- Page 1 V6908 V6908 IMPORTANT! KEEP INSTRUCTIONS FOR FUTURE REFERENCE. www.fisher-price.co.uk...
-
Page 2: Consumer Information
DO NOT use if any parts are missing or broken. use the high chair in the ® Contact Fisher-Price for replacement parts and instructions if needed. Never substitute parts. upright position. • NEVER leave child unattended. - Page 3 Assembled Parts Seat Back Seat Bottom Base Tray Food Tray Frame 2 Armrests Base 2 Frame Covers Note: Tighten or loosen all screws with a Phillips screwdriver. Do not over-tighten the screws. #8-16 x 1,9 cm Screw – 6 #10 x 1,9 cm Washer Head Screw – 2 Shown Actual Size...
-
Page 4: Back View
Assembly Base • Place the base on a flat surface. Hint: You may need to rotate the base sockets so they are upright, as shown. #8-16 x 1,9 cm Screws BACK VIEW • Carefully turn the seat bottom over. Frame •... - Page 5 Assembly Seat Back Frame Covers BACK VIEW • Fit the frame covers into each frame tube. • Fit the tabs on the seat back into the openings in each side of the seat bottom. #8-16 x 1,9 cm Screws #10 x 1,9 cm Washer Head Screws •...
- Page 6 Assembly Armrests Elastic Loops Elastic Loops FRONT VIEW • Fit the side slots in the pad onto the armrests. Tabs Tabs Crotch Belt Elastic Loops Elastic Loops BACK VIEW BACK VIEW • Insert both elastic loops on the pad through the holes in the footrest area of the seat bottom.
- Page 7 Assembly Waist Belts BACK VIEW Shoulder Belts To change shoulder belt slots: • From the back of the high chair, pull each shoulder belt through the slots in pad and seat back. • Fold the top of the pad down and insert the waist belts through •...
- Page 8 Assembly Secure Child Tabs Tabs WARNING Prevent serious injury or death from falls or sliding out: • The child should at all times wear Elastic Loops a safety harness correctly fi tted and adjusted. The tray is not designed to hold the child in the chair.
- Page 9 Secure Child LOOSEN Waist Belts Crotch Belt To loosen the waist/shoulder belts: • Lift the tabs on the seat back. • From the front of the seat, pull the restraint belts that you would like to loosen. • Lower the tabs on the seat back to secure the restraint belts in place.
- Page 10 Using the Trays WARNING Prevent serious injury or death from falls or sliding out: The child should at all times wear a safety • harness correctly fitted and adjusted. The tray is not designed to hold the child in PUSH the chair.
-
Page 11: Adjusting The Seat
Adjusting the Seat Using the Trays Food Tray WARNING Prevent serious injury or death from falls or sliding out: It is recommended that only children capable of sitting upright unassisted use the high chair in the upright position. Base Tray Hint: Adjust the seat angle to any of three positions: Upright, Semi-Recline or Recline. - Page 12 Adjusting the Seat Storage Hint: Adjust the seat height to any of four positions! PRESS PRESS • Lay the high chair on a flat surface. • Press both storage buttons on the frame and lower the base. To adjust the seat height: •...
