External Screen Setup; First Use; Software Upgrade; Switching Off - NAIM unitiserve-ssd Reference Manual

I ns tallat io n - G e tti ng St ar ted
2. 5 E x t erna l S cre e n S e tu p
If an external display is used, the UnitiServe-SSD external
display setup may need to be modified. Navigate, via the
System
menu, to the
save the desired External Display Theme, External Display
Aspect Ratio, External Display Mode
disable the Screen Saver
Note: The External Display Mode setting configures the
external display for use with either an external touch
screen or a remote handset. In touch screen mode, four
shortcut buttons are displayed on the right of the screen
that correspond to the home, browse, find and back keys
on the remote handset. The on screen shortcut buttons
can only be accessed from the touch screen so are not
shown in remote control mode.
Note: Once you have become used to the interface and
are familiar with its functions the screen saver can be
re-enabled.
2. 6 F irst Use
Before attempting to rip a CD you must ensure that the
necessary Network Attached Storage (NAS) disk drive is
appropriately configured, connected to the network, and
switched on. Section 7 of this manual describes the use
and configuration of external storage.
To rip a CD, insert the CD into the transport slot. The ripping
process will begin automatically. When CD ripping is
complete UnitiServe-SSD will eject the CD automatically.
See Section 6 for further information on ripping CDs.
Only CDs owned personally should be ripped. Ripping a
borrowed CD may violate copyright law.
Note: Although UnitiServe-SSD contains a small internal
music database, to be able to identify a CD and
download its associated data during the ripping process, it
must be connected to a working internet connection.
2. 7 S oft wa re U pgra de
Software upgrade CDs will occasionally be released
for UnitiServe-SSD. New software is installed simply by
inserting the upgrade CD in the transport. The software
upgrade process will commence automatically. As part
of the upgrade process UnitiServe-SSD will eject the CD
and re-boot. The upgrade process is complete once the
interface returns to the Home Menu.
Note: Any specific instructions included with the upgrade
CD should be followed carefully.
Never switch off UnitiServe-SSD from the rear panel power
switch or unplug it from the mains supply while a software
upgrade process is underway.
4
System Settings
menu. Select and
and TV System. Initially
(found on System Setup page 1).
2 . 8 Sw i tc h i n g O f f
Switching off UnitiServe-SSD from its rear panel power
switch is not normally necessary unless it is to be
un-installed. It can be put into shutdown mode by
touching the front panel logo for five seconds. UnitiServe-
SSD may take up to one minute to enter shutdown mode
during which time the logo will flash. Wait until the logo
stops flashing before switching off UnitiServe-SSD from the
rear panel power switch.
Never switch off UnitiServe-SSD from the rear panel power
switch or unplug it from the mains supply unless it is in
shutdown mode.
To switch UnitiServe-SSD back on from shutdown mode, the
power switch must be switched off and on again.
2 . 9 Da t a Ba ck u p
UnitiServe-SSD does not incorporate an integral backup
disk drive and we strongly advise that you protect your
stored music by implementing a regular backup to a
Network Attached Storage (NAS) hard disk drive.
Implementing regular backups to a network share can be
set up via the UnitiServe-SSD System menu. This is described
in Section 4.8.4.
