GM CLASS II DATA BUS INTERFACE
GMRC-02
INSTALLATION
INSTRUCTIONS
* Retains the factory door chime and supplies a
12V switched voltage for audio operation.
* READ IMPORTANT WARNING ON PAGE 1
BEFORE ATTEMPTING ANY INSTALLATION
APPLICATIONS
BUICK
• ALLURE 2005-09
• CENTURY 2004-05
• LACROSSE 2005-09
• RAINIER 2004-07
• RENDEZVOUS 2002-07
• TERRAZA 2005-08
CHEVROLET
• AVALANCHE 2003-06
• CAVALIER 2000-05
• COLORADO 2004-10
• EXPRESS 2003-07
• IMPALA 2000-05
• MALIBU 2001-03
• MALIBU CLASSIC 2004-05
• MONTE CARLO 2000-05
• SILVERADO PICKUP
CLASSIC 2007
• SILVERADO PICKUP
(All Models) 2003-06
INTERFACE COMPONENTS
• GMRC-02 Data Interface
• 10 pin to 24 pin GM harness w/ stripped leads
INST-GMRC02
1-800-221-0932
©Copyright 2010 Metra Electronics Corporation
(Not compatible with BOSE or
MONSOON systems)
• SSR 2003-06 • I SERIES PICKUPS 2006-
08
• SUBURBAN 2003-06
OLDSMOBILE
• TAHOE 2003-2006
• ALERO 2001-04
• TRAILBLAZER 2002-09
• BRAVADA 2002-05
• UPLANDER 2005-08
• INTRIGUE 2002
• VENTURE VAN 2000-05
• SILHOUETTE
2000-04
GMC
PONTIAC
• CANYON 2004-10
• AZTEC 2001-05
• ENVOY 2002-09
* GRAND AM 2001-05
• SAVANNA FULL SIZE VAN
• GRAND PRIX 2004-08
2003-07
• MONTANA SV6 (CANADA)
• SIERRA CLASSIC 2007
2005-08
• SIERRA 2003-2006
• MONTANA 2000-05
• YUKON/ YUKON XL 2003-
• SUNFIRE 2000-05
06
SAAB
HUMMER
• 9-7X 2005-09
• H3 2006-09
SATURN
ISUZU
• RELAY 2005-07
• ASCENDER 2003-08
