1
Features
OVERVIEW
The Intel® Socket 370 Celeron® with AGP VGA and 10/100Mbps Ethernet Single
Board Computer(SBC-370) is a PICMG bus form factor board. It is equipped with a
high performance Intel® Celeron processor (up to 466 MHz) and advanced high per-
formance multi-mode I/O.
This board has a built-in DiskOnChip™(DOC) Flash Disk for embedded applications.
The DOC Flash Disk is 100% compatible to hard disk. Users can use any DOS command
without any extra software utility. The DOC currently is available from 8 MB to 288 MB.
An advanced high performance super AT I/O chip - Winbond W83977TF is used in the
SBC-370 board. The on-chip UARTs are compatible with the NS16C550. The parallel
port and IDE interface are compatible with IBM PC/AT architecture.
SBC-370 uses the advanced Intel 440BX Chipset which is 100% ISA/PCI compatible
chipset with PCI 2.1 standard.
FEATURE LIST
CPU
Intel Celeron® processor up to 466 MHz
•
PICMG bus, meets PCI 2.1 standard
•
7 DMA channels
•
15 Interrupt levels
•
Intel 82440BX 66/100MHz CPU Clock Chipset
•
SDRAM
Four 168-pin DIMM sites support up to 1 GB SDRAM
•
Each DIMM module is 3.3 V SDRAM with a maximum of 256 MB.
•
6
