans certains cas, votre téléphone sans fil peut causer des interférences avec d’autres appareils. Iridium Extreme® PTT User Manual...
  • Page 29 Si vous portez votre téléphone satellite sur vous, utilisez un boîtier en cuir Iridium. Consultez la page www.iridium.com. L’utilisation d’accessoires autres que ceux d’Iridium peut faire en sorte que votre téléphone stellite dépasse les lignes directrices sur l’exposition à l’énergie électromagnétique HF.
  • Page 30 Si vous utilisez un autre appareil médical personnel, contactez le fabricant de votre appareil pour vérifier s’il est équipé d’un système antibrouillage de l’énergie HF externe. Votre médecin pourra vous aider à déterminer la compatibilité avec votre appareil médical. Iridium Extreme® PTT User Manual...
  • Page 31 En cas de mauvaise installation du matériel sans fil embarqué, le déclenchement du coussin de sécurité gonflable peut occasionner des blessures graves. Iridium Extreme® PTT User Manual...
  • Page 32 • Évitez de monter le volume pour bloquer les bruits ambiants. • Baissez le volume si vous ne pouvez pas entendre les personnes qui parlent autour de vous. • Le non-respect de ces consignes pourrait entraîner des blessures graves, voire la mort. Iridium Extreme® PTT User Manual...
  • Page 33 épaules, votre cou ou d’autres parties de votre corps. Si vous continuez à ressentir un tel malaise pendant l’utilisation du téléphone ou après son utilisation, arrêtez et consultez un médecin. Iridium Extreme® PTT User Manual...
  • Page 34 Iridium Extreme® PTT User Manual...

  • Page 35: 2: Initial Set-Up

    2: Initial Set-Up This section provides an overview of the Iridium Extreme® PTT device. You will discover all the features and components that you need to set up and start to use your new device. Iridium Extreme® PTT User Manual...

  • Page 36: Device Overview

    Device Overview The Iridium Extreme® PTT device provides an easy to use communication tool that fits securely in your hand and is designed for extended reliability. Front View Receiver (Earpiece) Speaker On/Off Button Programmable SOS Button (Phone Mode only) SOS Indicator...
  • Page 37 Side Views Convenience Key (Phone Mode) PTT Button (PTT Mode) Volume Up Key Volume Down Key Front Headset Jack Accessory Connector Accessory Connector Iridium Extreme® PTT User Manual...
  • Page 38 Back View Speaker Battery D-Ring Battery Pack Iridium Extreme® PTT User Manual...

  • Page 39: Sim Card

    SIM Card In order to use the Iridium Extreme® PTT device for Phone Mode services, you will need a Subscriber Identity Module (SIM) card from your service provider. The SIM card contains your service details and memory for storing phone book entries and messages. A SIM card is not required to operate within the PTT Mode of the handset (although activation of PTT services is required).
  • Page 40 In the event you need to remove your SIM card, first unlock the SIM door, then swing out the SIM door and slide the SIM card out of the slot. After SIM card is removed, close SIM door and lock into place. Iridium Extreme® PTT User Manual...

  • Page 41: Battery

    Battery Included with your Iridium Extreme® PTT device is a rechargeable lithium- ion battery. Refer to Section 1 “Introduction and Important Safety Information” on proper use, disposal of batteries, and other information. Battery Charging Batteries may be charged and discharged many times, but eventually they wear out.
  • Page 42 Note: Ensure that the battery is securely installed. Failure Battery Pack Pegs to do so could result in full or intermittent power disruption to the unit. Iridium Extreme® PTT User Manual...
  • Page 43 Accessories for battery charging Included with the Iridium Extreme® PTT device are two adapters. These adapters attach to the bottom of your phone and are required for charging, connecting the USB data cable, or using the external antenna. These adapters are designed to provide a robust and flexible approach to using external accessories with the Iridium Extreme®...
  • Page 44 • Prior to installation, open your phone’s accessory connector cover move it to the back of your phone, securing it to the rear retaining features. • Select the appropriate adapter and orient it so the Iridium brand is facing forward. Then press the adapter up until the side clasps are locked into place.
  • Page 45 • Can be used to power the phone when the battery is depleted. • The battery must be installed when using the charger to power the phone. • Includes five international plug adapters for use in many countries around the world. Accessory Adapter Iridium Extreme® PTT User Manual...
  • Page 46 Note: Calls can still be made or received while the battery is charging; however the battery charges faster if the phone is turned off. When the Iridium Extreme® PTT device is not in use the battery takes approximately 4 hours to fully charge.
  • Page 47 Important: The battery should only be charged in environments between 0°C (32°F) to 45°C (113°F). You must wait a minimum of 5 seconds before powering on the Iridium Extreme® PTT device after you have disconnected from the charger. The battery should not be allowed to discharge fully.

  • Page 48: Additional Included Accessories

    The convenient headset provides both an earphone and microphone in one small piece for simple hands-free and private telephone conversations and PTT sessions. The headset plugs directly into the jack on the right side of your phone. Headset Port Iridium Extreme® PTT User Manual...
  • Page 49 For the best performance, place the external antenna on a metal surface (e.g., vehicle roof ) for a proper grounding plane. The external antenna included with your device is also designed to operate on non-metallic surfaces. Iridium Extreme® PTT User Manual...
  • Page 50 Velcro is provided for this purpose. Use caution to ensure that your SOS cap cover and audio accessory cover are fully installed while inserting the phone through the case to avoid damage to these two connector covers. Iridium Extreme® PTT User Manual...
  • Page 51 USB Data Cable The USB data cable allows you to connect your Iridium Extreme® PTT device to a laptop in order to provide a data connection for email or web access. Software and installation instructions are provided on your included CD-ROM or can be obtained from your service provider. The USB Data Cable plugs directly into the mini-USB connector on the left side of your Accessory Adapter.

  • Page 52: Start-Up Procedure

    SOS button as a non-functioning button to avoid future confusion. For your safety and the safety of any users of your Iridium Extreme® PTT device, you must review and ensure that any users are provided with these important safety instructions regarding the use of this device and the SOS button.

  • Page 53: Power On Message

    Searching for The phone is attempting to establish Iridium... communications with the satellite network. This message appears while your phone searches for a network connection. In PTT Mode, devices without PTT provisioning will display this message. Iridium Extreme® PTT User Manual...
  • Page 54 SOS button. Additional details are included in a GEOS Service GEOS brochure in the packaging with your phone or on Iridium.com. If you decide to use the service by selecting “Use”, you will then be prompted to confirm you have registered at www.geosalliance.com/iridium from your home...
  • Page 55 Menu screen you will be able to navigate within Phone Menu following instructions outlined in Section 3 or switch to PTT Mode following the instructions outlined in Section 4. Help may be accessed from the main screen by pressing the right soft key. Iridium Extreme® PTT User Manual...
  • Page 56 Iridium Extreme® PTT User Manual...

  • Page 57: 3: Phone Mode Operation

    • Location – using SMS • SOS – using phone calling and SMS To access Phone Mode, power on your Iridium Extreme® PTT device by pressing the power button. The first time you use your Iridium Extreme® PTT device, it will power on in Phone Mode. If you have used the device previously and the phone launches into PTT Mode, you will need to press Menu and then press the left soft key to Switch to Phone.

  • Page 58: Indicators

    Wearing the phone on the body can interfere with proper phone operation, since the antenna requires a clear unobstructed view of the sky to access the Iridium satellite network. 7. Once you complete your call and are finished with the phone, return the antenna to the center upright position and gently retract the antenna before carrying or storing the phone between uses.
  • Page 59 Indicates an SMS message Registered 16:28 14-May-14 has been received Menu Help 16:28 14-May-14 Indicates SOS button and Registered Menu Help Emergency Mode has been activated 16:28 14-May-14 Registered Menu Help 16:28 14-May-14 Menu Help Iridium Extreme® PTT User Manual...

  • Page 60: Placing A Call

    + for the international access code so the only numbers that are required to add are the country code and phone number. Note: All Iridium subscriber numbers begin with country code of 8816 unless an alternative access number has been issued by your service provider.
  • Page 61 Iridium Extreme® PTT device. Calling 3. Calling followed +12155551212 by the number you dialed appears in the display. Options Speaker Iridium Extreme® PTT User Manual...
  • Page 62 Note: If you have disabled the timer, the word “Connected” is displayed. 00:00:01 4. A timer keeps track of the duration of each call. Select Back End a Call Call ended Press the red key. Iridium Extreme® PTT User Manual...

  • Page 63: Receiving A Call

    2. A valid SIM card must be inserted. 3. The phone must be connected with the network. There are two scenarios for receiving calls depending on the antenna position: 1. Antenna extended. 2. Antenna stowed; that is, in the down position. Iridium Extreme® PTT User Manual...
  • Page 64 Receiving a call with the Antenna Extended 1. Phone sounds or vibrates. 2. Status indicator alternates red and green. 3. Phone displays Incoming Call incoming call. Options Left Soft Key Red Key Green Key Iridium Extreme® PTT User Manual...
  • Page 65 Connected 3. Phone displays Connected. Options If the call does not connect properly, the following message appears: Message Directive Call Failed The antenna is not properly positioned or the network signal is not strong enough. Iridium Extreme® PTT User Manual...
  • Page 66 2-way left soft key, then Navi-key select Accept or Reject using the Green key 2-way Navi-key and making selection with the left soft key or directly answer by pressing the green key. Iridium Extreme® PTT User Manual...
  • Page 67 5. The phone displays Connected Connected. Mute Speaker If the call does not connect properly, the following message appears: Message Directive Call Failed The antenna is not properly positioned or the network signal is not strong enough. Iridium Extreme® PTT User Manual...

  • Page 68: Muting A Call

    Navi-key to scroll down and select “Speaker” using the left soft key for “Select”. To switch back to earpiece, press the left soft key again and scroll to “Ear” and press the left soft key to “Select”. Iridium Extreme® PTT User Manual...

  • Page 69: Speaker Volume

    As you press the keys, you hear the new volume level. The bar graph on the display indicates the volume level; the higher the graph, the louder the volume. Bar graph for speaker volume Upper volume control increases speaker volume Volume Lower volume control decreases Back speaker volume Iridium Extreme® PTT User Manual...

  • Page 70: Ringer Volume

    • As you press the keys, you hear the new volume level. The bar graph on the display indicates the volume level; the higher the graph, the louder the volume. Bar graph for ringer volume Upper volume control increases ringer volume Volume Lower volume control decreases Back ringer volume Iridium Extreme® PTT User Manual...

  • Page 71: Unanswered Calls

    To prevent accidental phone usage you can lock the keypad by: 1. Press the left soft key, labeled Menu. 2. Press the * key to lock the keypad. A message will flash indicating the keypad is locked. Iridium Extreme® PTT User Manual...
  • Page 72 Keypad Unlocked Unlock Help 1. Press the left soft key labeled Unlock. 2. Press the * key. A message flashes indicating the keypad is unlocked, and the lock symbol no longer appears on the main screen. Iridium Extreme® PTT User Manual...

  • Page 73: Traditional Text Entry

    Multi-tap is the default setting for text entry. For Example: Use the number 2 key for letters A, B, and C. Press 1 time for A Press 2 times for B Press 3 times for C Iridium Extreme® PTT User Manual...
  • Page 74 # key until the digit entry mode “123” is shown in the upper left corner of the screen. Then simply enter the digits. When done, press the # key again to return to letter entry mode. Iridium Extreme® PTT User Manual...
  • Page 75 “ è ó ʻ listing. ė ö ˜ à ê ù < á ë ú Select Back Press the left soft key labeled Select. 2-way Navi-key Press the * key to open the symbols menu. Iridium Extreme® PTT User Manual...
  • Page 76 Enter the desired digits. Options Clear 6. When done entering digits, you need to change back to letter entering mode. Press the left soft key labeled Options. Iridium Extreme® PTT User Manual...
  • Page 77 Options Clear Predictive Text Entry Predictive text is implemented on the Iridium Extreme® PTT device and affects the following areas: • Creating an SMS/Email • Adding Notes to an existing Phonebook entry • Entering the Name field for a Phonebook entry (LetterWise only) Predictive text is not set on a new phone by default, it must be enabled.
  • Page 78 Special character entry has the following modes: • Punctuation (#?@) for entry of punctuation and special symbols • Digit (123) for entry of numbers Iridium Extreme® PTT User Manual...
  • Page 79 • Multi-tap (abc) traditional text entry (non-predictive) The appropriate text entry mode can be selected by pressing the Convenience key on the side of the Iridium Extreme® PTT device. The active text entry mode will be displayed on the screen as indicated in the illustrations on the following page.
  • Page 80 WordWise predictive 1000 Options Clear LetterWise predictive 1000 Options Clear Convenience Punctuation 1000 Options Clear Digit 1000 Options Clear Iridium Extreme® PTT User Manual...
  • Page 81 Example: Entering “don’t” Options Clear 1. Press key 3. Desired letter did not come up. Options Clear  2. Press Next key ( ) for desired letter. Proceed to next letter of the word. Desired letter appears. Iridium Extreme® PTT User Manual...
  • Page 82 Clear 3. Press key 6. Desired letter appears. Options Clear 4. Press key 6 again. Desired letter appears. don’ Options Clear 5. Press key 5 for apostrophe. Apostrophe is predicted along with letters in English. Iridium Extreme® PTT User Manual...
  • Page 83 Next key ( ). As an alternative, you may also access Options using the left soft key to select “Insert symbol” or “Enter digits” during WordWise use. This also applies to LetterWise use. Iridium Extreme® PTT User Manual...
  • Page 84 “c & d”. The word “see” comes up which is more common than “red”. The underline indicates there are Options Clear other words to choose from.  3. Press Next Key ( The word “red” appears. Iridium Extreme® PTT User Manual...
  • Page 85 If there is more than one symbol on a key, press the Next key (  ) to get the others. English/French/Spanish* . , @ % $ £ - + = “ ( < : ; & ) > * Spanish includes inverted versions of ! and ?. Iridium Extreme® PTT User Manual...

  • Page 86: Using The Phonebooks

    155 entries Fixed Dial Numbers No entries 40 entries Phone Number Digits Name Characters Locating My Phonebook Registered Starting from the Main Screen: 16:28 14-May-14 Menu Help 1. Press the left soft key, labeled Menu. Iridium Extreme® PTT User Manual...
  • Page 87 • Create and send a text message (SMS). Edit Delete • Edit an entry • Delete an entry • Add an entry Select Back • Check the memory status of your Phonebook • Add notes regarding entries Iridium Extreme® PTT User Manual...
  • Page 88 Bob Smith Call Edit Delete 4. Use the 2-way Navi-key until the New option is highlighted. Select Back 5. Press the left soft key, labeled Select to proceed. Iridium Extreme® PTT User Manual...
  • Page 89 +9373321234 information into the fields. +123456789 +1112223333 msmith@aol.com Save Clear Note: While entering or editing contact information the side volume keys allow you to move backwards and forwards without deleting. Iridium Extreme® PTT User Manual...
  • Page 90 Save. Success 9. A message briefly appears Entry Added Successfully to indicate the contact was entered successfully. The screen reverts to the main Phonebook menu. Press the red key to return to the Main Screen. Iridium Extreme® PTT User Manual...
  • Page 91 Davy Jones Eddy Fisher order. Options Back My Phonebook 3. If there are no entries Empty (Empty) is displayed. See “Add a New Entry to My Phonebook” on p. 82. Options Back Iridium Extreme® PTT User Manual...
  • Page 92 Davy Jones Eddy Fisher is located. Select Back 3. With the entry highlighted, press the left soft key labeled Options. Note: You can also press the green key as a short-cut to calling an entry. Iridium Extreme® PTT User Manual...
  • Page 93 Deploy the antenna and make sure it is oriented toward the to extend the antenna. Calling 6. Calling followed by the number you +12155551212 dialed is displayed. The call is then connected. Options Speaker Iridium Extreme® PTT User Manual...
  • Page 94 5. Press the left soft key, labeled Select. Note: If an entry has more than one number, for example, Home, Work and Mobile, then all numbers are displayed. Using the 2-way Navi-key, highlight the number to be called and press Select. Iridium Extreme® PTT User Manual...
  • Page 95 • Save as a draft to send later. • Switch between wordwise and multi-tap entry. • Exit the messaging menu and return to main menu. Note: Use the Back option with the right soft key to return to message editing. Iridium Extreme® PTT User Manual...
  • Page 96 3. If no recipient is listed, you need to add a recipient as covered on this page in Adding an SMS Message Recipient. 4. Press the left soft key “Send” to send your message to your recipient. Iridium Extreme® PTT User Manual...
  • Page 97 Send 4. Once you are satisfied with the recipient(s) press left soft key, labeled Send. Note: Repeat this procedure if you want to send the same message to more than one contact at a time. Iridium Extreme® PTT User Manual...
  • Page 98 3. Press the left soft key, labeled Options. Phonebook Call 4. Use the 2-way Navi-key until the Edit Delete Edit option is highlighted. Select Back 5. Press the left soft key, labeled Select to proceed. Iridium Extreme® PTT User Manual...
  • Page 99 Save. Success 8. A message briefly appears Entry updated to indicate the entry was updated. The screen then returns to the main Phonebook menu. 9. Press the red key to return to the Main Screen. Iridium Extreme® PTT User Manual...
  • Page 100 2. The Phonebook is displayed. Bob Smith Cat Steven Use the 2-way Navi-key to Davy Jones Eddy Fisher scroll until the desired entry is highlighted. Options Back 3. Press the left soft key, labeled Options. Iridium Extreme® PTT User Manual...
  • Page 101 Success 7. A message briefly appears Entry Bob Smith deleted to indicate the entry was deleted. The main Phonebook menu then appears. 8. Press the red key to return to the Main Screen. Iridium Extreme® PTT User Manual...
  • Page 102 3. Press the left soft key, labeled Options. Bob Smith Memory Status Notes 4. Use the 2-way Navi-key until Memory Status is highlighted. Select Back 5. Press the left soft key, labeled Select to proceed. Iridium Extreme® PTT User Manual...
  • Page 103 2. The Phonebook is displayed. Bob Smith Cat Steven Davy Jones Use the 2-way Navi-key to Eddy Fisher scroll until the desired entry is highlighted. Options Back 3. Press the left soft key, labeled Options. Iridium Extreme® PTT User Manual...
  • Page 104 When the Phonebook is restricted, My Phonebook and SIM Phonebook do not appear. The main menu displays Fixed Phonebook only. The Fixed Phonebook cannot be edited as it is programmed directly to the SIM card using a PC software program. Iridium Extreme® PTT User Manual...

  • Page 105: Using The Messages Menu

    • Create messages. Drafts Outbox • Read, reply, delete, call and forward Settings messages. • Edit stored messages and send. Select Back • Enter service center number, set expiry period and enable or disable delivery reports. Iridium Extreme® PTT User Manual...
  • Page 106 Insert symbol Enter digits highlighted. If not then use the Save as draft Exit 2-way Navi-key to scroll until it is highlighted. Select Back 6. Press the left soft key, labeled Select to send the message. Iridium Extreme® PTT User Manual...
  • Page 107 11. In the Number field, after the prefix of 00 or +, enter *2. Clear 12. Press the left soft key, labeled OK. Send To Number: Send 13. Press the left soft key, labeled Send to send the message. Iridium Extreme® PTT User Manual...
  • Page 108 Insert symbol highlighted. If not then use the Enter digits Save as draft Exit 2-way Navi-key to scroll until it is highlighted. Select Back 7. Press the left soft key, labeled Select to send the message. Iridium Extreme® PTT User Manual...
  • Page 109 13. The Select Recipient screen appears with the recipient’s Send To name highlighted. To add another New Recipient Ada Adams Bob Smith recipient, use the 2-way Navi-key Cat Stevens to highlight the next recipient and repeat step 10. Send Iridium Extreme® PTT User Manual...
  • Page 110 SMS message with 320 characters may be billed as two standard SMS messages. Contact your service provider for additional information. Your personal mailbox works with Call Forwarding. For more information see “Forward a Received Message” on p. 107. Iridium Extreme® PTT User Manual...
  • Page 111 1. Press the left soft key, labeled Select. Messages Create Message 2. Use the 2-way Navi-key to scroll until Inbox (1 unread) Drafts Inbox is highlighted. Outbox Settings Select Back 3. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 112 1. Press the left soft key, labeled Options Back Options. Message 2. Use the 2-way Navi-key to scroll Reply Forward Call until Reply is highlighted. Delete Delete All Select Back 3. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 113 Note: If the sender’s phone number is not part of your phonebook, select New Recipient to add the number. Forward a Received Message Message While reading the Message: Text message will appear here. 1. Press the left soft key, labeled Options. Options Back Iridium Extreme® PTT User Manual...
  • Page 114 9. Use the 2-way Navi-key until Enter Number Quick GPS List Ada Adams the desired recipient from your Bob Smith Cat Steven phonebook is highlighted. Options Back 10. Press the left soft key, labeled Options. Iridium Extreme® PTT User Manual...
  • Page 115 8. Send 14. Once all recipients have been selected, press the right soft key, labeled Back. Send To New Recipient Ada Adams Bob Smith Cat Stevens Send 15. Press the left soft key, labeled Send. Iridium Extreme® PTT User Manual...
  • Page 116 3. Press the left soft key, labeled Select. Delete a Message Menu Switch to PTT My Phonebook Start at the Main Menu with Messages SIM Phonebook Messages highlighted: Voicemail Select Back 1. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 117 7. Use the 2-way Navi-key to scroll until Delete is highlighted. To delete all Message Reply messages highlight Delete All. Forward Call Save number Delete Delete All Select Back 8. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 118 1. Press the left soft key, labeled Select. Messages Create Message Inbox (1 unread) 2. Use the 2-way Navi-key to Drafts Outbox scroll until the Drafts option is Settings highlighted. Select Back 3. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 119 Insert symbol highlighted. If not use the 2-way Enter digits Save as draft Exit Navi-key to scroll until Send is highlighted. Select Back 9. Press the left soft key, labeled Select to send the message. Iridium Extreme® PTT User Manual...
  • Page 120 16. As you select recipients, they will be listed on the Send To Send To screen. Continue to add recipients New Recipient Ada Adams as outlined in step 10 until all Bob Smith Cat Stevens recipients have been added. Send Iridium Extreme® PTT User Manual...
  • Page 121 Use this capability to enter the number for the service center to which you wish to forward your outgoing messages. The Iridium Extreme® PTT device will use Iridium’s Service Center number by default if none has been explicitly configured. Menu...
  • Page 122 Use this capability to specify the amount of time your un-delivered messages should wait before auto-expiring. Menu Switch to PTT My Phonebook Start at the Main Menu with Messages SIM Phonebook Messages highlighted: Voicemail Select Back 1. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 123 6. Use the 2-way Navi-key to scroll 4 hours 1 day until the desired period of time is 2 days 1 week highlighted. Select Back 7. Press the left soft key, labeled Select. The screen returns to the Settings menu. Iridium Extreme® PTT User Manual...

  • Page 124: Settings Menu

    5. Press the left soft key, labeled Select. Delivery Report 6. Use the 2-way Navi-key to turn the Delivery Report OFF or ON. Select Back 7. Press the left soft key, labeled Select. The screen returns to the Settings menu. Iridium Extreme® PTT User Manual...

  • Page 125: Using The Voicemail Menu

    You can do the following functions using the Voicemail menu: • Listen to your voicemail. Voicemail Call Voicemail • Reply to a voicemail. Voicemail Settings • Store voicemail numbers. • Access and configure your voicemail. Select Back Iridium Extreme® PTT User Manual...
  • Page 126 2. Press the left soft key, labeled Select. Voicemail 3. Call Voicemail is highlighted. Call Voicemail Voicemail Settings Select Back 4. Press the left soft key, labeled Select. Follow the audio prompts for additional capabilities. Iridium Extreme® PTT User Manual...
  • Page 127 Voicemail Settings option is highlighted. Select Back 4. Press the left soft key, labeled Select. Voicemail Settings 5. The Number option is highlighted. Number Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 128 10. Press the red key to exit to the Main Screen. One-Touch Access to Voicemail The Iridium Extreme® PTT device provides one-touch access to voicemail for ease of use. To use this feature, press and hold the 1 key for 2 seconds in order to prompt a call to voicemail without having to navigate through the phone menu.

  • Page 129: Using The Data Modem Menu

    Using the Data Modem Menu In order to use the Iridium Extreme® PTT device as a modem for your computer, you must first follow the installation instructions provided on the CD-ROM included with your phone or use the instructions provided by your service provider.

  • Page 130: Using The Call History Menu

    Cancel If you need to remove the battery, first disconnect from the USB cable, power down the Iridium Extreme® PTT device and then remove the battery. Using the Call History Menu Locating the Call History Menu Starting from the Main Screen:...
  • Page 131 2. Press the left soft key, labeled Select. Call History 3. The Call History menu is displayed Call Log Call Meters with Call Log highlighted. Select Back 4. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 132 +321225551212 This feature may be enabled Select Back in the future. Press the right soft key labeled Back to go back one level, or the red key to return the Main Screen. Iridium Extreme® PTT User Manual...
  • Page 133 4. Press the left soft key, labeled Select. Call Log Received Calls Missed Calls 5. Using the 2-way Navi-key Dialed Calls scroll until Missed Calls is highlighted. Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 134 Starting from the Main Menu: Menu 1. Use the 2-way Navi-key to Call History Setup Security scroll until Call History is Help highlighted. Select Back 2. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 135 +011225551212 +881425551212 last ten calls. +881765551212 +991445551212 +651225551212 +331225551212 +321225551212 Select Back Press the right soft key labeled Back to go back one level, or the red key to return the Main Screen. Iridium Extreme® PTT User Manual...
  • Page 136 5. Last call time is highlighted. If not, Total call time Reset call timer use the 2-way Navi-key until it is. Lifetime call time In-call display Audible timers Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 137 2. Press the left soft key, labeled Select. Call History Call Log 3. Use the 2-way Navi-key to Call Meters scroll until Call Meters is highlighted. Select Back 4. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 138 Starting from the Main Menu: Menu Data Modem 1. Use the 2-way Navi-key to Call History Setup scroll until Call History is Security Help highlighted. Select Back 2. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 139 The screen displays: Reset call timers? Reset call timers? 7. Press the left soft key for Yes or the right soft key for No. Reset 8. If you press Yes, the display reads Call Call meters reset. meters reset. Iridium Extreme® PTT User Manual...
  • Page 140 2. Press the left soft key, labeled Select. Call History Call Log 3. Use the 2-way Navi-key to Call Meters scroll until Call Meters is highlighted. Select Back 4. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 141 Main Screen. Note: The Lifetime timer cannot be reset. Showing the In-call Display This capability enables or disables the call timer that displays the amount of time that has passed since placing a specific call. Iridium Extreme® PTT User Manual...
  • Page 142 Select Back 6. Press the left soft key, labeled Select. Call Timer 7. Use the 2-way Navi-key to scroll to Enabled Disabled Enabled or Disabled. Select Back 8. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 143 Total call time Reset call meter. . . 5. Use the 2-way Navi-key to scroll until Lifetime call time In-call display Audible timers Audible timers is highlighted. Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 144 10. Press the left soft key, labeled Select. Message Message Deleted Select Back 11. Press the right soft key labeled Back to return to the previous menu. 12. Press the red key to return to the Main Screen. Iridium Extreme® PTT User Manual...
  • Page 145 Total call time Reset call meter. . . 5. Use the 2-way Navi-key to scroll until Lifetime call time In-call display Audible timers is highlighted. Audible timers Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 146 10. Press the left soft key, labeled Select. Message Message Deleted Select Back 11. Press the right soft key labeled Back to return to the previous menu. 12. Press the red key to return to the Main Screen. Iridium Extreme® PTT User Manual...

  • Page 147: Using The Setup Menu

    Setup 2-way Navi-key to scroll until Setup Security Help is highlighted. Select Back 3. Press the left soft key, labeled Select. Note: All instructions for the Setup menu start from the Main Menu as shown. Iridium Extreme® PTT User Manual...
  • Page 148 • Reset phone settings to default. Select Back Note: The Setup menu consists of three screens. Scroll past the Language option using the 2-way Navi-key for more options. Note: Location options will be covered in more detail in Section 3. Iridium Extreme® PTT User Manual...
  • Page 149 Call Barring Fixed Dialing Select Back 6. Press the left soft key labeled Select to return to the previous menu. 7. Press the red key to return to the Main Screen. Iridium Extreme® PTT User Manual...
  • Page 150 Setup Location Options Call Options 3. Use the 2-way Navi-key to Volume and Tones Time and Date scroll until Volumes and Language Tones is highlighted. Select Back 4. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 151 Select Back Back to return to the Volume and Tones Menu. 9. You may exit the settings and return to the Main Screen by selecting the red key. Iridium Extreme® PTT User Manual...
  • Page 152 Select. Volumes and Tones Ringer Volume Speaker Volume 5. Use the 2-way Navi-key to Ring Tone Alert Tone scroll to Speaker Volume. Keypad Tone Vibrate Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 153 Starting from the Main Menu: Menu Data Modem 1. Use the 2-way Navi-key Call History Setup to scroll until Setup is Security Help highlighted. Select Back 2. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 154 Message Deleted pressing the right soft key labeled Back to return to the Volume and Tones Menu. Select Back 9. You may exit the settings and return to the Main Screen by selecting the red key. Iridium Extreme® PTT User Manual...
  • Page 155 Volumes and Tones Ringer Volume 5. Use the 2-way Navi-key Speaker Volume Ring Tone to scroll until Alert Tone is Alert Tone Keypad Tone highlighted. Vibrate Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 156 DTMF tones or no tones when the keypad is pressed. Starting from the Main Menu: Menu Data Modem 1. Use the 2-way Navi-key Call History Setup to scroll until Setup is Security Help highlighted. Select Back 2. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 157 Message Deleted labeled Back to return to the Volume and Tones Menu. Select Back 9. You may exit the settings and return to the Main Screen by selecting the red key. Iridium Extreme® PTT User Manual...
  • Page 158 Volumes and Tones Ringer Volume 5. Use the 2-way Navi-key Speaker Volume Ring Tone to scroll until Vibrate is Alert Tone Keypad Tone highlighted. Vibrate Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 159 Starting from the Main Menu: Menu Data Modem 1. Use the 2-way Navi-key Call History Setup to scroll until Setup is Security Help highlighted. Select Back 2. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 160 Select to confirm or press the right soft key labeled Back to return to the Time and Date Menu. 9. You may exit the settings and return to the Main Screen by selecting the red key. Iridium Extreme® PTT User Manual...
  • Page 161 4. Press the left soft key, labeled Select. Time and Date Select time zone 5. Use the 2-way Navi-key to scroll Time format Date format until Time format is highlighted. Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 162 Setup Location Options Call Options Volume and Tones 3. Use the 2-way Navi-key to Time and Date Language scroll until Time and Date is highlighted. Select Back 4. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 163 Starting from the Main Menu: Menu Data Modem Call History 1. Use the 2-way Navi-key Setup Security to scroll until Setup is Help highlighted. Select Back 2. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 164 6. Press the left soft key and then press it a second time. The English option is at the top so press the left soft key a final time to confirm change back to English. Iridium Extreme® PTT User Manual...
  • Page 165 Select to confirm selections or press the right Select Back soft key labeled Back to return to the Setup Menu. 7. You may exit the settings and return to the Main Screen by selecting the red key. Iridium Extreme® PTT User Manual...
  • Page 166 OK to confirm Back selections or press the right soft key labeled Back to return to the Setup Menu. 7. You may exit the settings and return to the Main Screen by selecting the red key. Iridium Extreme® PTT User Manual...
  • Page 167 Key Setup is highlighted. Phone Information Select Back 4. Press the left soft key, labeled Select. Setup 5. Convenience Key is highlighted. Convenience Key Right Soft Key Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 168 2. Press the left soft key, labeled Select. Setup Backlight Contrast Key Setup 3. Use the 2-way Navi-key Number Entry Phone Information to scroll until Key Setup is highlighted. Select Back 4. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 169 Select to confirm selections or press the right soft key labeled Back to return to the Setup Menu. 9. You may exit the settings and return to the Main Screen by selecting the red key. Iridium Extreme® PTT User Manual...
  • Page 170 Select to confirm selections or press the right soft key labeled Back to return to the Setup Menu. 7. You may exit the settings and return to the Main Screen by selecting the red key. Iridium Extreme® PTT User Manual...
  • Page 171 View Phone Information This capability allows you to view technical information about the Iridium Extreme® PTT device Satellite Phone software, hardware versions and the IMEI number. Starting from the Main Menu: Menu Data Modem 1. Use the 2-way Navi-key Call History...
  • Page 172 2. Press the left soft key, labeled Select. 3. Use the 2-way Navi-key to Setup scroll past the Key Setup Reset to defaults option until Reset to defaults is highlighted. Select Back 4. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 173 5. Press the left soft key, labeled Yes. Reset 6. A message appears briefly Phone settings reset indicating the phone settings have been reset. 7. Press the red key to return to the Main Screen. Iridium Extreme® PTT User Manual...

  • Page 174: Gps And Location-Based Services

    There are four main components to set up and use these features: • Location Options Setup Menu: located in the Iridium Extreme® PTT device main menu in the setup section, Location Options is where you customize your GPS, emergency, message, and format options.
  • Page 175 • Message Options: Set up the recipient and frequency of your auto GPS location update message. • Format: Configure the format of GPS location information. • Current Location: View and update your current GPS location. Iridium Extreme® PTT User Manual...
  • Page 176 Back 4. Within the Location Options menu Location Options GPS Options are GPS Options, Portal Options, Portal Options Emergency Options Message Options Emergency Options, Message Format Current Location Options, Format, and Current Select Back Location. Iridium Extreme® PTT User Manual...
  • Page 177 GPS Options Emergency Options Message Options can lock GPS settings, set the GPS Format Current Location refresh frequency rate, and turn GPS On or Off. Select Back 1. Press the left soft key, labeled Select Iridium Extreme® PTT User Manual...
  • Page 178 5 minutes, or every 10 minutes. 10 minutes To modify this setting, use the 2-way Navi-key to scroll and highlight the Select Back desired update rate. 2. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...

  • Page 179: Setting Emergency Options

    SOS button cover, press the red key located underneath, and initiate a message and/or phone call to your dedicated contact. This contact could be a family member, commercial safety service, safety office, or Iridium- supported public emergency number (e.g., 911 in U.S. or 000 in Australia).
  • Page 180 GEOS MEDIVAC™ Plus are services offered and provided exclusively by GEOS, and not by Iridium which is a separate, unrelated company. Neither GEOS nor Iridium will pay the cost of rescue efforts in the event that the Iridium Extreme® PTT device user fails to register and contract separately with GEOS for SAR and/or GEOS MEDIVAC™.
  • Page 181 Select Back Within the Emergency Options menu Emergency Options are Emergency Mode, Emergency Emergency Mode Emergency Actions Actions, Emergency Beep, Message Emergency Beep Message Recipient Recipient, Call Recipient, and GEOS Call Recipient Service. Select Back Iridium Extreme® PTT User Manual...
  • Page 182 Once in Emergency Mode the phone will initiate a call and/or message to your designated contacts. The phone Registered call (if programmed) will occur in speakerPhone Mode and will retry if 09-JUL-14 15:40 Menu the attempted call is unsuccessful. Cancel Iridium Extreme® PTT User Manual...
  • Page 183 If number of GPS satellites is generally greater than 4, the accuracy is generally good. If “NO GPS AVAIL” is displayed, the location provided is an approximate location based on Iridium location that is only an approximate location within an accuracy of ~90 miles.
  • Page 184 You will be provided the option prior to this screen to immediately turn off the phone or you can wait for confirmation that the power down notification was successfully sent and then the phone will automatically power down. Iridium Extreme® PTT User Manual...
  • Page 185 Enabled and press the Left Soft Key, labeled Select. Note: If the GPS Settings Lock is enabled, you will be prompted for the GPS Settings Lock PIN when attempting to change this setting. Iridium Extreme® PTT User Manual...
  • Page 186 Edit or Delete. Press the Left Soft Key, labeled Options. Options Back Note: If the GPS Settings Lock is enabled, you will be prompted for the GPS Settings Lock PIN when attempting to change this setting. Iridium Extreme® PTT User Manual...
  • Page 187 • To Enter Number, press the Left Soft Key, labeled Select, and enter the number. • To Enter Email, use the 2-way Navi-key to highlight Enter Email and press the Left Soft Key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 188 Additionally you may configure the Call Recipient to contact GEOS service by selecting “GEOS Service”, the last menu option under “Emergency Options”. Details on GEOS Service can be found in your phone box or on Iridium.com. To program a new Call Recipient, type Call Recipient in the desired number and press the left soft key, labeled Save.
  • Page 189 (e.g., +12125551212) or emergency number (e.g., +911). Note that Iridium only supports 911 in the US and 000 in Australia and these numbers will not work in other geographies. Message Options In the Location Options menu, Message Options will allow you to program settings for Regular Updates of location and also use of a Quick GPS list feature.
  • Page 190 • To select an existing address, use the 2-way Navi-key to highlight the My Phonebook listing and press the left soft key, labeled Select. Once the My Phonebook listing is selected, you will need to use the 2-way Navi-key Iridium Extreme® PTT User Manual...
  • Page 191 The format of your GPS location information can be modified. Location Options GPS Options Emergency Options The handset provides two (2) options Message Options Format for position: Current Location • Decimal degrees Select Back • Deg Min Sec (default setting) Iridium Extreme® PTT User Manual...

  • Page 192: Position Format

    Select. Altitude Format From the Format screen, to modify the Format Position setting for Altitude format, press the Altitude left soft key, labeled Select. Select Back Iridium Extreme® PTT User Manual...
  • Page 193 If location is available, it will be displayed in the configured format including Latitude, Longitude, Altitude, Age of fix, and number of GPS satellites. The screen will update automatically as frequently as your designated setting. Iridium Extreme® PTT User Manual...
  • Page 194 These recipients will be able to click this Web link that is viewable on a smartphone, tablet, or computer’s Internet browser. This information is not stored by Iridium and is subject to Iridium’s Privacy Policy posted on Iridium.com and Google Maps’s Terms of Service posted on the mapping page.

  • Page 195: Using The Security Menu

    1. Press the left soft key, labeled Menu. Menu Data Modem 2. The Main Menu is displayed. Use Call History Setup the 2-way Navi-key to scroll until Security Help Security is highlighted. Select Back 3. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 196 Security 3. The Phone lock option is Phone lock Sim lock highlighted. If not, use the 2-way Change PINs Navi-key to scroll until it is. Select Back 4. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 197 Clear 8. Press the left soft key, labeled Select. The Phone lock capability takes effect when you turn OFF your Iridium Extreme® PTT device. Each time you restart the phone, you are prompted to enter your Phone PIN. Once you do, the phone is fully operational.
  • Page 198 PIN number. * * * * Select Clear 7. Press the left soft key, labeled Select. The message SIM lock disabled or SIM lock enabled briefly appears, then returns to the SIM Lock menu. Iridium Extreme® PTT User Manual...
  • Page 199 4. Press the left soft key, labeled Select. Change PIN 5. The Change PIN menu appears. Phone PIN SIM PIN Phone PIN is highlighted. SIM PIN 2 Call barring PIN Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 200 Verify PIN **** Clear 8. When all fields are complete, press the left soft key, labeled OK. Change PIN PIN changed OK 9. The screen displays PIN changed OK then returns to the Change PIN menu. Iridium Extreme® PTT User Manual...
  • Page 201 4. Press the left soft key, labeled Select. Change PIN Phone PIN 5. Use the 2-way Navi-key to scroll until SIM PIN SIM PIN 2 Call barring PIN SIM PIN is highlighted. Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 202 Change PIN Phone PIN SIM PIN 5. Use the 2-way Navi-key to scroll until SIM PIN 2 Call barring PIN SIM PIN 2 is highlighted. Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 203 Verify PIN **** Clear 8. When all fields are complete, press the left soft key, labeled OK. Change PIN 9. The screen displays PIN changed PIN changed OK OK then returns to the Change PIN menu. Iridium Extreme® PTT User Manual...
  • Page 204 Change PIN Phone PIN SIM PIN SIM PIN 2 5. Use the 2-way Navi-key to scroll until Call barring PIN Call barring PIN is highlighted. Select Back 6. Press the left soft key, labeled Select. Iridium Extreme® PTT User Manual...
  • Page 205 Verify PIN **** Clear 8. When all fields are complete, press the left soft key, labeled OK. Change PIN 9. The screen displays PIN changed PIN changed OK OK then returns to the Change PIN menu. Iridium Extreme® PTT User Manual...

  • Page 206: Phone Mode Troubleshooting

    Do you have a clear unobstructed view of the sky? • Did you enter the number in international format? All calls made from the Iridium satellite system must be in international format. See “Placing a Call” on p. 54.
  • Page 207 • Is it an old battery? Battery performance declines after several years of use. Replace the battery. • Make sure you have an Iridium approved battery installed. If you see ? on the display near the charging icon, you cannot charge this battery.
  • Page 208 Phone is not Remove the battery from the phone and then responding to user reattach it to cycle power and reset. controls including the power keys. Iridium Extreme® PTT User Manual...
  • Page 209 6. Press the left soft key and then press it a second time. The English option is at the top so press the left soft key a final time to confirm change back to English. Iridium Extreme® PTT User Manual...
  • Page 210 You may either wait for it to automatically exit the power saving mode within a minute or two on its scheduled interval or just simply turn off your phone and turn it on again to accelerate the registration process. Iridium Extreme® PTT User Manual...

  • Page 211: 4: Push-To-Talk Mode Operation

    4: Push-to-Talk Mode Operation Introduction Your Iridium Extreme® PTT device provides access to the world’s largest push-to-talk network, powered by Iridium. This section covers the setup and use of push-to-talk service with your Iridium Extreme® PTT device. While in Push-to-Talk mode, you will be able to access the push-to-talk service.

  • Page 212: Tips For Efficient Operation

    During in-vehicle or in-building use, your device must be used in conjunction with an external Iridium antenna oriented with the open sky or with a docking station (or device orientation) that maintains your GPS reception.

  • Page 213: Device Overview

    9) Additional details on the proper use of your Iridium Extreme® PTT device and service are outlined in this section and are critical to optimizing your user experience. Device Overview Front View Receiver (Earpiece) Speaker On/Off Button Programmable SOS Button...

  • Page 214: Indicators

    Indicates that the User Keypad locked John Smith Keypad locked Soft Key Functions is in PTT Mode IDLE Indicates Speaker Talkgroup 1 Keypad locked John Smith Keypad locked is Enabled IDLE Menu Scan Talkgroup 1 Iridium Extreme® PTT User Manual...

  • Page 215: Getting Started In Ptt Mode

    Getting Started in PTT Mode Follow these steps to enter PTT Mode if your Iridium Extreme® PTT device is in Phone Mode: 1. Press the left soft key, labeled Menu. 2. Press the left soft key, labeled Select. 3. Wait for the device to switch to PTT.

  • Page 216: Using Ptt Mode

    (e.g., if someone else is talking on the target talkgroup, or someone else just requested the floor for the target talkgroup), the device displays the text “Request Denied” and plays the Reject Tone (two notes descending in rapid succession). Iridium Extreme® PTT User Manual...
  • Page 217 Scan State provides information about the activity of those talkgroups and plays the audio. Only audio for talkgroups that are actively communicating is sampled while in Scan State. You will hear a single distinctive tone indicating the talkgroup change. Iridium Extreme® PTT User Manual...

  • Page 218: About The Menu

    About the Menu Press the left soft key, labeled Menu (when displayed) to configure push- to-talk operation on your Iridium Extreme® PTT device. This brings up the following options: Top of Menu List Bottom of Menu List Menu Menu Switch to Phone...

  • Page 219: Ptt Options

    (see Vibrate on p.216). In order to hear the Receiver audio, the Iridium Extreme PTT device should be held to your ear.

  • Page 220: Backlight

    Choices are: Off, 5 (factory default), 10, 15, 20, 30 seconds. Backlight 5 Seconds 10 Seconds 15 Seconds 20 Seconds Select Back • Contrast: Sets the resolution level for the display using the 2-way Navi-key to increase or decrease the screen contrast. Contrast Back Iridium Extreme® PTT User Manual...

  • Page 221: Ptt Options Submenu

    • Location Sharing: Allows you to control whether your relative location is shared with other talkgroup participants. The choices are Enabled (factory default) and Disabled. If location sharing is Disabled, other participants in the talkgroup see Unknown Location. Location Sharing Enabled Disabled Select Back Iridium Extreme® PTT User Manual...

  • Page 222: Scan Period

    IDLE to a LISTENING state. This feature is designed to assist in reducing missed calls when audio is routed to a wired headset or the built-in Receiver. The options are Enabled or Disabled (factory default). Vibrate Enabled Disabled Select Back Iridium Extreme® PTT User Manual...

  • Page 223: Locking And Unlocking The Keypad

    Locking and Unlocking the Keypad If the Auto Keypad Lock is Enabled, your Iridium Extreme® PTT device will automatically lock the keypad after 35 seconds to prevent accidental presses of the keys. When locked, the Keypad Locked symbol appears at the top of the screen.

  • Page 224: Navigating To Phone Mode To Dial

    If you attempt to press the SOS button while in PTT Mode, you will receive the following notification: “WARNING! Must go to Phone Mode for SOS. ” WARNING! Must go to Phone Mode for SOS. Phone Back Iridium Extreme® PTT User Manual...
  • Page 225 +112 for both the SOS CALL Recipient and SOS Message recipient. This will allow you to avoid the message received upon power- up to configure your SOS emergency response settings. Advise all users accordingly. Iridium Extreme® PTT User Manual...
  • Page 226 Phone Mode. A valid SIM card and Airtime subscription are required for phone services. The Iridium Extreme® PTT device purchaser is responsible for informing all users on the proper usage and capabilities of each Iridium Extreme® PTT handset. If you are unsure whether your Iridium Extreme® PTT is configured for Phone Mode, check with your Iridium service provider and make a test call to confirm status.

  • Page 227: Ptt Home State

    • Left soft key, labeled Menu: returns the device to the Menu • Right soft key, labeled Scan: exits the Home Talkgroup and enters Scan State • 2-way Navi-key: navigates to the Talkgroups List IDLE John Smith Talkgroup 1 Menu Scan Iridium Extreme® PTT User Manual...

  • Page 228: Listening

    • Left soft key, labeled Menu: returns the device to the Menu • Right soft key, labeled Ignore: exits the active talkgroup and enters the IDLE Status • 2-way Navi-Key: navigates to the Talkgroups List • Volume Up/Down Keys: adjusts the device’s volume Iridium Extreme® PTT User Manual...

  • Page 229: Talking

    The last line displays the name of the current talkgroup. When TALKING is displayed, the PTT Button is held down and other keys are disabled during use. The device cannot perform other functions until the PTT Button is released. Iridium Extreme® PTT User Manual...
  • Page 230 Talkgroup1 Menu Menu Ignore Scan When 20 seconds has elapsed, Time Expired is displayed on the screen and the device moves to the OPEN status, giving others in the talkgroup session a chance to speak. Iridium Extreme® PTT User Manual...

  • Page 231: Open

    • Left soft key, labeled Menu: returns the device to the Menu • Right soft key, labeled Ignore: exits the Home Talkgroup and enters the IDLE Status • 2-way Navi-key: navigates to the Talkgroups List OPEN John Smith Talkgroup1 Menu Ignore Iridium Extreme® PTT User Manual...

  • Page 232: Priority Talkgroup

    Scan State samples activity on all active talkgroups in sequential order. As additional talkgroups become active, they are scanned within the rotation. When a talkgroup ends communication, it is removed from the Iridium Extreme® PTT User Manual...
  • Page 233 • Push the PTT Button to navigate to the Home State and begin monitoring the talkgroup being sampled at the time Note: You may only enter Scan State by selecting Scan from the IDLE Status. Iridium Extreme® PTT User Manual...

  • Page 234: Talkgroups List

    Cursor line is always in the middle of the screen. Active Talkgroups – Represented by the active talkgroup names flashing. Additional Push-to-Talk terms and troubleshooting tips are outlined in the following pages. Iridium Extreme® PTT User Manual...

  • Page 235: Push-To-Talk Mode Glossary

    PTT Button but is out of the talkgroup's defined area at the time. Phone Mode This side of the Iridium Extreme® PTT enables the use of phone calling, SMS, voicemail and SOS. Iridium Extreme® PTT User Manual...
  • Page 236 The beeps will cease when the floor is either granted or denied. PTT Button The button on the right side of the Iridium Extreme® PTT device is the PTT Button that serves to request, hold and release the floor on the handset.
  • Page 237 When the floor is granted to the user of a device, the Talk Tone (three ascending notes) is played to that user. Talkgroup A talkgroup is a collection of Iridium Extreme® PTT devices that have been provisioned to transmit content to each other within a specified geographic area(s).

  • Page 238: Push-To-Talk Mode Troubleshooting

    OR that the update took longer than the device waiting period. The user may attempt the update again by selecting “Refresh Talkgroups” in the Menu or wait for updates to take effect based on internal timers. Iridium Extreme® PTT User Manual...

  • Page 239: 5: Certification And Compliance Information

    Safety in the United States, European Union and Canada. FCC Compliance The Iridium Extreme® PTT is certified under 47 CFR Part 25 as FCC ID: Q639575. It also complies with Part 15 of the FCC Regulations. Operation is subject to the condition that this device does not cause harmful interference.
  • Page 240 Iridium Extreme® PTT User Manual...

  • Page 241: 6: Limited Warranty Including Exclusions, Disclaimers, Limitations Of Liability And Conditions Of Use; Warranty Claim Process, Privacy And Data Security, And Software License

    Warranty Period and in accordance with the instructions set out in this Limited Warranty, notice of a defect in the Product covered by this Limited Warranty, Iridium will repair or replace the Product or refund the purchase price of the Product, at Iridium’s sole option. Iridium shall have...
  • Page 242 You should contact your Product provider in relation to problems with the Product and Accessories and Iridium will assist your Product provider to resolve them, including replacement where required. Exclusions This Limited Warranty does not apply in the following circumstances: Normal wear and tear.
  • Page 243 Service Provider are excluded from coverage. Altered Products. Products that have been tampered with, altered, have non-Iridium housings or parts, or have had the serial numbers or date tags removed, altered or obliterated are excluded from coverage. Communication Services. Defects, damages or failure of the Product...
  • Page 244 This Limited Warranty is your sole and exclusive remedy. These terms and conditions supersede any prior agreements or representations, including those made in Iridium sales literature or advice given to you by or on behalf of Iridium in connection with your purchase.
  • Page 245 Warranty. If you fail to comply with this Limited Warranty, Iridium may void certain protections offered under the Limited Warranty and Iridium reserves the right to terminate your right to use the Product on the Iridium system. If you do not accept the terms of this Limited Warranty, do not use the Product on the Iridium system.
  • Page 246 In the event any Iridium term or condition conflicts with any Service Provider term or condition, the Iridium term or condition shall govern. Service provider will be provided with notice of any new terms and conditions or any changes in these terms and conditions. All...
  • Page 247 Use, we may seek equitable relief to prevent such Unauthorized Use without having to wait to see if damage to the Iridium system occurs. This Product is covered by a U.S.A. warranty. This Limited Warranty is applicable in all countries and is enforceable in any country or region where Iridium or its Service Provider offer warranty service for the Product.
  • Page 248 Disclosure to Governmental and Quasi-Governmental Agencies By your use of the Product and Iridium Satellite Services you consent to Iridium’s disclosure of user information, including, but not limited to name, address, telephone number and location information, including, where...
  • Page 249 Iridium. You shall implement reasonable security measures to protect such trade secrets. To the extent required by law, and at your written request, Iridium shall provide you with the interface information needed to achieve interoperability between the Software and another independently created program, on payment of Iridium’s applicable fee, if any.
  • Page 250 You may terminate the license at any time by destroying all copies of Software and any Documentation. Your rights under the license will terminate immediately without notice from Iridium if you fail to comply with any provision of the license and Limited Warranty. Upon termination, you shall destroy all copies of Software and Documentation in your possession or control.

Table of Contents
