Digital Multiplex Recorder
USER'S MANUAL
Please read the instructions thoroughly before operation and retain it for future reference.
777 W V1.0

Advertisement

Table of Contents
loading

Summary of Contents for Maxtor Digital Multiplex Recorder

  • Page 1 Digital Multiplex Recorder USER’S MANUAL Please read the instructions thoroughly before operation and retain it for future reference. 777 W V1.0...
  • Page 2 WARNING All the safety and operating instructions should be read before operation. The improper operation may cause permanent damage. • Please use the provided adaptor (Other adaptor is not suitable for this machine). • Please lift and place this equipment gently. •...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS What Do You Get What Do You Get • FEATURES -------------------------------------------------------------------------------------- • PACKAGE INCLUDING ---------------------------------------------------------------------- Before Operation Before Operation • INSTALLATION GUIDE ---------------------------------------------------------------------- • FRONT PANEL ---------------------------------------------------------------------------------- • BACK PANEL ----------------------------------------------------------------------------------- Basic Operation Basic Operation • START THIS UNIT ------------------------------------------------------------------------------ •...
  • Page 4 TABLE OF CONTENTS Advanced Operation Advanced Operation • OPERATION OPTIONS ----------------------------------------------------------------------- • KEY LOCK ---------------------------------------------------------------------------------------- • TROUBLE SHOOTING-------------------------------------------------------------------------- • SPECIFICATIONS ------------------------------------------------------------------------------- Appendix Appendix • APPENDIX #1 – INSTALL HDD--------------------------------------------------------------- • APPENDIX #2 – RACK MOUNT--------------------------------------------------------------- • APPENDIX #3 – RECORDING SPEED------------------------------------------------------ •...

  • Page 5: Features

    • Power-loss memory function • Support 2 Removable HDDs, IDE Type • Quick Multiple Search by date/time, alarm, full list • Security password protection PACKAGE INCLUDING Digital Multiplex Recorder(with HDD cartridge) User’s Manual CD-ROM Accessories pack 2 Keys for Cartridge...

  • Page 6: Before Operation

    Manufacturer HITACHI Deskstar 180 GXP (120 GB) HITACHI Deskstar 7K250, HDS722516VLAT20 HITACHI Deskstar 7K250, HDS722525VLAT80 Deskstar 120GXP (80GB) Deskstar 120GXP (120GB) Maxtor DiamondMax 536DX(60GB) 4W060H4 Maxtor DiamondMax Plus 9 Maxtor DiamondMax Plus 9, Model#6Y120L Maxtor DiamondMax Plus 9, Model#6Y160L0 Seagate...

  • Page 7: Front Panel

    FRONT PANEL 1. REMOVABLE HDD CARTRIDGE Please refer to page.46 Appendix #1. 2. MENU Press MENU button to enter main menu. 3. ENTER Press ENTER button for confirmation. 4. ZOOM Press ZOOM button to enlarge the picture display. Press PIP button for Picture in Picture screen. 6.
  • Page 8 7, 9, 10, 13 channels display mode 16 channels display mode 11. LED LIGHT The LED Light is ON under the following conditions. •HDD : HDD is activated •HDD Full : HDD is full •ALARM : If you want to turn off the ALARM LED light, please refer to page.13 and set the Camera / ALARM item as OFF.

  • Page 9: Back Panel

    BACK PANEL 1. POWER Please use the provided adaptor to connect power cord (Other adaptors are not suitable for this machine). 2. EXTERNAL I/O •Controlled remotely by an external device or control system. •Alarm input, external I / O explanation. 3.

  • Page 10: Basic Operation

    START THIS UNIT Before using the DMR, please have the HDDs installed ready. (refer to Appendix #1 for installation or removal of HDDs). Connect the AC Power Cord with Power Adapter and plug into an electrical outlet. The Red LED indicator light will be ON and the DMR is in Standby mode.
  • Page 11 PLAY Press “ PLAY ” button, the DMR will show the last recording. 1. FAST FORWARD (F.F. ) & FAST REWIND (F.R.) You can increase speed for Fast Forward and Rewind on the DMR. In the Play mode, press ” ►► ” once to get 2X speed forward and press twice to get 4X speed,… and the maximum speed can reach 32X.

  • Page 12: Detailed Menu Setup

    MENU SEAR CH TIM ER LA ST R E CO RD D AY FU LL LIST STA RT A LA R M LIST EN D M O TIO N LIST Q U A LITY TIM E SEA R CH TIM ER EN A B LE Detailed Menu Setup M ENU R E CO RD...

  • Page 13: Access Menu

    ACCESS MENU The Menu allows you to configure your DMR settings. Please follow the steps below to access the Menu : Press the Menu button. The password screen will appear: NOTE : The default Password is 0000. Press the Enter button to access the Menu. To key-in the Password, press the “Right”...

  • Page 14: Menu Options

    MENU OPTIONS SYSTEM 1. AUDIO INPUT To choose one of 4 channels to record. ( 2. INT AUDIBLE ALARM To set the INTERNAL AUDIBLE ALARM. It will be trigged by event occurrence when the setting is ON. 3. EXT AUDIBLE ALARM To set the EXTERNAL AUDIBLE ALARM.
  • Page 15 11. NEW PASSWORD : XXXX (Default password : 0000) To set the new password. 12. CLEAR HDD Delete all the contents of your HDD. When you choose “YES” on this option, you will be prompted with the question shown : Press “►” to clear HDD or press ”◄” not to clear HDD. 13.
  • Page 16 TIMER 1. DAY Select the day, or days of the week (Mon–Fri / Sat-Sun / Daily) that you wish to schedule the DMR to auto recording. NOTE : 1.Special Date could be changed by “Enter”, “Up” and “Down” buttons. 2. If you have selected the specific date and recording timer set from that specific day to a new day, then the Recording Timer Schedule will be set as a whole week.
  • Page 17 RECORD 1. HDD OVERWRITE Select “YES” to overwrite previous recording video in HDD. NOTE : When the HDD is full under O/W Recording mode, previous recorded files may be overwritten without further warning notices. 2. RECORDING IPS Select the images per second of recording. The options are as following : NTSC－25A、15、8、4、2、1 PAL－18A、12、6、3、2、1...
  • Page 18 NETWORK ”◄” “►” Press the “▲” “▼” buttons to move the cursor. Press the “+” “-” buttons to change the digit. Press the “MENU” button to confirm the changes/ to exit the menu. Set IP ADDRESS, GATEWAY, NET MASK, DNS and PORT. Choose YES in RESET DEFAULT will go back to default value of NETWORK.

  • Page 19: Motion Detection

    MOTION DETECTION MOTION DETECTION SETUP 1. Press “ MENU “ to enter the menu set up, then “ Down ” to CAMERA setup. 2. Press “ENTER” twice to enter the Motion Detection Setup. 3. Each screen displays the current camera picture overlaid with the motion targets (as Figure 1). You can push the button “...
  • Page 20 Figure 1 MOTION DETECTION SETUP Figure 1-2 MOTION DETECTION SETUP-- LINE EVENT There are only 16 recorded events will be shown on a single page and please press “◄ ” or “► ” to change the pages or press ▲ + ▼ to CLEAR the EVENT record. M-HDD WARNING: Master HDD might be failed.

  • Page 21: Network Setting Guide

    HARDWARE CONNECTION AT DMR SIDE Direct Connect with PC Direct Connect with PC CAMERA Remote Connect Via Internet Remote Connect Via Internet CAMERA Network Setting Guide MONITOR MONITOR...

  • Page 22: Static Ip Setting

    STATIC IP SETTING STEP1: Software installation 1.Put the attached CD into a CD-ROM and it will start to install the application program on Windows PC. 2. Press “Next”. 3.Choose destination location and press “Next”.
  • Page 23 4.Set program shortcuts setting and press “Next”. 5.Press “Next” to copy files 6.After the installation, there are 6 files and 1 folder in your assigned path (file folder) as below.
  • Page 24 Step2 : Static IP setting In DMR MENU / NETWORK set IP ADDRESS, GATEWAY, NET MASK, DNS and WEB PORT which are provided from your local ISP ( internet service provider ). (MENU) SEARCH TIMER RECORD CAMERA SYSTEM EVENT ► NETWORK For example (NETWORK) 61.66.138.74...
  • Page 25 Step3 : Connect PC and DMR via the internet Click twice and enter your User name, Password (Note : If you never change the “Account” before, the default user name and password are both “admin”) and Server IP which you have set to DMR in step 2. Then click OK to connect.

  • Page 26: Dynamic Ip Setting

    DYNAMIC IP SETTING Step1 : Software installation 1.Put the attached CD into a CD-ROM and it will start to install the application program on Windows PC. 2. Press “Next”. 3.Choose destination location and press “Next”.
  • Page 27 4.Set program shortcuts setting and press “Next”. 5.Press “Next” to begin copying files 6.After the installation, there are 6 files and 1 folder in your assigned path (file folder) as below.
  • Page 28 Step2 : DDNS apply 1. Click on free site “http://www.dyndns.org” ( please look at the example below, you can also apply DDNS in other DDNS web page) and “ACCOUNT” 2. Press “Create Account”...
  • Page 29 3. Register the information and click on “Create Account” 4.After registering your account, you will receive an e-mail, which contains instructions to activate your account. If you do not follow these directions within 48 hours, you will need to re-register your account. 5.Login your account.
  • Page 30 6.Click on“Account” and “Add Host” 7 Users can set up their own DDNS HOST. For example, the user’s applied Host name is “TEST”. And then press “Add Host” to finish the setting. (NOTE : Some routers don’t support some DDNS HOST) TEST Step3 : Login router NOTE : The following settings are different from router to router.
  • Page 31 2. Network setting for PC. (The instruction is based on Win XP O/S. If your O/S is Win 2000 or Win 2003, the setup procedure is similar to that of Win XP O/S.) Local Area Connection Click twice Enabled Realtek RTL8139 Family 3.Click “Properties”...
  • Page 32 4.Click on “INTERNET PROTOCAL (TCP/IP)” , then select “Properties” to setup 5.Choose “Obtain an IP address automatically” 6. Enter “Command Prompt”...
  • Page 33 7. In the setting window, type “ ipconfig” to find out router’s gateway(e.q. 192.168.1.1) 8. Close the window in the above step. Enter the IP address ( router’s gateway : 192.168.1.1 ) to log in to the router from internet explore. And then enter the login web page and key in the router’s user name and password.
  • Page 34 Step4 : Router setting NOTE : In the router setting, we have four steps as follows. 1. Dial setting 2. DHCP setting 3. Virtual server setting 4. DDNS setting (◇ The following settings will differ from router to router. Please refer to the user’s manual of router) 1.Press “INTERNER PORT”...
  • Page 35 3. In “ADVANCED SETUP / Virtual Server”. Choose “By Port” and set “Port Number” to 80 for DMR. And set “Local Server IP Address” to 192.168.1.10. Press add after you finish the set up. 4. In “ADVANCED SETUP / Dynamic DNS”. Key in the “DNS Account”, “User Name” and “Password”...
  • Page 36 Step 5 : IP setting In DMR MENU / NETWORK set SERVER IP, GATEWAY, NET MASK, DNS and WEB PORT. (MENU) SEARCH TIMER RECORD CAMERA SYSTEM EVENT ► NETWORK For example (NETWORK) SERVER IP 192.168.001.010 GATEWAY 192.168.001.065 NET MASK 255.255.255.000 168.095.001.001 00080 WEB PORT...
  • Page 37 Step7 : Connect to DMR via internet 1. Change PC network setting to the original setting and link PC to the internet. 2. Click twice and enter your User name, Password and host (Note : The default User Name and Password are both “admin”).

  • Page 38: Software Operation At Client Side

    SOFTWARE OPERATION AT CLIENT SIDE Follow the steps for connection at your client site (remote site). (e.g. If you set up the server at your office with one static IP, you can remotely proceed to watch the video anywhere with a networked computer.) Step 1 twice to enter Login setup (please refer to “software installation”)

  • Page 39: Introduction Of Basic Operation

    INTRODUCTION OF BASIC OPERATION A. Video Web Server control panel 1. Image transmission rate per second 2. Data transmission rate 3. Connection/Disconnection 4. Resolution : D1、CIF 5. Image quality : High、Middle、Low 6. Image adjusting : Brightness/ Contrast/ Saturation 7. Snapshot : press this button, the image will be automatically saved in the PC. 8.
  • Page 40 B. Digital device control panel CH1-16, 4cut, 7cut, 9cut, 10cut, 13cut,16cut, PIP Zoom, Select, Lock, Record Stop, Rewind, Fast Forward, Pause, Slow, Play Menu(Exit), Left, Right, Up, Down Enter TURBO uNOTE： After you press the record icon, there will be a recording file in the path that you have set.Each recording file can be save up to 6000 frames.

  • Page 41: Playback Operation

    PLAYBACK OPERATION Please find a recording file in the PC and click twice on it to playback. 2 3 4 5 6 7 8 9 10 11 12 2004/12/15 09:49:38 2004-DEC-15 [WED] 09:49:33 NTSC_CIF 1. On Screen Display 2. Snapshot 3.

  • Page 42: Advanced Setting

    ADVANCED SETTING Click “System Config” for advanced setting. ACCOUNT ALARM NOTE : Apply-- After changing all setting, press “apply” to refresh the data. Reboot-- SYSTEM CONFIG Press this button to restart the server. Set up the user’s account( Max 10 accounts) , password and authority ( Max 6 accounts on line at the same time) .
  • Page 43 MAIL File Path C:\Documents and Settings\bowbow.huang\desktop C:\Documents and Settings\bowbow.huang\desktop When the alarm is triggered, the video server program will capture the instant picture and e-mail the captured image to the assigned recipients. 1.You can get all the data from the ISP company or by mailing to the server supplier.(POP3/SMTP server) 2.You should set the mail list which you...
  • Page 44 TOOLBOX Online User Upgrade the firmware and get the online users’ information. NOTE :Do not reboot the DMR while it is upgrading the firmware. 1.Firmware Version : The current firmware version. You can click on “Find” button to get the latest firmware from PC and press “Upgrade Firmware”...

  • Page 45: Connect Video Web Server Via Ie Browser

    CONNECT VIDEO WEB SERVER VIA IE BROWSER You can also connect Video Web Server via browser. This function is suitable in both WIN 2000 and WIN XP ( WIN XP is preferable to WIN 2000) Step 1：Enter IP address that you want to connect.(example) 219.84.21.166 Step 2：Enter your Username and Password to login Video Web Server.
  • Page 46 Step 3：After you login, you will see as below. (example) 1.Image transmission rate per second 2.Data transmission rate 3.Video Channel 4. Resolution :D1、CIF 5.Image quality : High、Middle、Low 6.Number of online users 7.Channel switching button 8.Resolution switching button 9.Quality switching button 10.Menu, Left, Right, Up, Down, Exit 11.Lock, Enter, Zoom, Search, Select.

  • Page 47: Advanced Operation

    OPERATION OPTIONS SELECT This device allows user to get the ideal view size. àPress button to make different view size. àPress “ Select ” then “ Left ” or “ Right ” button to locate the desired position. àPress “ Camera Select (1-16) “ to select the appointed camera. àPress “...

  • Page 48: Key Lock

    KEY LOCK For further security, you can “Lock” all buttons on your DMR. Locking disables the buttons and prevents other people from using the system. Press ENTER and MENU at the same time to enable Key Lock. Press ENTER and MENU at the same time and key in password (Default : 0000), then press “ENTER“ to disable Key Lock. TROUBLE SHOOTING RS232 REMOTE PROTOCOL When malfunction occurs with DMR, it may be not serious and can be corrected easily.

  • Page 49: Specifications

    SPECIFICATIONS TROUBLE SHOOTING Video format Network Interface Protocals Trigger & Action Hard disk storage Record mode Camera Input Signal Camera Loop Back Main Monitor Output Call Monitor Output Audio input Audio output Motion Detect Area Motion Detect Sensitivity Video Loss Detection Refresh Rate Recording Rate Dwell Time...

  • Page 50: Appendix #1 - Install Hdd

    APPENDIX #1 – INSTALL HDD Please follow the next steps carefully in order to ensure correct installation. The compartment located on the front panel of the DMR is the removable Cartridge Casing in which you insert the HDD. The various parts of the Cartridge Casing are labeled for your reference. Remove the Cartridge Case from the DMR Cartridge Casing Remove the Cover from the Cartridge Casing...
  • Page 51 Secure the HDD in the Casing (optional) Use the supplied screws and tighten them, and positioning the HDD into place. Slide the top Cover over the Cartridge Casing Slide the Cover forward over the Cartridge Case. Ensure it is secured in place over the release latch. 6.Reinsert the Cartridge Casing into the DMR Fully insert the Cartridge Case into the DMR.

  • Page 52: Appendix #2 - Rack Mount

    APPENDIX #2 – RACK MOUNT Screws and brackets for rack mounting applications can be purchased as an optional accessory. Front Angle with Rack Mount Side View with Rack Mount...

  • Page 53: Appendix #3 - Recording Speed

    APPENDIX #3 – RECORDING SPEED The Record Time is different based on Record Speed and Record Quality. Please refer to following table. NTSC SYSTEM PAL SYSTEM Note: Above data is from actual test data obtained from recording normal TV program. (Reference only)

  • Page 54: Appendix #4 - Pin Configurations

    APPENDIX #4 – PIN CONFIGURATIONS 25 pin com port To connect wire from ALARM INPUT ( PIN 2 -- 9 ; PIN 15-22) to GND ( PIN 1 ) connector, DMR will start recording and buzzer will be on. Ø When Menu/ Camera/ Alarm is set up to “Low” : ALARM INPUT When alarm input signal is “...
