  • Page 1 WDR-516S Installation Guide...
  • Page 2: Fcc Compliance Statement

    FCC Compliance Statement Caution : Any changes or modifications in construction of this device which are not expressly approved the party responsible for compliance could void the user's authority to operate the equipment. NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 3: Important Notice

    516S from water, moisture, or temperature (higher or lower than specifications). To clean the WDR-516S, gently wipe the outside with a clean dry cloth. 3. Be sure to use a DC adapter that is provided by DENTEC Corp. Connecting WDR-516S directly to an AC current will cause electric damages to WDR-516S.
  • Page 4: Table Of Contents

    OVERVIEW... 7 What is WDR-516S?... 7 Supplied Accessories... 8 Description & Function ... 9 INSTALLATION AND CONNECTION ... 11 Connecting & Running WDR-516S ... 11 4.1. Connecting camera...11 4.2. Connecting Monitor... 12 4.3. Connecting Audio ... 12 4.4. Supplying Power... 13 Running OSD menu ...
  • Page 5 Connecting RS232... 32 12.1.2. Connecting RS485... 32 12.1.3. Connecting RS422... 32 12.2. Configuring Serial Port ... 33 Connecting USB Device ... 34 Connecting External Storage ... 36 14.1. IEEE1394 Bay... 36 14.2. Connecting IEEE1394 Device ... 36 WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 6 Registering & Formatting HDD... 37 Network Monitoring & Managing ... 38 15.1. Connecting Ethernet ... 38 15.2. Configuring WDR-516S’s Network Information ... 39 Using WDR Manager ... 40 16.1. PC System Requirements for running WDR Manager ... 40 16.1.1. Installing WDR Manager ... 40 16.1.2.
  • Page 7: Overview

    OVERVIEW 1. What is WDR-516S? The WDR-516S is a 4-Analog, 12-IP channel network digital video recorder. The WDR-516S can record and display 4 analog video channels and 12 IP video channels simultaneously. Video, Audio, and Text Event-Logs are digitized and stored on two internal hard-drives.
  • Page 8: Supplied Accessories

    2. Supplied Accessories Unpack and check all the items as below. 1. WDR-516S (1) 3. AC Power Cord (1) 5. Remote Controller (1) 7. Plug Bracket (1) WDR-516S Installation Guide 2. DC Power Supply (1) (110V~220V) 4. CD-ROM (Including WDR Manager) (1) 6.
  • Page 9: Description & Function

    3. Description & Function WDR-516S Front (1) LED (2) IEEE1394 connecter (3) Remote controller receiver (4) USB connecter (5) Function buttons (6) Bracket fixing hole for rack mount WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 10 (13) Terminal block for Sensor input (14) Terminal block for Relay output (15) Video output for MONITOR or VCR (16) Video input type/impedance select & remote controller switch (17) IEEE1394 connecter (18) USB connecter (19) Power connector (DC12V) (20) GND WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 11: Installation And Connection

    INSTALLATION AND CONNECTION 4. Connecting & Running WDR-516S 4.1. Connecting camera (1) Connect CCTV camera to WDR-516S with BNC cable as shown below. (2) Set video type (NTSC/PAL) by rear panel’s switch. <Note> The video type for all channels should be either NTSC or PAL. NTSC is the standard used in North America.
  • Page 12: Connecting Monitor

    (1) Connect CCTV monitor to WDR-516S with BNC cable as shown below. <Note> WDR-516S has two video output ports ; for Monitor and VCR. The output signals from the two ports are same and either port may be used. 4.3. Connecting Audio (1) Connect audio signal to WDR-516S.
  • Page 13: Supplying Power

    4.4. Supplying Power (1) Connect power cable to WDR-516S. (2) Turn on the power switch located on the WDR-516S rear panel. <Note> Use the plug bracket to secure the power cable if needed. <Note> To connect EARTH, refer to the following picture.
  • Page 14: Running Osd Menu

    [◄ or ►] or [▲/▼] arrow buttons. After the value is set, press the [EXIT] button. To exit the Setting Page, press the [EXIT] button. (4) Help message: Related information for each menu/setting will be displayed here. WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 15: Dialogue Box To Edit A Word

    The following symbols are for executing specific functions: : Enter : Back Space & delete : Space ◄ : Move to left ► : Move to right : Previous Code Page : Next Code Page WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 16: Setting Remote Controller

    Set the remote control DIP switch to “ON.” 6.2. Set ID of WDR-516S When controlling several WDR-516S with one remote controller, set Remote Control ID as follows. (1) Press [MENU] button. (2) Select “System” with using [►] button and press the [ENETR] or [▼] button.
  • Page 17: Selecting Wdr-516S

    If several WDRs are set with unique ID numbers, they can be controlled with one remote controller. To select a specific WDR-516S, press the ID button of remote controller until the 8 LEDs on the front of the WDR-516S light up and a buzzer sounds.
  • Page 18: Operable Range Of Remote Controller

    6.4. Operable range of remote controller 6.5. Loading the batteries into remote controller Remote controller requires two AAA-type batteries. 1. Remove the battery cover. WDR-516S Installation Guide 2. Taking care that the poles(+/-) are correctly positioned. 3. Replace the battery cover.
  • Page 19: Wdr-516S Configuration

    7. WDR-516S Configuration 7.1. Basic Configuration 7.2. Advanced Configuration WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 20: External Storage & Backup Configuration

    7.3. External Storage & Backup Configuration 7.4. Internet/Intranet Configuration WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 21: Wdr-516S Basic Setting

    8. WDR-516S Basic Setting 8.1. Viewing Image After initial start-up, images from Ch.1~4 are displayed in a quad-split screen. <Note> If user password is set, a prompt for entering the password will appear. WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 22: Setting Date & Time

    (1) “Daylight Saving Time” is only activated for time zones that use Daylight Savings. If activated, press [ENTER] to enter a new value. (2) Select “On/Off” using the [◄ or ►] button and press the [EXIT] button when finished. WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 23: Time Format

    (1) Select “Apply Date/time” using the [◄ or ►] or the [▲/▼] buttons and press [ENTER]. A warning message will appear. (2) Select “OK” using the [◄ or ►] or the [▲/▼] buttons and press [ENTER]. To cancel, press the [EXIT] button. WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 24: Setting Recording Condition

    Recording conditions under the “Quick Setup” menu tab apply the same values to all analog channels 1~4. All settings are applied for 24 hours/day regardless of the values set for “Time Schedule” or “Alarm Rec.” WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 25: Configuration Status

    When “Recording Speed/Quality” is set as “Custom,” values can be set manually. (1) Select “Speed” using [▲/▼] buttons and press the [ENTER] button. (2) Select a value using the [◄ or ►] button. Press the [EXIT] button when finished. WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 26: Quality

    (2) Select a value using the [◄ or ►] button. Press the [EXIT] button when finished. 8.3.7. Apply (1) Select “Apply” using [▲/▼] buttons and press the [ENTER] button. (2) Setting values are applied and the previous menu will be displayed. WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 27: Connecting And Configuring Sensor

    To connect a sensor to S1, fix the wire to “S1” and “G“. <Note> Devices connected to the sensor input should have “Dry contact.” The following diagram is of an electric circuit with approximately 12mA flows. WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 28: Setting Sensor At Osd Menu

    “On” or “Off.” Press [EXIT] when finished. <NOTE> When activated, the “Pre / Post Alarm” function will cause the WDR-516S to record images at the specified Speed and Quality for a length of time before and/or after the sensor is triggered.
  • Page 29: Connecting & Configuring Relay Out

    10. Connecting & Configuring Relay Out 10.1. Connecting Relay Out WDR-516S has total four ports of Relay Out. To connect a device to “R1,” connect the wires to two “R1”s. <Note> The rated voltage and current of Relay Out are as follows. Do not exceed the rated values.
  • Page 30: Configuring Relay Out

    (Weekday (Day), Weekday (Night), Weekend (Day), Weekend (Night)). Relays can also be control led locally by pressing the [SEARCH/RELAY] button followed by the relay number (1- 4). Relays can also be controlled remotely through the “WDR Manager S/W.” WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 31: Connecting External Device With Serial Port

    11. Connecting External Device with Serial Port 11.1. Connecting Text Input Device (ATM / POS / Access Control) In addition to images, the WDR-516S can record text data received from POS/ATM through the RS232 serial port. Connect RS232 to 9pin D-sub of WDR-516S, and configure the “Text” sub-menu under the “System” tab.
  • Page 32: Connecting & Configuring Serial Ports For Pan/Tilt/Zoom

    12. Connecting & Configuring Serial Ports for Pan/Tilt/Zoom 12.1. Connecting Serial Port The WDR-516S has most major PTZ protocols already pre-programmed. Makes and models not supported can still be controlled using the Transparent Protocol. For a list of supported protocols, refer to the list on the OSD Configuration menu.
  • Page 33: Configuring Serial Port

    After completing serial setup, configure base address and port for each channel under the “Camera” menu tab. When connecting PTZ devices to several cameras, be sure the base address matches the address for the camera. WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 34: Connecting Usb Device

    Output Voltage/Current Max. 200mA per DC 5V / Port <Note> The disk should be formatted with FAT32 type. WDR-516S Installation Guide Stranded Wire: Peel off the wiring cover 8~10mm and solder it. Wire gage should be AWG 22 ~ 26.
  • Page 35 Set copy range (up to 1 minute) Select drive Copy (press “Start”). <Note> USB Flash products that require a Windows program to operate may not be recognized by the WDR- 516S. WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 36: Connecting External Storage

    When using FireWire supported external HDD, hard drive bays can be connected to 1 port in the front panel or 2 ports in the rear panel. The WDR-516S does not supply power to the hard drive bay; therefore only bays that use external power can be used.
  • Page 37: Registering & Formatting Hdd

    (5) Select “Apply” using [▲/▼] button and press [EXIT] button. The HDD status is changed to “[*]”. (6) Select “Action” using [▲/▼] button and press [EXIT] button. (7) Select “Format” using [◄ or ►] button and press [EXIT] button. WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 38: Network Monitoring & Managing

    2) Connect WDR-516S to hub with Ethernet cable. 3) Turn on WDR-516S’s power switch. <Note> 1. Supply power to WDR-516S after connecting Ethernet cable to protect against electrical damage to WDR-516S. 2. Check cable connection status. 3. Check LED on WDR-516S’s rear panel after supplying power.
  • Page 39: Configuring Wdr-516S's Network Information

    15.2. Configuring WDR-516S’s Network Information The following description is on based on Ethernet connection. For more detailed information on the Network Settings Page, please refer to “WDR-516S OSD User’s Guide”. (1) Press [MENU] button. (2) Select “System” using the [◄ or ►] buttons and press [ENTER].
  • Page 40: Using Wdr Manager

    (1) Insert Setup CD-ROM into CD-ROM drive of administrator’s PC (2) Doubleclick the WDR Manager setup file. Install Shield Wizard will be automatically installed. (3) Click the “I Agree” button to accept the license agreement WDR-516S Installation Guide Recommended Requirements P-Ⅲ 1GHz or above...
  • Page 41 (5) Browse and choose a directory if the default directory is not preferred. Click the “Install” button, after selecting a directory to install. (6) Click the “Close” button after WDR Manager program is installed successfully WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 42: Uninstalling Wdr Manager

    (1) Click Windows “Start” Button. (2) Select and Click ‘Uninstall’ icon to run Uninstall Shield. (3) WDR Manager program will be automatically deleted. 16.2. Configstation Click icon on desktop to run “WDR Manager Configstation” program. WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 43: Monitor

    16.3. Monitor Click the related icon and run the “WDR Manager Monitor” program. 16.4. Playback Click the related icon and run the “WDR Manager Playback” program. WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 44: Appendix

    APPENDIX APPENDIX WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 45: Appendix #1 Installing And Replacing Internal Hdd

    Appendix #1 Installing and Replacing internal HDD Compatible HDD It is recommended to use the following HDD models with the WDR-516S. If a non-recommended HDD is used, DENTEC Corp. will not guarantee the warranty. Manufacturer : MAXTOR Series Model No.
  • Page 46 (3) Remove the 6 screws as illustrated below and pull up the cover from the rear part to open SCREW COVER (4) Take out power and data cable of HDD from Main PCB ASS’Y. Remove 4 HDD Bracket screws and take out HDD ASS’Y. MAIN PCB ASS’Y HDD CABLE WDR-516S Installation Guide HDD POWER CABLE SCREW Rev 1.0(93/11)
  • Page 47 (6) Connect HDD power cable to main PCB ASS’Y. Secure the HDD with screws. MAIN PCB ASS’Y (7) Connect HDD cable’s connector to HDD as in the following picture. WDR-516S Installation Guide SLAVE HDD HDD FIXING SCREW 4EA HDD POWER...
  • Page 48 “Disk Manager” will automatically run on start-up after installing a HDD. If “Disk Manager” does not automatically run on start-up, make sure the HDD is properly installed. (9) Press [ENTER] button at “Select Disk”. (10) Select new added HDD (indicated as “[F]”) using [▲/▼] button and press [EXIT] button WDR-516S Installation Guide Rev 1.0(93/11)
  • Page 49 5. [X] HDD cable is not <Note> HDD Managing Command 1. Format : Format as WDR-516S’s file system. Not available to PC file system. 2. Add : Add HDD for recording. Need to format. 3. Add Used : Add a HDD that has been used and formatted. There is no need to reformat 4.
  • Page 50: Appendix #2 Video Input

    Video type / impedance setup switch It’s possible to set up Impedance of Video input line. When one Video output is connected to several Input as below, the impedance of one input should be 75 ohm. WDR-516S Installation Guide REMOTE CONTROL Hi-Z 1 2 3 Rev 1.0(93/11)
  • Page 51: Appendix #3 Using Cd-Rom

    1. Insert the supplied CD-ROM into CD-ROM drive of PC. 2. Open the user’s guide, PDF file. WDR-516S Installation Guide : WDR-516S Installation Guide : WDR-516S User’s Guide : WDR Manager User’s Guide ( WDR-516S Remote Management Program) Rev 1.0(93/11)
  • Page 52: Appendix #4 Specification

    Network Browser Protocol Connector S/W Upgrade Simultaneous Users Security WDR-516S Installation Guide 32bit RISC Processor (200MIPS) 64MB Embedded LINUX 4 Analog Channel & 12 IP Video Channel (NTSC or PAL) Internal 3.5” IDE HDD 2EA External 3EA for IEEE1394 Interface Support Max.
  • Page 53 Input/Output Video Audio Digital Output Digital Output Schedule Sensor Input WDR-516S Installation Guide Max. 120ips (Analog Video 60ips) (IP Video 60ips) 1ch, 4ch, 9ch, 13ch, 16ch, Auto Sequential Max. 60ips 1x, 2x, 4x, 8x, 16x (Forward & Reverse Play) Step-Forward, Step-Reverse 5~45 Cº...
  • Page 54: Ptz Control

    Text Data Recording Electricity Power (Applied Adaptor) Consumption Current Consumption Voltage WDR-516S Installation Guide RS232(1), RS485/422(1), RS232(1) Front panel button & IR remote controller (control IP video channel as well) On-the-screen PTZ control on PC 16 points preset per channel 2x (Live &...
  • Page 55 Mechanical Dimension (WⅹDⅹH) Weight WDR-516S Installation Guide 350ⅹ298ⅹ66(mm) 3.5Kg (With one HDD) RS-232 AUDIO VIDEO VIDEO OUTPUT INPUT COMM. RELAY OUT SENSOR IN RS232 RS422/485 PLAY MULT I SELECT ZOOM IEEE1394 POWER ETHERNET 10/100 REMOTE CONTROL DC12V Hi-Z IEEE 1394...
  • Page 56 Model: WDR-516S Warranty: Full 1 year as of invoice shipping date Manufacture :DENTEC CORP. Email: tech@dentec.com.tw Address: 8/F, No. 116 Hou-Kang St. Shih-Lin Dist, Taipei, Taiwan http://www.dentec.com.tw WDR-516S Installation Guide Rev 1.0(93/11)
