  • Page 1 GE 6610 AC-1...
  • Page 3 The unit is a product in the Getinge range. The unit may also be a sterilizer that is a medical engineering product and which conforms to the EU medical devices directive, or which is constructed in a similar way to a medical device.
  • Page 4 Attention symbols I Some of the warnings, instructions and advice in this manual are so important that we used the following special symbols to draw attention to them. The symbols used are as follows: Warnings This symbol indicates a warning in the text of the manual. The nature of what the warning relates to is such that it may result in more or less severe injury and in certain cases mortal danger.

  • Page 5: Table Of Contents

    SERVICEMANUAL TABLE OF CONTENTS INSTALLATION ..........7 General requirements to be met by the installation location .
  • Page 6 Checking the door action ..........54 Checking and adjusting the door position.

  • Page 7: Installation

    Functional test prior to use. General requirements to be met by the installation location Use Getinge Sterilization AB’s installation drawings for design and building purposes when determining the necessary dimensions and design. Experience has shown that particular attention should be paid to the following points.
  • Page 8 Sterilizers with vertically-operating doors: These models have a generous gap between the front plates of the sterilizer and the wall opening. The gap must be covered with suitable fitting pieces. Getinge sells an add-on system for this purpose. • Sterilizers with horizontally-operating doors There are two variants: either the front plates are designed to lie outside and overlap the wall, or a gap is left between the wall and the plates.

  • Page 9: Unpacking

    Unpacking • Check when unpacking the equipment that the order No. of its data plate conforms with the ordering No. of the documents. • Check that the sterilizer is faultless. Any transportation damage should be reported within seven days to the transport company that was responsible for delivery.

  • Page 10: Connection

    Connection Certain types of installation work, water and electrical, for example, should be done by authorized technicians. If the work is not done properly, injury and damage may result. Faulty installation work invalidates the warranty on the product supplied. Pipework and electrical wiring should be done in a professional manner so that the service compartment looks workmanlike and provides a practical workplace which minimizes the risk of accidents.
  • Page 11 • Check that all terminal screws are tight.. General:Connect the equipment through a nearby multi- pole lockable, safety-marked switch to a three-phase supply with non-disconnectible protective earth conductor. In the planning phase: Concerning voltage and frequency, mains cicuit breaker ratings and wiring sizes, see the document “Technical data”.

  • Page 12: Esd (Electrostatic Discharge)

    must at least be capabable to provide 100 Amps on each phase or have a impedance of Z[ohm]=0,15+0,15*i. • Load-breaking switches in accordance with IEC 898, with B or C characteristic, are recommended for circuit protection. If such switches are not available, protection can be provided by IEC 269-1 fuses, characteristics gG or gM.
  • Page 13 ESD damage. Requirements for protection in installation and servicing GETINGE has ESD protection integrated into the production and test- ing of electronic equipment and also requires ESD protection to be used after delivery for the warranty to apply.

  • Page 14: Incoming Media

    Incoming media General safety requirements for supply lines The document Technical Data states permitted pressure levels for all incoming media. If the stated pressure of the medium does not exceed the design pressure of the pressure vessel , the equipment does not normally have protection against excessive pressure for that medium.

  • Page 15: Connecting Water

    Driving liquid for the vacuum pump TEMPERATURE The highest water temperature for maximum pump performance is 15 C. This temperature may be exceeded by 5 degC if reduced depth of evacuation and pump capacity can be accepted. This applies primarily to sterilizers of the EN model, i.e.
  • Page 16 Back flow prevention must be observed; see Connecting with reverse siphon protection. Connection with reverse siphon protection Any connections made to a drinking water supply must comply with national and local regulations. In countries where EU regulations apply, the national requirements will gradually be complemented by harmonised EN standards, regulating the connection and prescribing equipment for such purposes as reverse siphon protection.

  • Page 17: Steam

    conditions can be connected to pipe systems with a pressure as low as 1.0 bar(e), equivalent to 100 kpa(e) or 15 psig. Precise information about pressures, temperatures, consumption rates and connection size for each medium is given in the Technical Data document. In case of doubt, Technical Data always takes precedence.
  • Page 18 2. For the same reason, liquids must not occur, except very small amounts of water. 3. Gases will prevent close contact between the steam and the micro- organisms to be killed. They must be kept below the proportions below. · Hydrazine (N2H4) max 0.11 mg/kg (ppm) steam.
  • Page 19 (EP) 3rd edition 1997, United States Pharmacopoeia (USP XXIII) and/ or another local pharmacopoeia. Alternatively, steam with a chemical content equivalent to clean steam for sterilization as per HTM 2031 may be used if the user’s local regulations and official requirements allow it. Pressure A See the document “Technical Data”...
  • Page 20 “Technical Data”. If the installation is to be connected to a steam supply at a different pressure, the table can be used for guidance. If in doubt, contact Getinge Sterilization AB. 3. The steam supply pipes should have a fall of at least 1:50 (1/4 inch per foot) in the direction of flow.
  • Page 21 9. Branch pipes should be connected to the top of a horizontal main pipe. 10. A steam sampling point with shutoff valve should be provided between the reducing valve and the sterilizer so that the quality of the steam can be checked. The sampling point can also be used for blow-down in preparation for work that requires the steam system to be depressurized.
  • Page 22 An arrangement as shown below normally satisfies the requirements for dewatering, filtration and monitoring facilities when supplying a sterilizer with steam from a main steam supply line. Feed line in the ceiling (bilder skall ändras 12 t.h. om 4) Supply line in floor or in the storey below (ändr) High-pressure line Vent Labyrinth diverter / separator...

  • Page 23: Compressed Air Quality

    Where the equipment is connected to a common supply of process air and instrument air, the levels recommended below may be unacceptable for process air from a hygienic point of view. Getinge recommends instrument air in the following classes: • Contaminants content Class 3 or better.

  • Page 24: Air Connection

    • Oil content Class 3 or better. Air connection Instrument air only Some equipment in its basic version has only instrument air. Refer to the practical arrangements below. Any non-return valves, filters, etc. are supplied by the purchaser, unless the contract states otherwise. Common supply If the user’s requirements for air quality and the compressed air network can meet the peak loading of the equipment without the pressure...

  • Page 25: Drain

    document “Technical data”. Where information is contradictory, “Technical data” always takes precedence. Main supply line Shut-off valve Filter Pressure gauge Drain Waste pipes coming from different parts of the equipment must not be combined. They must be piped separately to the floor drain without restriction or back-pressure.

  • Page 26: Outlet From Safety Valve

    • The capacity of the waste water system must comply with current regulations. The technical data of the equipment states starting values for the calculation of standard flow in hospital and industrial environments. These calculations must be made in accordance with national regulations.

  • Page 27: Response For Pressure Vessel And Safety Valves

    All sterilizers Bear in mind the heat contribution of the load when unloading and when storing after the process. The load contributes a significant amount of heat to the operator area when the load is unloaded on completion of the process. This heat emission is not stated in the technical specification.

  • Page 28: Functional Check-Up Prior To Use

    Pressure vessel with door(s): If the equipment is provided with pres- sure vessel doors, a description of a safety check is to be found in the DOOR chapter. Only for equipment according to the European pressure vessel directive: The first inspection must be carried out at the latest upon a number of cycles given by the manufacturer on the pressure vessel EEC declaration of conformity.

  • Page 29: Function Check

    FUNCTION CHECK Before use Read all the documentation and check that all supply media are correctly connected to the connection points. • Check that the guidelines of the installation instructions about the connection of supply media are followed: electric power, water, compressed air, steam, etc.
  • Page 30 • If the vacuum pump has jammed, pull off the pump impeller according to the instructions in the COMPONENTS chapter of this manual. • Perform all safety checks as described in the GENERAL ADVICE and The Door chapters. • Check and, if necessary, adjust the supply of sealing water and leak air to the vacuum pump.

  • Page 31: Maintenance

    MAINTENANCE To be done by trained technicians only ESD (Electrostatic discharge) ESD damage in installation and servicing may destroy the electronic equipment. Read the instructions in the ESD section in the INSTALLATION chapter BEFORE starting work. Overview of safety devices Cladding and front panels must prevent access to the parts of the installation that are normally accessible only to trained personnel.

  • Page 32: Maintenance Plan

    For this reason, they must not be replaced with components of any make or design that has not been approved by GETINGE AB. It is of the highest importance that the operational reliability of these components is continuously upheld during the entire service life of the installation.
  • Page 33 equalisation takes too long. In any event, the filter must be changed at least once a year. Replacing the sterile filter Depending on use, number and size, the filter should be replaced, in the event of a breakdown or according to local regulations, but in any event at least once a year.
  • Page 34 Quarterly • Carry out the maintenance under “Monthly”. • Check the door seal. If necessary, lubricate or replace the seal. See the section on DOOR. Note that special operating conditions and/or media quality may require shorter or longer intervals. • Perform a leaktightness test by running the Leakage test process.
  • Page 35 • If the seal is not intact, the valve must be replaced. Alternatively, an authorized person from the pressure vessel authority can be called to re-inspect and re-seal the valve. If the seal of a safety valve has been broken, the opening pressure may have been changed.

  • Page 36: Cycle Counter

    0.01 x P(a). Calibration of pressure sensors, see CONTROL UNIT. If the pressure sensor of the unit is removed, the gasket must be replaced with a genuine Getinge spare part. • Check and adjust the water level in the feedwater tank so that it is about 12 mm below the overflow.

  • Page 37: The Eco Water-Saving System

    The ECO water-saving system Patent pending PCT/SE94/00998 The autoclave is fitted with the ECO (economy-ecology) water-saving system. This means that the water systems of the autoclave are divided up into two separate pipe networks. One system contains water that has come into direct or indirect contact with the items, and has consequently been contaminated.
  • Page 38 Recovery of cooling water Connections A and B are normally linked, but if the water in the cooling water circuit is to be re-used as process water, then A and B will be separated. Water via connection A will be used exclusively for sealing water for the vacuum pump and, in certain cases, also as feed water for the steam generator.
  • Page 39 Warranty conditions and warranty period are described in the commercial documentation. See the order confirmation that governs the terms of delivery for this unit. Service Contact your local GETINGE representative GETINGE Service Team International dept. Phone: +46 35-15 56 36...

  • Page 41: Advice And Instructions

    ADVICE AND INSTRUCTIONS Manual interventions in the process When faults occur during a process because of interruptions in the supply of media or component faults, the process may, after an alarm has been triggered, get stuck in a phase from which the control equipment cannot proceed.

  • Page 42: Faulty Analog Sensor

    Faulty analog sensor If an analog pressure sensor or temperature sensor becomes faulty during a process, the process stops. The type of fault does not allow restarting of the process, since the sensor fault persists after acknowledgement, even if it is not indicated again. Another consequence of a faulty analog sensor is that no pressure or temperature controller becomes operative.

  • Page 43: External Safety Interlock Fault

    Normally the operator is informed at the start of the next process if an output is set to manual mode. Despite this, the status must always be reset to auto mode immediately on completion of work. When using this method, the blocks that prevent hazardous situations from arising are removed.

  • Page 44: Backup Battery Fault

    5. Check that interlock faults have not been activated after completion of a process. Backup battery fault If there is a fault in the control system backup battery, an alarm is triggered when the current process has ended and the control system has returned to the standby phase.

  • Page 45: Restoring Software From E-Prom (Cold Start)

    The above method may only be used by technicians who are thoroughly familiar with the process, the properties of the load and the functioning of the individual components. Note: If the control unit PROM is to be used to restore the software by a “cold start”, when the unit has been brought to a safe mode, all changes made and calibrations done since delivery are deleted.

  • Page 46: Manual Door Opening

    Manual door opening The following important steps must be taken into consideration before a door is opened after manual intervention. • Identify the valve that is to be operated, to be sure that it really is the proper valve. • Manually open a drain valve, to drain the chamber of liquids.
  • Page 47 See also the section on setting the parameter values in the CONTROL SYSTEM chapter. Suitable settings for steam sterilizers with different types of goods are described in the separate Getinge guide STERILIZATION WITH STEAM.
  • Page 48 Maintenance codes Time-based or cycle-based intervals can be programmed so that the unit keeps track of when maintenance is needed. A number of intervals are alr eady progr ammed on de li ve ry, in acc ordanc e w ith the recommendations in the MAINTENANCE chapter.
  • Page 49 The autoclave number is an identification of a particular autoclave which is used in communication between operator control panels or GETINGE programs. The number, which must be in the range 1 - 99, also serves as an identification on printed listings of process data and thus makes the lists traceable.

  • Page 50: Safety Valve Check

    Safety valve check Raising the pressure and checking the unit The following pressure testing of safety valves can be done on equipment supplied with incoming media at a pressure above the opening pressure of the safety valve. Checking of safety valves on equipment with a lower pressure or safety valves combined with a bursting disk is described below under Testing in a test rig.
  • Page 51 310±16 kPa(e) / 45±2 psig 340 kPa(e) / 50 psig 3.5±0.18 bar(e) 3.85 bar(e) Rated pressure of valve ±5% Rated pressure of valve +10% Testing in test rig Equipment supplied with media at a pressure below the opening pressure or equipment fitted with a bursting disk in combination with a safety valve cannot be pressure-tested on the unit.

  • Page 53: The Door

    THE DOOR General The opening and closing motion of the door is executed by a pneumatic cylinder. The door motion speed is controlled by adjustable chokes in the cylinder admittance pipe. As a safety measure there is a squeeze protection integrated in the top of the door. When the door is completely closed, it is locked mechanically.

  • Page 54: Media To The Chamber

    Media to the chamber Before media can be admitted to the chamber, all the requirements below must be met: A Emergency stop not activated B Door(s) closed. C Door seal pressurized. D Control system giving a control signal to open the media valves. Checking the door action The speed of motion of the door can be changed with the variable restrictor in the air line to the door cylinder.
  • Page 55 4. Insert a prop under the door and lower the door until it rests on the prop. Make sure the door is resting securely on the prop. 5. Loosen the support bracket (A) and adjust the door to the measurement, then tighten the screws. 6.
  • Page 56 4. The door must cover the chamber symmetrically, with the minor deviations that may be required for the clearance to the cladding plates. 5. When adjustment is complete, secure the side guides with the nuts C. IN DEPTH This adjustment may be necessary if the distance between the door and the chamber is not correct.

  • Page 57: Removing The Door

    7. Remove the metal strips. The setting of the door locking mechanism must be checked after adjustment. See under “Interlocking of the start function”. Removing the door 1. Open the front. 2. Place a block or similar to stop the door about 150 mm from its final position when lowered.
  • Page 58 7. Loosen the eight nuts D and remove the screws C together with the two guides. 8. Lean the top of the door away from the sterilizer and lift it out. The door weighs about 75 kg.

  • Page 59: The Door Seal

    The composition of the material, the design of the seal, its fitting and care are of extreme importance for reliable operation and long life of the seal. GETINGE's door seal consists of a special silicone material, and its physical design is intended to make best use of its special characteristics.

  • Page 60: Lubrication And Replacement Of The Door Seal

    • If the steam valve for the sealing groove does not close, or if the drain valve does not open, the door cannot be opened after the test as a result of friction against the door seal. The same thing will occur if the seal has hardened or if the absence of its lubricant layer has caused it to fasten in the sealing groove.
  • Page 61 reduce the force behind this movement, and it could severely crush a hand etc. Removal and cleaning 1. Remove the gasket from the groove. Be careful with the seal and the groove. 2. Carefully clean the seal groove. · First remove any coatings of hardened lubricant with a very fine emery cloth (no coarser than 320 grit) ·...

  • Page 62: Replacing The Door Cylinder

    4. Press the seal join into the middle of the upper horizontal part of the groove. 5. Secure the seal in the middle of the straight parts of groove so that its excess length is equally distributed between the fixing points. 6.

  • Page 63: Replacing The Piston Seal

    4. Remove one of the safety plate attachment screws and push the plate towards the empty screw hole until it loosens at the opposite end. The door will now be pushed forward by the spring. Beware of the risk of crushing when the prop and/or safety plate is/are removed.

  • Page 64: Door Safety Arrangements

    2. Remove the cylinder attachment plate. 3. Twist the cylinder end plate until the end of the locking wire appears in the locking wire hole. 4. Twist the cylinder end plate in that direction which feeds the locking wire out of the hole. The wire may need help from a tool to enter the edge of the hole.
  • Page 65 which this plate makes the exhaust valve open, thereby stopping the upward motion immediately. This will prevent personnel injuries and material damage. Safety check The safety check shall be performed in the early stage of the door- closing operation. This in order to reduce the risk for injuries due to squeezing.

  • Page 66: Blocking The Start And Opening The Door

    Blocking the start and opening the door To prevent the door from opening by its own weight in case the pneumatic door cylinder should become depressurized, a brace underneath the door keeps it in closed position. The brace is brought in stop position under the door by spring-force 20 seconds after a door closing command has been given.

  • Page 67: Blocking The Media Supply To The Chamber

    Blocking the media supply to the chamber Media supply to the chamber requires several safety systems to be intact. The systems are all independent of the control system and cut off the electric power supply to the media valves. Limit switches A limit switch senses that the door is fully closed before the signal is passed to the media valve.
  • Page 68 function, nor with ethylene oxide sterilizers. On these, each door has its own pressure switch. Identify the components involved by referring to the electrical and pipework diagrams of the sterilizer. The pressure switch operating pressure is shown on the pipework diagram. Setting 1.

  • Page 69: Safety Interlocking Of The Door Opening

    9. Reconnect the pipe to the pressure switch and refit the pressure switch cover. 10. Open the incoming steam and air supplies. Blocking the door motion and the door seal mediums The supervisory system is doubled: 1. Through the hardware, with a pressure switch sensing the pressure in the chamber.
  • Page 70 To prevent door opening at high pressure, the pressure switch is wired to break the interlocked signal /5027 before the pressure in the chamber reaches 0.2 bar(e) / 20 kPa(e) / 3 psig. Getinge recommends using a reference instrument for pressure measurement.
  • Page 71 4. If necessary, repeat the above setting procedure. Always end with a safety check. The control system Adjustment The safety interlocking provided by the control system is not adjustable, since the pressure limits for allowing the door to open are programmed in the software.

  • Page 73: Control Unit Pacs 3000

    CONTROL UNIT PACS 3000 The letters PACS stand for Programmable Autoclave Control System. The purpose of the control system is to issue orders and send them to the executive components of the unit so that a number of process steps are performed in accordance with a predetermined template.
  • Page 74 A number of special terms STERILIZATION refers to the entire series of treatments that make up a process aimed at achieving the total killing of all living organisms. This applies to sterilizers and usually includes air removal, heat treatment and a drying phase. STERILIZING refers to the actual killing part of the process, the heat treatment.
  • Page 75 goods, there is no need for temperature-sensitive products to be exposed to a high temperature for longer than is necessary to make them sterile.

  • Page 76: Operating Panel Type Op 30

    Operating panel type OP 30 0 0 : 0 3 : 0 0 0 0 : 1 2 : 0 0 1 2 1 . 1 S T E R I L I Z I N G T I M E R E M A I N I N G T I M E S T E R I L I Z I N G...

  • Page 77: Display

    Reset the alarm. Startup Display The display is divided into a number of windows in which information about the process appears as described below. Fields 1 - 3 Process parameters Program number, program name and process time Field 4 Phase number, phase name and phase time Field 5 Process window Field 6...
  • Page 78 Function keys 1. Five labels for the function keys appear at the bottom of the character window. The texts (max two lines of seven characters) are centred in a window. 2. The key texts always appear in the same place. Example: if the HEM function is active on any of the display, it always appears in key position two.
  • Page 79 are more fields below it, pressing the down key causes the list to scroll up one row at a time. The same applied when scrolling in the opposite direction. 5. All selectable list boxes and choices operate as rotating lists. This means that, if you press the down key when the last choice is selected (highlighted), the first choice in the list is selected.
  • Page 80 • Editing alphanumeric fields – A keyboard is displayed above the current screen display. The keyboard is not transparent. A cursor appears where the field value is located. The field value is empty. The first key on the keyboard is selected. The arrow keys are used to access a character.

  • Page 81: Operator Menu Tree

    Operator menu tree CHOSEN BASIC DISPLAY MENU CHOOSE PROGRAM BATCH DATA MORE... EDIT VALUES PROCESS VALUES CURVE DIAGRAM BAR CHART EXTRA PRINTOUT CHOOSE PACS SYSTEM MENU APPARATUS INFO Description of operator menu tree Chosen basic display The control system has three ways of reporting on the process. The basic setting is defined in the system menu and is described in the service manual.
  • Page 82 When the function has been chosen, a new display with the following options appears: 1. CANCEL – return to previous menu display 2. HOME – return to basic display 3. NO – return to previous menu display 4. YES – print out the latest process and return to the previous menu display Choose PACS This option only appears if the panel is connected to more than one...
  • Page 83 Batch This option is only available if the function has been defined. A PC is required to define this function. Entry of batch data Defined values are entered with an alphanumeric keyboard. Press SAVE to save entered data. Menu This function is only displayed in situations where one of the pre- programmed functions is active.

  • Page 84: System Menu

    System menu SYSTEM PASSWORD CALENDAR CALIBRATION MANUAL CALIBRATION AUTOMATIC CALIBRATION BRIDGE COMPENSATION TABLE DOCUMENTATION PRINT PRGM SETTINGS CONFIGURATION NAME AND ADDRESS LANGUAGE, DATE AND UNITS PRINTER LOG VALUES PANEL SETTING ALARM CLOCK PACS ADDRESS PASSWORD DIP SWITCHES SERVICE ERROR LOG DIAGNOSTICS TEST ANALOG INPUT TEST ANALOG OUTPUT...
  • Page 85 Calendar Use the arrow keys to move the cursor to the task you want to change. Press ENTER to choose. Use up-arrow to increase the value and down- arrow to reduce it. Use the left and right arrow keys to move to the next digit/number.
  • Page 86 enter a name. To quit, press ENTER. In the next menu display, choose SAVE or CANCEL. Documentation In this menu you can choose to print out program documentation (phase list and parameter list) for chosen programs or for all programs. Configuration Name and address Use the up/down arrow keys to select the item to be edited.
  • Page 87 Passwords A list of names, valid passwords and access areas is displayed. Use the arrow keys to select the item to change and press ENTER to make it editable. Use the up/down arrow keys to change the value and press ENTER when the change is complete.
  • Page 88 In the SET field the operator can specify the value to which the output should be set. The limits for the value field are 0.0 - 100.0%. Note that MANUAL mode must be selected, otherwise the value will be ignored.. Remember to reset the MODE to AUTO before quitting the menu.

  • Page 89: I2C-Link Faults On Pacs 3000 Modules

    LEDs and buzzer When TEST is pressed, the LEDs light up and the buzzers sounds intermittently for five seconds. Save RAM in Flash With this function you can save the content of the RAM in a Flash memory if there is one. C-link faults on PACS 3000 modules.
  • Page 90 Example: DIP settings Module DIP number number Digital 4. 3. 2. 1 Calculation 0000 on on on on 0 + 0 + 0 + 0 = 0 0001 on on on off 0 + 0 + 0 + 1 = 1 0010 on on off on 0 + 0 + 2 + 0 = 2...
  • Page 91 1 = off 4 = on The same applies to digital outputs (DO) on pages that begin with “5”, for example 50 for DO module “0”, 51 for DO module “1”, etc. If you look closely at the module you can see the word “ON” printed on the DIP-switch case.
  • Page 92 Manual check of I C faults Fault tracing: 1. Check that the I C cables and the power supply AC1 - COM - AC2 – are correctly connected to all modules. The voltages AC1 and AC2 are 18 V to COM, ie 36 V between AC1 and AC2. 2.

  • Page 93: Technical Data, Pacs 3000

    Technical data, PACS 3000 Adaptation to mains voltage by means of transformer 2 * 18 ±10% V AC, 50 - 60 Hz Power consumption depends on the size of the system < 100 VA Permitted ambient temperature in service +10 — +60°C Moisture resistance of control system 90% rel.
  • Page 94 Type and number of analog inputs per module: 4 general purpose 0 - 20 mA 0 - 5 V 0 - 10 V 4 - 20 mA Type of analog input: A. Temperature Sensor Pt 100 only four-wire Resolution 0.1 °C Inaccuracy ±0.1 °C Range...
  • Page 95 Type of analog input: E. Pressure Sensor Wheatstone bridge 0 - 500 mV/v Resolution 0.001 bar(a) Inaccuracy ±0.01 bar(a) within 0 - 1 bar(a) ±1% of actual value within 1 - 5 bar(a) Range 0 - 5 bar(a) Type of analog input: F.

  • Page 97: Components

    The thermal paper has been specially developed for the GETINGE panel printer in order to withstand particularly severe requirements in respect of heat resistance, resistance to fading and permanent documentation.
  • Page 98 The printer also logs all alarm messages that occur during the cycle. The printer has a paper take-up reel which is large enough for the entire reel of paper. If printouts for separate loads are required, this reel can be removed. The printout is retained under the paper cover until the operator opens the cover and tears off the printout.
  • Page 99 To tension the paper without feeding more paper: 1. Press and release FEED. Then immediately press and hold FEED. The reel tensions the paper. 2. Release FEED. Printing out a copy of the log To print a copy of the previous process, press and release COPY when the unit is in standby mode.
  • Page 100 • Separate printouts – to collect individual printouts for each cycle: STATUS 00-01G For separate small printouts the paper is fed out through the slot in the cover. Keep the cover closed when the slot is used. Tear off the printout after each process before the sterilizer door is opened.
  • Page 101 CHANGE ROLL REMOVE THE USED CORE STATUS INSERT A NEW CORE STATUS ALIGN NOTCHES WITH TABS INSERT A NEW ROLL STATUS LOAD THE PAPER STATUS • PRESS AND RELEASE • THEN PRESS AND HOLD FOR 1 REVOLUTION 01-00-D...
  • Page 102 REMOVING THE TAKE-UP REEL The printer has a take-up reel which is large enough for the entire reel of paper. The printout is kept behind the transparent cover until the cover is opened and the printout is torn off or the reel is removed. 1.
  • Page 103 Wind up at least one turn of paper. 6. Release FEED. Close the transparent cover. Storing and handling paper rolls Use only genuine GETINGE paper for the best printout durability. The printer uses only a special heat-sensitive paper. The printer cannot print on ordinary paper.

  • Page 104: Vacuum Pump Lem 50

    Vacuum pump LEM 50 Variants Item no. Volt Notes 479 04 20-01 200-254/350-440 479 04 20-02 200-254/350-440 570 01 13-01 220-254/350-440 larger motor 570 04 17-01 220-240/380-415 570 04 17-02 220-240/380-400 The direct-on-line starter cutout current should be set to the value stated on the motor data plate.
  • Page 105 Method A: 1. Restrict the water as much as possible without the pump running unevenly, then open the valve slightly to ensure a sufficient flow of water. If the pump getts too much water, cavitation will occur. If it does not get enough, its performance will drop and getting a deep vacuum may be difficult.
  • Page 106 Servicing The purpose of the following instructions is to make easier any form of work that involves dismantling the pump. 43.30 Mechanical seal 10.10 Pump housing end plate 90.90 Adjusting nut 13.70 Guide plate 23.50 Impeller 10.90 Pump housing 90.30 Plug 52.50 Spacer...
  • Page 107 Dismantling 1. Remove the hexagon screws in the pump housing end plate (90.10). 2. Separate the pump housing end plate (10.10) together with the guide plate (13.70) from the pump housing (10.90) by prising at the centering groove with a screwdriver, for instance. Take care of the plastic balls (75.40).
  • Page 108 Check that the key is in place in the keyway before assembly begins. Take care to prevent dirt, foreign bodies and excess sealant getting into the pump housing. The following general recommendation concerning tightening torques for screws and nuts must be observed. Thread: Torque: 8.5 Nm...
  • Page 109 11. Re-check the clearance when the locknut has been tightened. 12. Where applicable, apply sealant to the treads of the special screw (90.31) and screw it into the impeller (23.50). 13. Place the valve balls (75.40) at their positions in the pump housing end plate (10.10).

  • Page 110: Pressure Transmitter

    • If required, tap carefully on the loosened housing. • Tighten the screws, in rotation checking that the shaft is free to rotate. Reset the lockable switch and check by brief manual operation of the contactor that the pump works normally. Pressure transmitter The control system uses the pressure tranmitter to measure the pressure.
  • Page 111 Temperature limits -20 - +70 Contact ratings 5A / 250 V Contact situation at atmospheric NO (3) pressure with the type (1) C 469 56 96 NC (2) With type 02, the contact situation depends on whether the switch is set for change over at sub- or overatmospheric pressure.

  • Page 112: Solenoid Valves

    Solenoid valves Hum from a solenoid valve may be a forewarning of overheating due to abnormally high electric current through the solenoid. Generally an alternating current rises when the circuit impedance decreases and this happens when the solenoid is no longer surrounded by a closed iron circuit.

  • Page 113: Pt 100 Sensor (Rtd)

    Foreign particles in the valves may block the valve in the open position and cause leaky operation, so that open doors close or media valves accidentally open, for example. Observe extreme cleanliness when working on control valves. Be aware of the risk of foreign particles in the valves, which may cause unintended operation.

  • Page 114: Piston Valves

    A = White B = Red C = Blue D = Yellow Piston valves Piston valves are used for various media as shut-off valves or as control valves with an on/off function. Such valves are normally maintenance- free, and so any maintenance or replacement is determined by long-term wear or by seal damage.

  • Page 115: Filters And Strainers

    connected to the sterilizer chamber, the easiest way to detect such leakage is by means of a leak test of the sterilizer. Pressurise the actuator with compressed air when removing the valve body to replace the stem seal. This will compress the closing spring.

  • Page 116: Soldered Plate-Type Heat Exchangers

    Pressure testing will reveal any leakage. Cleaning Our first recommendation for cleaning is an environment-friendly and harmless cleaning agent produced specially for GETINGE plate-type heat exchangers. The agent, trade mark “Limeclean” contains special ingredients. It should not be confused with similar products available on the open market.
  • Page 117 acids below, if the position of the connections, etc, makes this possible. · 5% phosphoric acid · 5% oxalic acid · 10% citric acid Do not use other acids or other concentrations than those listed above. Working with acids may be dangerous. Follow the instructions and safety regulations of the chemical suppliers.

  • Page 119: Scrapping Instruction

    SCRAPPING INSTRUCTION • When taking apart compressed air controlled piston valves, com- pressed air must be used due to the spring load in the actuator. • When dismounting doors and chamber care has to be taken due to the weight of the items. •...
