- Page 1 Quick Start...
- Page 2 Thank you for purchasing the Mobile WiFi. This Mobile WiFi brings you a high speed wireless network connection. This document will help you understand your Mobile WiFi so you can start using it right away. Please read this document carefully before using your Mobile WiFi. For detailed information about the functions and configurations of the Mobile WiFi, refer to the online help on the web management page that comes with the Mobile WiFi.
- Page 3 Getting to Know Your Mobile WiFi Note: The Mobile WiFi function descriptions and illustrations in this document are for your reference only. The product you have purchased may vary. Application Scenarios Wi-Fi devices (such as smartphones, tablet computers, and game consoles) or computers can all access the Internet through Mobile WiFi.
- Page 4 Scenario 1: Accessing the Internet Using an LTE, 3G, or 2G Network The Mobile WiFi uses your operator's LTE, 3G, or 2G network to access the Internet. LTE/3G/2G...
- Page 5 Scenario 2: Accessing the Internet Using a Wi-Fi Network When you use the Mobile WiFi in Wi-Fi coverage areas, for example, an airport, cafe, hotel, or your home, the Mobile WiFi can access the Internet via Wi-Fi networks, helping save your LTE, 3G, or 2G network usage.
- Page 6 Appearance Power button Screen Micro USB port MENU button...
- Page 7 Screen Home screen 100% Roaming R: Data roaming turned on. Signal strength : Signal strength from weak to strong. Network type 0 B/2GB 4G/3G/2G: Connected to an LTE/3G/2G network. : Connected to WLAN. Data connection status ...
- Page 8 Wi-Fi Wi-Fi turned on. Number of connected Wi-Fi devices. 5G: 5GHz turned on. Traffic statistics Data usage this month. Monthly data usage limit. Note: To set the start date of the monthly data usage statistics and data usage limit, go to ...
- Page 9 Menu screen Press the MENU button to display the menu. Back Back XXXXXXXXX Return to the previous screen. XXXXXXXXX Options XXXXXXXXX Operation tips Next Menu Press the MENU button to scroll down. Press the button to confirm your selection. ...
- Page 10 Update screen When updates are available, you will be prompted to update 100% the Mobile WiFi. New Software Update When Update is selected, press the button to update the Update Mobile WiFi. Ignore Ignore Next Menu When Ignore is selected, press the button to ignore the update.
- Page 11 SSID and Wireless Network Encryption Key When a Wi-Fi device establishes a connection to the Mobile WiFi for the first time, you may need to enter the default Service Set Identifier (SSID) and wireless network encryption key. The default SSID and encryption key are printed on the Mobile WiFi label.
- Page 12 To view the current SSID and wireless network encryption key on the screen: Press the MENU button to display the menu. Press the MENU button to scroll to Device Info. Back Device Info Next Menu Press the button to enter Device Info. Back SSID: XXXXXXXXXX PWD: XXXXXX...
-
Page 13: Getting Started
Getting Started Installing Install the SIM card, microSD card, and battery according to the illustration. Note: The microSD card is an optional accessory. If no microSD card is included in the package, please purchase one separately. - Page 14 Charging the Battery If the Mobile WiFi has not been used for a long time or if the battery is fully depleted, the Mobile WiFi may not power on immediately after the charger is plugged in. Please charge the battery for a while before attempting to power on the Mobile WiFi. Method 1: Use the charger to charge the device Note: Only use chargers compatible with...
- Page 15 The Mobile WiFi's charger model is HW-050100XYW. X and Y represent letters or numbers that vary by region. For details about the specific charger model, contact an authorized dealer. Method 2: Charge the device through a computer connection Use the data cable provided with your device to connect the Mobile WiFi to the computer.
- Page 16 Turning on the Mobile WiFi Press and hold the button until the screen lights up, indicating that the Mobile WiFi is turned on. You can use the menu screen or log in to the web management page and turn the fast boot function on or off.
- Page 17 Connecting to the Internet Using an LTE, 3G, or 2G Network By default, the Mobile WiFi's management parameters have been preset according to your operator's requirements. The Mobile WiFi will be connected to the Internet after its startup. If data is transmitted, the Mobile WiFi will automatically connect to the Internet. If data is not transmitted for a period of time, the Mobile WiFi will automatically disconnect from the network connection.
- Page 18 Using a Wi-Fi Network Ensure that the Wi-Fi extender function is enabled. The Mobile WiFi automatically connects to a Wi-Fi hotspot set by your service provider or yourself. When the Mobile WiFi is connected to a Wi-Fi network, and the Wi-Fi hotspot SSID are displayed on the screen.
- Page 19 Logging In to the Web Management Page Make sure the connection between the Mobile WiFi and the Wi-Fi device or computer is working normally. Open the browser, and enter http://192.168.8.1 in the address box. Note: If the IP address conflicts with other IP addresses on the network, the IP address of the Mobile WiFi automatically changes.
- Page 20 Battery Saving Mode If the Mobile WiFi has been inactive for some time, the Mobile WiFi enters the standby mode, in which the display screen turns off. Pressing any button causes the display screen to light up. When the Mobile WiFi is being powered only by the battery, you can choose to enable or disable the automatic Wi-Fi off function.
- Page 21 Turning Wi-Fi extender On or Off Press the MENU button to display the menu. Back Press the MENU button to scroll to Wi-Fi extender. Press the button to turn Wi-Fi extender on or off. Wi-Fi extender Note: Next Menu Alternatively, you can log in to the Mobile WiFi's web management ...
- Page 22 Huawei HiLink Scan the 2D Barcode on the Mobile WiFi to download the HUAWEI HiLink APP. Next Menu Note: Alternatively, you can search for HUAWEI HiLink in Google Play or HUAWEI App Center and download the app to your device.
- Page 23 Press the button to display the Wi-Fi key screen. Back On your Android device: Wi-Fi key Scan the 2D Barcode on the Mobile WiFi using the HUAWEI HiLink APP. Next Menu Your Android device will then connect to the Mobile WiFi.
- Page 24 Establishing a WPS Connection If the Wi-Fi device to be connected to the Mobile WiFi supports WPS, the wireless network encryption key is generated automatically and there is no need to enter it manually. The steps for WPS connection are as follows: Turn on the Mobile WiFi.
- Page 25 Restoring to Factory Settings If you forget the user name, password, or SSID you have set, you can restore the Mobile WiFi to its factory settings. To do so, simply press and hold the RESET button until the Mobile WiFi restarts.
- Page 26 Example 1: Connecting to a Computer (for example, running the Windows 7 operating system) through Wi-Fi Ensure that the Mobile WiFi's Wi-Fi function is on. Select Start > Control Panel > Network and Internet > Network and Sharing Center > Connect to a network.
- Page 27 "SSID and Wireless Network Encryption Key" section. Wait a moment for the wireless network connection icon to appear in the system tray in the lower right corner of the computer screen. The wireless network connection is then established.
- Page 28 Example 2: Connecting to a Game Console (for example, PSP) through Wi-Fi On the PSP, turn on the WLAN. Choose Settings > Network Settings. Select Infrastructure Mode. Select New Connection, and enter the connection name. Select Scan to search for wireless networks.
- Page 29 save settings. Select Test Connection to test whether the network connection is successful. You can now open the browser and access the network.
- Page 30 Example 3: Connecting to a Tablet Computer (for example, iPad) through Wi-Fi Touch Settings > WLAN to turn on WLAN. The tablet computer automatically searches for wireless connections and displays a list of access points. Select the access point with the Mobile WiFi's SSID.
- Page 31 Tips When the Mobile WiFi is in use for an extended period of time, it will become warm and may overheat. Should this happen, the Mobile WiFi will automatically close the network connection and turn off to protect itself from damage. If this occurs, place the Mobile WiFi in a well ventilated space to allow the heat to dissipate, then turn it on and continue to use it as normal.
