4.3 Technical Specifications
GENERAL
Input Power
Below are power consumption estimates:
Ethernet Port
Serial Port
LAN Protocols
Networking
Configuration
Security
Physical
Size
Housing
Weight
Environmental
Operating Temperature Range
NOTE
Operating temperature range may be reduced based on model configuration. See product label
for detail.
Caution:
This device may exceed safe handling temperatures when operated in an ambient temperature
above 55°.
Agency/Regulatory Approvals
FCC
MDS 05-7280A01, Rev. A
6 to 36 VDC, 1.0 Amp max. 6.0 Watts maximum (NET9L)
6 to 36 VDC, 1.6 Amp max. 9.6 Watts maximum (NET9S)
Table 4-1. TransNEXT Power Consumption:
Mode
NET9L
Receive
760 mw 970 mw
Transmit
6.0 W
RJ-45 10/100 Mbps Auto-MDIX
RJ-45, supporting RS-232/RS-485
802.3 (Ethernet), TCP/IP, ICMP, ssh, http/https
N/A
Serial console, SSH, HTTP/HTTPS
Secure Boot, Signed Firmware, Roll-based Access Control
5.3" long (13.46 cm), 3.8" wide (9.65 cm), 1.6" high (4.06 cm)
Die-cast Aluminum
1.25 lbs. (0.57kg). without mounting hardware
°
°
-40
C to +70
C
NET9L (Lite) – E5MDS-NET9L
MDS TransNEXT Technical Manual
NET9S
9.6 W
53
