TECHNICAL DATA
Sound system
Max power: 4x25 W
Frequency: 30÷20.000 Hz.
Aerial
For versions/markets, where provided, the
antenna can be integrated into the heated
rear window or located on the roof of the car.
Remember to remove the
aerial from the roof when
washing the car at auto-
matic car-wash to avoid damages.
Power aerial and
outer amplifier
The sound system is preset for controlling
an automatic power aerial (that comes out
when turning the sound system on and will
retract when turning it off).
Aerial switching voltage is on sound sys-
tem contact (5-fig. 3).
Switching voltage: +12 V, max current
0.5A.
Speakers
Sound system consists of the following:
– 2 tweeters with 40 W power each
– 4 speakers with 165 mm diameter (2
front and 2 rear) with 40 W power each
(40 W+8 W for front speaker on passenger
side if free-hand set is provided).
Protection fuses
The sound system has a 10A fuse (A-fig.
3).
fig. 3
WARRANTY
Warranty covers 12 months from sound
system purchase date that shall be evi-
denced by fiscal document.
AFTER-SALES SERVICE
For servicing operations on sound system,
contact Alfa Romeo Authorized Services.
23
