AT&T 5635 Owner's Manual

AT&T 5635 Owner's Manual

Amerocan telephone & telegraph owner's manual cordless answering system 5635
Hide thumbs

Advertisement

Quick Links

Download this manual
Installation
Table/Desk Installation
1.
Choose a spot near an electrical outlet and a telephone jack.
Your phone requires a modular telephone jack and a standard electrical outlet (110v AC). The outlet
should not be controlled by a wall switch – if the switch is ever turned off, the phone will not operate
properly.
2.
Install the base batteries.
Open the battery door on the bottom of the unit by pulling on the tab. Insert the batteries, making sure
that they are in correctly, then close the door.
The batteries are used to save your messages in the event of a power failure.
When the base batteries need to be replaced, the LO BATT BASE Light on the base will blink.
3.
Set DIAL MODE switch.
Set the DIAL MODE switch on rear of the base unit to TONE if you have touch tone service, or
PULSE if you have dial pulse (rotary) service. To change dial mode during a call, see Temporary
Tone.
4.
Connect the telephone line cord.
The telephone line cord has a snap-in plug on each end. Insert one of the plugs into the jack in the rear
of the base unit. Insert the other plug into a telephone jack. Make sure the plugs snap into place.
5.
Set the HANDSET RINGER switch (ON, OFF).
Set the HANDSET RINGER switch on the base unit to ON so the phone will ring. When the switch is
set to OFF, the phone will not ring.
6.
Fill in the telephone number card.
On the handset, insert a pointed object into the hole in the window, and gently pry up the window until
it pops out. Write your phone number on the card and replace the window.
7.
Install the flexible handset antenna.
The flexible handset antenna has a metal end with a threaded tip. Slide the metal tip straight down
into the hole in the top of the handset. When you feel the antenna reach the bottom of the hole, turn
the antenna clockwise slightly to make sure that the tip is set in place, and then continue to screw the
antenna clockwise until the rubber is snug against the top of the handset. Do not overtighten the
antenna.
8.
Plug in the power cord.
Plug the AC adapter on the power cord into an electrical outlet not controlled by a wall switch. When
you connect the unit to an electrical outlet, the system automatically begins formatting digital memory.
The Message Window begins to count down from 8 to 0. When memory formatting has been
completed, "0" will blink in the Message Window to indicate that the system is on, but an
announcement has not been recorded.
9.
Charge the handset batteries for 10 hours.
Place the handset in the base and let the batteries charge for 10 hours. You can use your phone before
the 10 hours are up, but be sure to return the handset to the base so it can charge fully. The
CHARGING Light on the base unit will light to show the batteries are charging.
10. Check for dial tone.
CORDLESS ANSWERING SYSTEM 5635
Installation
Telephone Operation
Memory Dialing
Answering System
At the Base
Away From the Base

Advertisement

loading

Related Manuals for AT&T 5635

Summary of Contents for AT&T 5635

  • Page 1 CORDLESS ANSWERING SYSTEM 5635 Installation Telephone Operation Memory Dialing Answering System Installation Table/Desk Installation Choose a spot near an electrical outlet and a telephone jack. Your phone requires a modular telephone jack and a standard electrical outlet (110v AC). The outlet should not be controlled by a wall switch –...
  • Page 2 After the batteries are charged, pick up the handset and extend both the handset and the base antennas. Now press PHONE on the handset. The PHONE Light should light, and you should hear a dial tone. 11. Set Answering System Features. To fully utilize this system you need to: a) Set the clock.

  • Page 3: Telephone Operation

    sleeve toward the screw head. Insert the screws into the holes you started. Tighten the screws until the small end of the mounting sleeve is flat against the wall. 11. Connect the telephone line cord. The telephone line cord has a snap in plug on each end. Insert one of the plugs into the jack in the rear of the base unit.
  • Page 4 Occasionally, especially when you pick up the handset between rings, you may not be connected. If this happens, press PHONE on the handset to connect the call. If the handset rings when it’s out of the base, pick up the handset, extend the antenna and press PHONE to answer the call.
  • Page 5 PHONE. Move closer to the base, then press PHONE again to answer the call. Changing Channels Your Cordless Answering System 5635 has an advanced 10-channel AutoSelect™ feature that minimizes the chance of interference. Every time you answer or make a call, the AutoSelect circuit provides the clearest channel.

  • Page 6: Memory Dialing

    Using the Intercom During a Phone Call First place the call on hold by pressing HOLD. Then use the intercom. While you are using the intercom, the Phone Lights on the handset and the base will blink to show that your call has not been disconnected. The person on the other end of the phone call will not be able to hear your intercom conversation.
  • Page 7 To use the directory card concealed in the back of your handset, press the arrow and slide the door toward the top of the handset until it snaps in place. The directory card has an erasable surface. If you write in pencil, you’ll find it easy to change names when necessary.

  • Page 8: Answering System Operation: At The Base

    Answering System Operation: At The Base About Mailboxes This answering system provides two voice mailboxes. These mailboxes provide a convenient way to share an answering system with other members of your household or business. Callers using a touch tone phone can choose the mailbox in which their message will be recorded by pressing 1 or 2 after the system answers the call.
  • Page 9 Pre-recorded Announcement If you do not record your own announcement, callers will hear this announcement: “Hello. Please leave a message after the tone.” The Message Window blinks to indicate that the user needs to record an announcement. To select the pre- recorded announcement as your announcement and stop the display from blinking, press and release ANNC.
  • Page 10 While the system is taking a call, the Message Window displays “-.” After a message is recorded, the display changes to show the total number of recorded messages. NOTE: Messages are limited to a maximum of two minutes each. If the caller is still speaking after two minutes, is silent for more than 7 seconds, or if system memory runs out (system memory is 12 minutes in length), the system will beep once and hang up.
  • Page 11 C (steady) C (followed by 0-9) Indicator Lights The LO BATT BASE Light will start blinking to tell you when you need to replace the base batteries. Mailbox Lights The two mailbox lights indicate whether the mailboxes have messages. If a mailbox contains new messages, its light blinks. If a mailbox contains messages, but no new messages, its light is on steady.
  • Page 12 Saving Messages The system saves your messages automatically if you do not delete them. NOTE: The system can save about 12 minutes of messages. When memory is full, you must delete some or all of the messages before any new messages can be recorded. Deleting Selected Messages To delete only a specific message, press and release DELETE while the message you want to delete is being played.
  • Page 13 In addition, the 5635 has been designed to make access to the answering system’s features as easy as possible. Whether you are using the cordless handset or calling from a touch tone phone outside your home, you press the same buttons in the same order on either phone.
  • Page 14 If it doesn’t receive any instructions in a few seconds, the system will automatically play all of your messages for you. First Mailbox 1 followed by Mailbox 2. You can allow the system to play your messages, or you can use the number buttons on the handset to direct the system to perform any of the other operations.
  • Page 15 If you enter an invalid code, the system will beep five times. NOTE: If AC power fails and there are no base batteries installed, or the batteries are low on power, the Access Code returns to 50. Listening to Your Messages Playing All of your Messages Press and release 1 (ALL MSG).
  • Page 16 You can work with the clock setting any time after the system has given you the two-beep signal to indicate that it is ready to accept a command. Reviewing the Day/Time Setting Press and release 8 (CLOCK). The answering system will announce the current day/time setting and then beep twice to indicate that it is ready to accept a command.
  • Page 17 Speak into the phone in a normal tone of voice. Just as with messages, the system will accept memos up to two minutes in length. To stop recording, press and release 5 (STOP). The memo is counted as a new message. Recording a Telephone Conversation Once you’ve established a connection with the answering system you can record a telephone conversation.
  • Page 18 After the two-beep signal which indicates that it is ready to accept a command, press and release 6 then The system beeps once and “L” will be displayed in the Message Window of the base unit. To stop room monitoring, press and release 5 or hang up. Turning the Answering System On or Off You can perform the operations described below using the cordless handset.
  • Page 19 If the batteries don’t charge properly The batteries can be recharged many, many times, but if you get a low battery signal even after 10 hours of charging, the battery pack should be replaced. CAUTION: To avoid thee risk of fire and damage to the telephone set, use only AT&T Replacement Battery 4051.
