Sno.
1
2
3
4
5
6
7
8
9
1. MODEL RANGE
Commercial Code
12NC
13EAN AUS
Product Description
Ikea Details
Ikea Article #
Service Manual
INDEX
Detail
Model Range
Feature /Technical specification
Controls & Electronic configuration
Wiring Diagram
Controlling the refrigerator temperature
Service Process
Exploded view
Serviceable Parts List
Plug Pin Check Points
IRIBT26WA
852460153230
9320921075347
IKEA 260LT WHITE TOP MOUNT
REFRIGERATOR
LAGAN fridge/freezer176/57Lwhite
AU
00275532
IRIBT29MB
852460153240
9320921075446
IKEA 290LT STAINLESS TOP
MOUNT REFRIGERATOR
ENERGISK fridge/freezer
202/57L silver colour AU
20275531
1
Page No.
2
5
6
7
9
10
18
30
33
Advertisement
Table of Contents
Related Manuals for IKEA IRIBT26WA
Summary of Contents for IKEA IRIBT26WA
- Page 1 Commercial Code IRIBT26WA IRIBT29MB 12NC 852460153230 852460153240 13EAN AUS 9320921075347 9320921075446 Product Description IKEA 260LT WHITE TOP MOUNT IKEA 290LT STAINLESS TOP REFRIGERATOR MOUNT REFRIGERATOR Ikea Details LAGAN fridge/freezer176/57Lwhite ENERGISK fridge/freezer 202/57L silver colour AU Ikea Article # 00275532 20275531...
- Page 4 TECHNICAL /FEATURE SPECIFICATION MODEL 260L IRIBT26WA 290L IRIBT29MB Type Frost Free Frost Free Capacities (L) total net 260 L 290L Product Dimensions (mm) Width Height 1587 1714 Depth Gross Weight (kg) Voltage / Hz 220V /240V/50Hz 220V /240V/50Hz Voltage Range...
-
Page 5: Controls & Electronic Configuration
Electronic Configuration, Logic & Troubleshooting GENX Controls & Electronics Configuration Product Configuration 240/260/290L Product Control RC Controlled Software User interface Auto cool mode Quick Chill/Fast Forward Ice Auto Power save mode Door Alarm RC Illumination Yes(Lamp) Control Board Defrost heater Yes (Radiant Heater 180 W) Fan motor FAN MOTOR MI... -
Page 6: Wiring Diagram
Wiring Diagram GENX Dlx Refrigerant Charging Qty:... - Page 7 Note: - There is no Service routine provided in this model. In Dlx models Diagnosis of the Error / Sensor / Pot failure is not of continuous nature. In case of any detailed technical information please check with the Dlx technical specification.
-
Page 8: Controlling The Refrigerator Temperature
5. Controlling the refrigerator temperature- Dlx Models: To control the temperature of your refrigerator. Turn the knob according to your requirement. This control is provided inside the refrigerator section. Turn knob to the left to reduce the cooling and to the right to increase the cooling. -
Page 9: Service Process
6. Service Process:- Separate FC door from refrigerator Use 8mm round spanner and remove three screws of center hinge Remove Center Hinge Pick the RC door upward and separate from refrigerator... - Page 10 FC PLENUM:- Identify 2 screws of FC Plenum Use Star screw driver and remove 2 screws of FC Plenum Pull plenum down by inserting your fingers in the slot located at top center Disconnect fan motor connectors Separate FC Plenum from refrigerator FC Plenum is mandatory to dismantle for dismantling of Thermal fuse, Bimetal, FC sensor, D heater etc.
- Page 11 INTERIOR PARTS OF FC PLENUM :- Separate FC Plenum from refrigerator Remove LHS EPS block Remove RHS EPS block Disconnect Thermal Fuse Disconnect Bi metal Disconnect FC sensor. Precaution : All the components present interior to FC plenum must be fitted at their original location.
-
Page 12: Fan Motor
FAN MOTOR:- Use star screw driver and open three screws of fan motor bracket fitted on plenum at back side. Separate fan motor bracket Use star screw driver to remove single screw of fan motor Separate fan motor bracket cover Pull the fan blade out Separate fan blade from fan bracket Separate Fan motor from refrigerator... -
Page 13: Defrost Heater
DEFROST HEATER:- Separate FC Plenum from refrigerator Disconnect Heater terminals Pull out cooling coil slightly upwards and towards your side Remove LHS and RHS EPS blocks Remove Thermal Fuse Take the black wire (thin) out Take the white wire (thick) out Cut white wire of defective heater at by wire cutter Separate defrost heater from the machine Note –... -
Page 14: Diffuser Assembly
DIFFUSER ASSEMBLY:- Pull out the lens cover and bulb holder Use star screw driver and remove 2 screws Pull out assembly slightly from bottom (ensure 2 inserters will come out properly) Pull out thermostat knob Disconnect thermostat connector Separate diffuser assembly from refrigerator. - Page 15 INTERIOR PARTS OF DIFFUSER ASSEMBLY:- Thermostat - Defrost Timer Disconnect thermostat connectors Separate thermostat from machine Remove deodorizer cover Use star screw driver and remove 1 screw Disconnect D Timer connectors Separate D Timer from refrigerator BOTTOM HINGE:- Use 8mm round spanner and open 2 screws from front side Tilt the machine slightly at back side Open 2 screws from bottom side Separate bottom hinge from machine...
- Page 16 COMPRESSOR MOUNTING PLATE:-...
-
Page 17: Exploded View
7. Exploded View:- SR NO LOCATION PART NO DISCRIPTION CABINAT EXTERIOR W10507748 TOP HINGE COVER NEO-DLX WHITE CABINAT EXTERIOR W10463885 TOP HINGE COVER NEO-DLX CHARCOAL GRAY CABINAT EXTERIOR W10418501 SCREW- TRILOBULAR M6X1.0 HEX HEAD CABINAT EXTERIOR W10444351 HINGE TOP ASSY- DLX... - Page 18 CABINAT EXTERIOR W10426650 CENTRE HINGE ASSY- L60 CABINAT EXTERIOR W10479958 CAP - CENTER RAIL WHITE TRINITY CABINAT EXTERIOR W10478024 SCREW-TRILOBULAR M6X1.0 HEX HEAD CABINAT EXTERIOR W10528520 PLATE LEVELLER ASSEMBLY,GENX CABINAT EXTERIOR A201354000D PHILIPS HEAD SCREW M5.5X1.8 CABINAT EXTERIOR W10528523 HINGE BOTTOM ASSEMBLY, GENX...
- Page 19 FC DOOR W10533610 FC FOAMED DOOR WHITE GENX-2 FLUSH H FC DOOR W10533611 FC FOAMED DOOR REAL STEEL GENX-2 FLUSH FC DOOR EXTERIOR W10391355 NAMEPLATE-WP,WHT FC DOOR EXTERIOR W10412075 HANDLE FC FRONT FLUSH WHITE FC DOOR EXTERIOR W10477284 HANDLE FC FRONT FLUSH EXPO WARM SILVER 2 FC DOOR EXTERIOR W10511612 HANDLE FC BACK FLUSH WHITE...
- Page 20 FC DOOR INTERIOR W10412095 TRIVET FC GENX 2 FC DOOR INTERIOR W10530157 GASKET SUB-ASSY FC GENX FC INTERIOR W10412128 KNOB - FREEZER DAMPER / THERMOSTAT,L 60 FC INTERIOR W10507116 FC GLASS SHELF FRAME - GEN-X 2 FC INTERIOR W10507117 GLASS FC SHELF - GEN-X FC INTERIOR W10471820 SCREW CAP- PLENUM...
- Page 21 FC PLENUM INTERIOR W10511079 PLENUM FRONT WITH REFLECTOR L60 FC PLENUM INTERIOR W10532079 PLENUM BACK SUB ASSY L60/GENX 2 FC PLENUM INTERIOR W10533473 Freezer Damper Control GENX- AUS FC PLENUM INTERIOR W10468717 EPS BLOCK FOR PLENUM FRONT L60 & GENX FC PLENUM INTERIOR W10169462 FAN BLADE 90MM DIAMETER...
- Page 22 FC PLENUM INTERIOR W10532059 THERMAL FUSE WITH CONNECTOR FOR GENX FC PLENUM INTERIOR A2119170000 BI-METAL ASSY. TOD-39TV FC PLENUM INTERIOR W10467187 RADIANT HEATER 180W/230V L60...
- Page 23 RC DOOR W10533613 305L RC FOAMED DOOR WHITE GENX-2 FLUSH RC DOOR W10533614 305L RC FOAM DOOR REAL STEEL GENX2 FLUSH RC DOOR W10533612 275L RC FOAMED DOOR WHITE GENX-2 FLUSH RC DOOR W10548059 255L RC FOAMED DOOR WHITE GENX-2 FLUSH RC DOOR EXTERIOR W10412079 HANDLE RC FRONT FLUSH...
- Page 24 RC DOOR INTERIOR A2240510000 EGG TRAY - ONYX RC DOOR INTERIOR W10479640 BOTTLE RETAINER GENX RC DOOR INTERIOR W10412105 TRIVET RC- GENX 2 RC DOOR INTERIOR W10412106 SHALLOW BIN GENX RC DOOR INTERIOR W10473470 PUSH IN GASKET(B)-RC 242L GENX 2 RC DOOR INTERIOR W10473471 PUSH IN GASKET(B)-RC 262L GENX 2...
- Page 25 RC INTERIOR W10412104 CRISPER 21.4 L GENX 2 RC INTERIOR W10426608 CRISPER COVER ASSY M1 GENX 2 RC INTERIOR W10412101 ALBUM COVER GLASS SHELF RC GENX 2 RC INTERIOR W10509476 GENX GLASS WITH WHITE PRINTING RC INTERIOR W10432663 DEFROST TRAY - AUSTRALIA RC INTERIOR w10507104 THAW GLASS SHELF FRAME , GEN-X...
- Page 26 RC DIFFUSER EXTERIOR A2221820000 BULB HOLDER - DUO RC DIFFUSER EXTERIOR A2221470000 BULB APPLIANCE, E14 RC DIFFUSER EXTERIOR W10441496 EAST DRAGON DEFROST TIMER RC DIFFUSER EXTERIOR W10523684 THERMOSTAT - GENX 292L/262L RC DIFFUSER EXTERIOR W10523685 THERMOSTAT-GENX,242L RC DIFFUSER EXTERIOR W10539585 LENS IN DIFFUSER ACRYLIC RC DIFFUSER EXTERIOR W10412109...
- Page 27 RC DIFFUSER EXTERIOR W10383978 CONTROL BOX HARNESS DLX...
- Page 28 W10412129 COMPRESSOR MOUNTING PLATE ASSY GENX A201354000D PHILIPS HEAD SCREW M5.5X1.8 W10494984 SLEEVE GROMMET W10494985 WASHER GROMMET L60 W10494983 COMPRESSOR GROMMET L60 D111204100D HEX NYLOC NUT M6 COMPRESSOR DECK AREA W10479607 DRIER HOLDER -L60 & GenX COMPRESSOR DECK AREA W10536565 DISCHARGE COIL GENX2 COMPRESSOR DECK AREA W10499649...
- Page 29 COMPRESSOR DECK AREA A201358000F M/C Screw for Fan Motor Bracket ( FOR EARTHING)
-
Page 30: Serviceable Parts List
8. Serviceable Part List:- W10507748 TOP HINGE COVER NEO-DLX WHITE W10463885 TOP HINGE COVER NEO-DLX CHARCOAL GRAY W10418501 SCREW- TRILOBULAR M6X1.0 HEX HEAD W10444351 HINGE TOP ASSY- DLX W10426650 CENTRE HINGE ASSY- L60 W10479958 CAP - CENTER RAIL WHITE TRINITY W10478024 SCREW- RILOBULAR M6X1.0 HEX HEAD CENTRE RAIL W10528520... - Page 31 W10532059 THERMAL FUSE WITH CONNECTOR GENX 2 A2119170000 BI-METAL ASSY. TOD-39TV W10467187 RADIANT HEATER 180W/230V W10533613 305L RC FOAMED DOOR WHITE GENX-2 FLUSH W10533614 305L RC FOAM DOOR REAL STEEL GENX2 FLUSH W10533612 275L RC FOAMED DOOR WHITE GENX-2 FLUSH W10548059 255L RC FOAMED DOOR WHITE GENX-2 FLUSH W10412079...
- Page 32 W10523685 THEMOSTAT - GENX 242L W10539585 LENS IN DIFFUSER ACRYLIC W10412109 DEODERIZER COVER,L60 W10504843 CHARCOL - DEODRISER W10507108 BAD SUB ASSY GENX,292L W10412090 BAD SUB ASSY GENX,242L/262L W10502379 SUB ASSSEMBLY OF COVER AIR DIFFUSER W10412091 COVER AIR DIFFUSER-GENX,242L/262L W10383978 CONTROL BOX HARNESS DLX W10412129 COMPRESSOR MOUNTING PLATE SUB ASSY A201354000D...
-
Page 33: Plug Pin Check Points
Plug Pin check points Ensure proper earthling and phase direction • Confirm phase at right side • Confirm voltage in Phase and Neutral ~220V • Confirm Voltage in Phase and Earthling~ < 220V • Confirm Voltage in Earthling and Neutral ~ <5V •...
