Vidyo VidyoRoom HD-100 Getting Started Manual

Part Number: DEV-ACC-DOC-GSG100-D9020-RD
VidyoRoom™ HD-100 Revision D
Getting Started Guide
What's Included
Your HD-100 Revision D ships with the HD-100 Revision D codec and the following items:

Power cables for the United States, Europe, and
Ireland/United Kingdom – 6 ft (1.82 m)
Depending on your order, you may receive one of the following Pro Pack Accessory Kits or the DVI to USB adapter:
Pro Pack Accessory Kit
Part Number: PKG-ACC-RM-PRO

VISCA to serial cable, EVI control – 6 ft (1.82 m)

DVI to USB 3.0 adapter – includes 3 ft. (.91 m) USB 3.0
cable

USB hub

Sony EVI-HD7 and Phoenix Quattro 3
Separate diagrams in this guide show connections for both the Logitech CC3000e and Sony EVI-HD7V cameras with the Phoenix Quattro3 speakerphone. Additional peripherals sold separately. To view a list of
peripherals compatible with VidyoRoom, go to
Logitech CC3000e

Camera, Speakerphone, Remote Control, and Powered Hub

Wall or table camera mount

Speakerphone to hub cable – 16 in (40.6 cm), USB cable
and Remote control

Adhesive (for mounting hub) and Power adapter
© 2015 Vidyo, Inc. all rights reserved. Vidyo's technology is covered by one or more issued or pending United States patents, as more fully detailed on the Patent Notice page of Vidyo's website
http://www.vidyo.com/about/patent-notices/, as well as issued and pending international patents. The VIDYO logotype is a registered trademark of Vidyo, Inc. in the United States and certain other countries,
and is a trademark of Vidyo, Inc. throughout the world. VIDYO and the Vidyo family of marks are trademarks of Vidyo, Inc. in the United States and throughout the world.

HDMI to HDMI Cable – 6 ft (1.82 m), Qty. 2

DisplayPort to HDMI adapter, Qty. 2
For use with your HDMI or DVI connected cameras (sold separately)

VISCA to serial cable, EVI control – 6 ft (1.82 m)

Serial to USB adapter – 1 ft (.30 m)

DVI to USB 3.0 adapter – includes 3 ft. (.91 m) USB 3.0 cable
http://www.vidyo.com/support/peripherals.

Camera

Power adapter and power cables for United States, Ireland and
United Kingdom, and Europe – 6 ft (1.82 m)

DVI to DVI Cable – 15 ft (4.57 m)

Remote control
VidyoRoom HD-100 Revision D
Pro Pack Accessory Kit (Lite)
Part Number: PKG-ACC-RM-LITE
Sony EVI-HD7

Ethernet cable, Cat5E – 7 ft (2.13 m)

Infrared remote control with 2 AAA batteries

External infrared receiver with USB cable – 6 ft (1.828 m)
DVI to USB3 Adapter
Part Number: DEV-ACC-RM-DXT-D2U3
For high frame rate shares and projection capabilities

DVI to USB 3.0 adapter – includes 3 ft. (.91 m) USB 3.0
cable
Phoenix Quattro3

Quattro3 unit

USB A to USB Mini B cable

Ethernet Cable
