Kenmore 795.75002.402 Service Manual page 49

#EV#
Loc No. Part No.
103A 3650JJ2003M Handle,Rear
103B 3650JJ2003L
103C 3551JJ1015E
103E 5218JJ3001A Rail,Slide
105A 5251JA3003B Tube Assembly,Drain
105F 5070JJ3002A Skirt,Lower
106A 4779JA2003A Leg Assembly,Adjust
106B 4J00382C
120B 5209JJ1002A Duct Assembly,Multi
125D 4930JJ3007A Holder,Bracket
128A 4975JJ2002A Guide Assembly,Rail
128B 4975JJ2002B Guide Assembly,Rail
128E 4930JJ1012A Holder,Rail
128F 4930JJ1012B Holder,Rail
131A 5074JJ1017A Bucket,Ice
135C 3550JJ2030A Cover,Grille Fan
136C 3390JJ1058A Tray,Drawer
140B 5027JJ2007A Shelf Assembly,Refrigerator
140D 5026JJ2001G Shelf,Net
140E 5026JJ2001H Shelf,Net
142D 5026JJ2001L
142E 5026JJ2001M Shelf,Net
143A 5027JJ1028A Shelf Assembly,Refrigerator
143B 5027JJ1015A Shelf Assembly,Refrigerator
143E 5027JJ1008A Shelf Assembly,Refrigerator
143F 5027JJ1008C Shelf Assembly,Refrigerator
145A 4930JJ2003A Holder,Shelf
145B 4930JJ2004A Holder,Shelf
149A 5026JJ1058A SHELF,FREEZER
151A 3390JJ1032A Tray,Vegetable
151C 4940JJ2003A Knob,Shutter
154A 3550JL2001G Cover,TV
155B 4981JJ2001B Supporter Assembly,Cover TV
158A 3550JJ1040A Cover,Lamp
158E MCK30060901 Cover,Lamp
167B 4890JL1002G Shelf,Glass
170A 3391JJ2004G Tray Assembly,Meat
200A 3581JJ8023F
201A 5433JJ0017P
203A 4987JJ1004G Gasket Assembly,Door
205D 5004JJ1041A Basket,Door
212A 3650JJ1031B Handle,Refrigerator
212F 4810JJ3015A Bracket,Handle
212G 4140JL2001C NAME PLATE
212J 4620JJ3007E
230A 3581JJ8046C Door Assembly,Refrigerator
231A 5433JJ0016S
233A 4987JJ1004H Gasket Assembly,Door
241A 3550JJ1024A Cover,Tray
241B 5004JJ1035A Basket,Door
241C 5004JJ1030A Basket,Door
241D 5004JJ0002A Basket,Door
241E 5004JJ1028A Basket,Door
241F 5005JJ2009E
243A 4620JJ3006C Stopper,Door
244E 5006JJ3016C Cap,Handle
244P 3650JJ2012B Handle,Freezer
262D 4004JA3002A Clip
262E 4350JA3005B Ring
281A 3550JJ2013C Cover,Hinge
281B 4775JJ2003B Hinge Assembly,Upper
281E 5006JJ3014C Cap,Hinge
282B 4775JJ8002E
282C 1PZZJJ3002F
282E 5006JJ2001F
282F 3806JL2006D Decor,Duct
282H 5006JJ3004E
282Z 5006JJ3010C Cap,Handle
283B 4775JJ2007B Hinge Assembly,Lower
283D 4774JJ2002A Hinge,Lower
283F MJB36873202 Stopper,Door
284D 1STZJA3004K Screw,Customized
286A 4984JJ3003A BUSH
795.75009.402
Description
Handle,Rear
Cover Assembly,Lower
Washer,Common
Shelf,Net
Door Assembly,Freezer
Door Foam Assembly,Freezer
Stopper,Handle
Door Foam Assembly,Refrigerator
Basket Assembly,Door
Hinge Assembly,Center
Pin,Common
Cap,Hinge
Cap,Hinge
Loc No. Part No. Description
301A 5421JJ1001A Evaporator Assembly
304A 3551JJ2008A Cover Assembly,Machinery(Rear)
305B 4580JJ3001A Roller
305C 4J04238A Pin,Common
307A 2521CRA5715 Compressor,Set Assembly
308A EBG32606502 Thermistor Assembly,PTC
309A 6750C-0004S Overload Protect
310A 3550JA2059A Cover,PTC
312A 5040JA3031A Damper,Compressor
314A 4620JA3009A Stopper,Compressor
315A 3103JJ1001K Base Assembly,Compressor
317A 5851JJ2002F Drier Assembly
318A 4930JA3034A Holder,Drier
319A 3390JJ0003A Tray,Drip
319C 4974JJ1009A Guide,Fan
319E 4810JJ0002A Bracket,Motor
323B 5403JJ1005A Condenser Assembly,Wire
327A 5006JA3034A Cap,Drain Tube
328A 4J03020A Damper,Pipe
328B 4J04328A Damper,Pipe
329A 5901JJ1005A Fan Assembly
329C 5901JJ1004B Fan Assembly
332A 3531JJ1004B Grille Assembly,Fan
401A 6615JB2005C Controller Assembly
404A 4680JK1002B Motor, AC Freezing
405A 4811JJ2002B Bracket Assembly,Motor
405B 4810JA3007A Bracket,Motor
405C J756-00008B Damper,Motor Support
406B 6600JB1010A Switch,Push Button
409B 6912JK2002D Lamp,Incandescent
409C 6912JK2002A Lamp,Incandescent
409D 3034JJ1002B Reflector,Lamp
410A 6621JK2003B Harness Assembly
410G 0CZZJB2012J Capacitor,Electric Appliance Film,Box
411A 6411JK1006A Power Cord Assembly
418A 5300JB1100D Heater,Sheath
420A 4680JK1001B Motor,AC
501A 6871JB1215J PCB Assembly,Main
501F 3551JJ1020A Cover Assembly,PCB
503C 6871JB2047A PCB Assembly,Display
503D 3110JJ1005A Case,Display
503E 3550JJ2031A Cover,Display
503F ABQ33905307 Case Assembly,Display
503G 3806JL1051A Decor,Control
600A 5989JA0002P Ice Maker Assembly,Kit
600C MEA32865501 Guide,Tube
602A 4931JA3005B Holder Assembly,Bracket
610A 3550JJ2020A Cover,Sensor
616E 5210JA3005N Tube,Plastic
618A 5210JJ3005B Tube,Inject
619A 5220JA2009D Valve,Water
619B 3550JJ2024A Cover,Valve
619C 5221JA2008G Valve Assembly,Water
622A 5040JA2015A Tube,Inlet
622B 4810JA3036A Bracket,Cover
623C 4770JA3001A Band
627A 4930JA3054A Holder,Pipe
700B 3651JJ2015B Handle Assembly,Refrigerator
903A 3550JJ0005C Cover,Lower
903B 4930JJ2021A Holder,Cover(Lower)
903D 6500JK1003A Sensor,Temperature
903E 6500JK1004A Sensor,Temperature
B01 1STZJA3004F Screw,Customized
S01 1SZZJJ3010A Screw,Customized
S02 1SZZJJ3010D Screw,Customized
S22 J471-00001J Screw,Customized
S24 1SZZJA3011B Screw,Customized
S27 4J01424C Screw,Customized
S28 1SZZJJ3005E Screw,Customized
S29 4J00415D Screw,Customized
S31 4000W4A003A Screw,Customized
S38 4J00415D Screw,Customized
