Icom IC-F4160 Service Manual page 113

Aug. 2008
SECTION 7
[FRONT UNIT] (For F4060 series)
REF ORDER
NO. NO.
IC501 1180002401 S.REG S-812C30AMC-C2K-G
IC505 1110007330 S.IC M62320FP-DF5G
IC506 1110007330 S.IC M62320FP-DF5G
IC508 1110006770 S.IC TDA8547TS/N
IC509 1110007010 S.IC NJM12904R
Q501 1520000460 S.TR 2SB1132 T100 R
Q502 1590001190 S.TR XP6501-(TX) .AB
Q506 1590003230 S.TR UNR9113J-(TX)
Q507 1590003290 S.TR UNR9213J-(TX)
Q508 1590001330 S.TR DTA114EUA T106
Q509 1590000980 S.TR DTB123EK T146
Q512 1590003290 S.TR UNR9213J-(TX)
Q513 1590003290 S.TR UNR9213J-(TX)
Q515 1560001360 S.FET 2SK3019 TL
Q516 1590003290 S.TR UNR9213J-(TX)
D504 1790001250 S.DIO MA2S111-(TX)
D505 1160000140 S.DIO DAP222 TL
D506 1160000140 S.DIO DAP222 TL
D508 1160000060 S.DIO DAN202U T106
R503 7030009140 S.RES ERJ2GEJ 272 X (2.7 k)
R504 7030008290 S.RES ERJ2GEJ 183 X (18 k)
R505 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R506 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R508 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R509 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R510 7030005720 S.RES ERJ2GEJ 563 X (56 k)
R511 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R513 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R514 7030005060 S.RES ERJ2GEJ 333 X (33 k)
R515 7030005080 S.RES ERJ2GEJ 823 X (82 k)
R516 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R518 7030010040 S.RES ERJ2GEJ-JPW
R521 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R522 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R523 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R524 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R525 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R526 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R527 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R528 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R529 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R530 7030009280 S.RES ERJ2GEJ 391 X
R531 7030005000 S.RES ERJ2GEJ 471 X (470 )
R532 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R533 7030007250 S.RES ERJ2GEJ 220 X (22 )
R534 7030007250 S.RES ERJ2GEJ 220 X (22 )
R535 7030004970 S.RES ERJ2GEJ 470 X (47 )
R536 7030004970 S.RES ERJ2GEJ 470 X (47 )
R537 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R538 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R539 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R540 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R541 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R542 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R543 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R544 7030004980 S.RES ERJ2GEJ 101 X (100 )
R546 7030009280 S.RES ERJ2GEJ 391 X
R547 7030009280 S.RES ERJ2GEJ 391 X
R548 7030005230 S.RES ERJ2GEJ 334 X (330 k)
R552 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R553 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R554 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R555 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R557 7520000270 S.RES PRG21BC4R7MM1RA
R558 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R559 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R560 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R561 7030005000 S.RES ERJ2GEJ 471 X (470 )
R562 7030005000 S.RES ERJ2GEJ 471 X (470 )
R563 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R564 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R566 7030010040 S.RES ERJ2GEJ-JPW
R567 7030005090 S.RES ERJ2GEJ 104 X (100 k)
C501 4550006760 S.TAN TEESVB21A336M8R
C502 4550006760 S.TAN TEESVB21A336M8R
C506 4550006250 S.TAN TEESVA 1A 106M8R
C507 4550006250 S.TAN TEESVA 1A 106M8R
C508 4550006250 S.TAN TEESVA 1A 106M8R
C509 4030017460 S.CER ECJ0EB1E102K
C510 4030016930 S.CER ECJ0EB1A104K
C511 4030017460 S.CER ECJ0EB1E102K
C514 4550006250 S.TAN TEESVA 1A 106M8R
C515 4030016930 S.CER ECJ0EB1A104K
C517 4030016930 S.CER ECJ0EB1A104K
C518 4030017460 S.CER ECJ0EB1E102K
C520 4030017460 S.CER ECJ0EB1E102K
C522 4030016930 S.CER ECJ0EB1A104K
C523 4030016930 S.CER ECJ0EB1A104K
PARTS LIST
DESCRIPTION M.
LOCATION
B 66.7/35.7
B
B 56.8/24.5
B 79.6/11.9
B 79.8/24.9
B
B 75.8/20.8
B
B
B
B 72.4/12.3
B
B 74.9/15.6
B
B
B
B 63.6/21.9
B
B
B
B 74.8/18.4
B 76.6/18.4
B 75.2/13.7
B 81.8/18.2
B 79.1/18.2
B 81.7/16.6
B 78.3/16.6
B 85.2/41.1
B 87.5/38.8
B
B 79.4/32.4
B
B 68.3/24.8
B 53.6/18.8
B 54.6/18.8
B 55.6/18.8
B 56.6/18.8
B
B 63.6/23.5
B 63.6/24.4
B
B 71.6/14.4
B
B 65.2/31.6
B 63.2/27.8
B
B
B
B
B
B
B 80.3/20.2
B 79.4/20.2
B 81.7/28.3
B 82.6/27.1
B 82.6/29.9
[TENKEY] only B 71.6/15.3
[TENKEY] only B 71.6/16.2
B
B 79.8/30.4
[4-key] only B 72.9/41.7
[TENKEY] only B 79.4/41.3
B
B
B 73.9/18.4
B 77.4/16.6
B 77.5/18.4
B 82.7/22.7
B 83.4/20.3
B 80.4/16.6
B 79.5/16.6
B 77.6/20.2
B
B 93.4/37.3
B 96.7/37.3
B 75.8/31.1
B
B 70.5/31.1
B 75.6/12.5
B
B 75.7/18.4
B
B 80.9/18.2
B
B 71.9/26.7
B
B 85.2/39.9
B
[FRONT UNIT] (For F4060 series)
H/V REF ORDER
NO. NO.
C525 4030016930 S.CER ECJ0EB1A104K
74/36.8 C526 4030017460 S.CER ECJ0EB1E102K
C527 4030017460 S.CER ECJ0EB1E102K
C528 4030016930 S.CER ECJ0EB1A104K
C529 4030016930 S.CER ECJ0EB1A104K
C530 4030017460 S.CER ECJ0EB1E102K
C531 4030017460 S.CER ECJ0EB1E102K
75.2/25 C532 4550007090 S.TAN
C534 4030016930 S.CER ECJ0EB1A104K
83.6/41 C535 4030016790 S.CER ECJ0EB1C103K
72.3/6.1 C536 4550005980 S.TAN
72.2/9 C537 4030016930 S.CER ECJ0EB1A104K
C538 4550000460 S.TAN
72/18 C539 4030016930 S.CER ECJ0EB1A104K
C540 4030018140 S.CER ECJ0EB1H391K
81/32.2 C541 4030016930 S.CER ECJ0EB1A104K
80.9/36 C542 4030017440 S.CER ECJ0EC1H221J
C543 4550006250 S.TAN
C544 4030017460 S.CER ECJ0EB1E102K
71/25.1 C559 4030016790 S.CER ECJ0EB1C103K
C560 4030017770 S.CER ECJ0EB1E332K
63.6/26 C561 4030016930 S.CER ECJ0EB1A104K
75.1/5.7
J501 6510025240 S.CNR IMSA-9631S-20Y912
74/20 J502 6510025250 S.CNR IMSA-9631S-08Y912
J503 6510025260 S.CNR IMSA-9631S-10Y912
DS501 5040002961 S.LED
DS502 5040002961 S.LED
DS503 5040002961 S.LED
DS504 5040002420 S.LED
DS505 5040002420 S.LED
DS506 5040002420 S.LED
81.8/34 DS507 5040002420 S.LED
DS508 5040002420 S.LED
66/23 DS509 5040002420 S.LED
DS510 5030003140 LCD
MC501 7700002760 MIC
65.1/23
W501 9028930010 WIR
W502 9014506004 WIR
65/24.7
82.7/33
[FRONT-A UNIT] (For F4160 series)
REF ORDER
64/29.1
NO. NO.
69.7/3.4
69.7/5.4
IC501 1180002401 S.REG S-812C30AMC-C2K-G
69.7/4.4
IC505 1110007330 S.IC
72/3.1
IC506 1110007330 S.IC
69.7/2.4
IC508 1110006770 S.IC
IC509 1110007010 S.IC
Q501 1520000460 S.TRA
Q502 1590001190 S.TRA
Q506 1590003230 S.TRA
Q507 1590003290 S.TRA
74.4/8.5
Q508 1590001330 S.TRA
Q509 1590000980 S.TRA
Q512 1590003290 S.TRA
Q513 1590003290 S.TRA
Q515 1560001360 S.FET
Q516 1590003290 S.TRA
74.4/9.4
Q517 1590003290 S.TRA
87/34.7
D504 1790001250 S.DIO
D505 1160000140 S.DIO
D506 1160000140 S.DIO
D508 1160000060 S.DIO
D509 1790001280 S.DIO
81/30.4
R503 7030009140 S.RES ERJ2GEJ 272 X (2.7K)
R504 7030008290 S.RES ERJ2GEJ 183 X (18K)
R505 7030005120 S.RES ERJ2GEJ 102 X (1K)
R506 7030005120 S.RES ERJ2GEJ 102 X (1K)
R508 7030005050 S.RES ERJ2GEJ 103 X (10K)
R509 7030005050 S.RES ERJ2GEJ 103 X (10K)
70.5/29
R510 7030005720 S.RES ERJ2GEJ 563 X (56K)
R511 7030005090 S.RES ERJ2GEJ 104 X (100K)
R512 7030005530 S.RES ERJ2GEJ 100 X (10)
73.1/20
R513 7030005050 S.RES ERJ2GEJ 103 X (10K)
R514 7030005060 S.RES ERJ2GEJ 333 X (33K)
78.5/5.4
R515 7030005080 S.RES ERJ2GEJ 823 X (82K)
R516 7030005090 S.RES ERJ2GEJ 104 X (100K)
80/18.2
R521 7030005050 S.RES ERJ2GEJ 103 X (10K)
R522 7030005090 S.RES ERJ2GEJ 104 X (100K)
87/41.1
R523 7030005090 S.RES ERJ2GEJ 104 X (100K)
R524 7030005090 S.RES ERJ2GEJ 104 X (100K)
80/34
R525 7030005090 S.RES ERJ2GEJ 104 X (100K)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
1
DESCRIPTION M.
B
B
B
B
B
B
B
TEESVA 1A 226M8R B
B
B
TEESVA 1A 475M8R B
B
TEESVA 1C 105M8R B
B
B
B
B
TEESVA 1A 106M8R B
B
T
B
B
B
B
B
SML-A12MT T86J T
SML-A12MT T86J T
SML-A12MT T86J T
SML-310MT T86 T
SML-310MT T86 T
SML-310MT T86 [TENKEY] only T
SML-310MT T86 [TENKEY] only T
SML-310MT T86 [TENKEY] only T
SML-310MT T86 [TENKEY] only T
M7-0626TIZ
EM6027P-46C33-G-01
23/04/020/W02/W02 <TJM>
23/00/025/W02/W02 <TJM>
DESCRIPTION M.
B
M62320FP-DF5G B
M62320FP-DF5G B
TDA8547TS/N B
NJM12904R-TE1-#ZZZB B
2SB1132 T100 R B
XP6501-(TX).AB B
UNR9113J-(TX) B
UNR9213J-(TX) B
DTA114EUA T106 B
DTB123EK T146 B
UNR9213J-(TX) B
UNR9213J-(TX) B
2SK3019 TL B
UNR9213J-(TX) B
UNR9213J-(TX) B
MA2S111-(TX) B
DAP222 TL B
DAP222 TL B
DAN202U T106 B
MA111(TX) B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
S.=Surface mount
H/V
LOCATION
80.9/34
70.9/26.7
86.1/41.1
80.3/41.3
58/29.5
81.2/41.3
56.4/29.5
67.4/39.9
65.8/38.2
64.9/38.2
67/31.5
55/37.7
54.6/31.9
82.6/28.3
81.2/20.2
74.4/7.6
79.8/29.4
75.8/29
82.6/26.2
87.8/27.1
78.5/20.2
82.4/31.1
63.5/11.4
58.8/35.5
89.8/24.4
82.9/33.6
82.9/23.1
82.9/12.6
38.1/12.9
38.1/30.9
29.2/14.9
29.2/28.9
11.7/14.9
11.7/28.9
H/V
LOCATION
66.7/36
74/36.8
56.8/24.5
76.4/8.7
80.1/20.5
68.7/24.3
72.9/25
83.6/41
70.7/8.4
71.6/11.2
71.8/14.3
75/21
73/16.7
81/32.2
80.9/36
56.7/9
72.8/30.3
63.6/21.7
63.6/25.8
73.8/28.2
56/11.1
73.3/23.2
75.4/24
75.4/25.8
74/14.1
80.4/14.6
77.2/15.5
79.1/14.1
75.8/14.1
87.6/16.2
85.2/41.1
87.5/38.8
81.8/34
79.4/32.4
72.4/31.5
53.6/18.8
54.6/18.8
55.6/18.8
56.6/18.8
