TRENDnet TEW-624UB User Manual

TRENDnet TEW-624UB User Manual

300mbps wireless n usb 2.0 adapter
Hide thumbs Also See for TEW-624UB:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TEW-624UB and is the answer not in the manual?

Questions and answers

Related Manuals for TRENDnet TEW-624UB

Summary of Contents for TRENDnet TEW-624UB

  • Page 2: Fcc Radio Frequency Exposure Statement

    Regulatory notes and statements Wireless LAN, Health and Authorization for use Radio frequency electromagnetic energy is emitted from Wireless LAN devices. The energy levels of these emissions however are far less than the electromagnetic energy emissions from wireless devices such as mobile phones. Wireless LAN devices are safe for use frequency safety standards and recommendations.

  • Page 3: Fcc Interference Statement

    frequency exposure limits. Nevertheless, this device shall be used in such a manner that the potential for human contact during normal operation is minimized. When nearby persons has to be kept to ensure RF exposure compliance, in order to comply with RF exposure limits established in the ANSI C95.1 standards, the distance between the antennas and the user should not be less than 20 cm.

  • Page 4: Ce Mark Warning

    The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be located or operating in conjunction with any other antenna or transmitter. CE Mark Warning This is a Class B product.

  • Page 5: Table Of Contents

    TABLE OF CONTENT Introduction ....................1   Overview of this User’s Guide ................1   Unpacking and Setup .................. 2   Unpacking ......................2   Setup ........................2   Connecting the USB Extension Cable ..............2   Software Installation ................... 3  ...

  • Page 6: Introduction

    INTRODUCTION Congratulations on your purchase of this 300Mbps Wireless N USB 2.0 Adapter. This manual contains detailed instructions regarding the operation of this product. Please keep this manual for future reference. With the 300Mbps Wireless N USB 2.0 Adapter, a desktop or laptop computer can communicate with another computer wirelessly.

  • Page 7: Unpacking And Setup

    This section provides unpacking and setup information for the 300Mbps Wireless N USB 2.0 Adapter. Unpacking The box should contain the following items: One TEW-624UB 300Mbps Wireless N USB 2.0 Adapter One Driver & Utility CD-ROM One Multi-Language Quick Installation Guide One USB extension cable If any item is found missing or damaged, please contact your local reseller for replacement.

  • Page 8: Software Installation

    SOFTWARE INSTALLATION This section describes how to install the driver and utility for the 300Mbps Wireless N USB 2.0 Adapter. Windows Based Utility Installation 1) Insert the Utility and Driver CD-ROM into your computer’s CD-ROM Drive and then click Install Utility. Click on Vista when you are installing this adapter on Windows Vista operation system or XP/2000 for Windows 2000/XP operating system.

  • Page 9: Wireless Utility Setting

    3) Click Finish to restart the computer. 4) Plug the 300Mbps Wireless N USB 2.0 Adapter into an available USB slot on your computer Wireless Utility Setting The user can configure the wireless settings using the Wireless Adapter Configuration Utility. Double-click the utility icon that appears in the taskbar. The Wireless Adapter Configuration Utility is divided into five sections: Link Info, Configuration, Advanced, Site Survey and About.
  • Page 10 Status: Shows the associated BSSID, which can be used to identify the wireless access point. SSID: Shows the current SSID, which must be the same on the wireless client and AP in order for communication to be established. Frequency: Shows the current frequency used for the wireless network. Wireless Mode: Shows the current wireless mode used for wireless communication.
  • Page 11 SSID: Service Set Identifier, which is a unique name shared among all clients in a wireless network. The SSID must be identical for each client in the wireless network. Wireless Mode: There are two modes available for selection ●Infrastructure – to establish wireless communication with the LAN and other wireless clients through the use of Access Points.
  • Page 12 Preamble: Select Long or Short & Long Preamble type. Preamble is a sequence of bits transmitted at 1Mbps that allows the PHY circuitry to reach steady-state demodulation and synchronization of bit clock and frame start. Two different preambles and headers are defined: the mandatory supported Long Preamble and header, which interoperates with the 1Mbps and 2Mbps DSSS specification (as described in IEEE 802.11), and an optional Short Preamble and header (as described in IEEE 802.11b).
  • Page 13 Auth Mode: The following options are available: Open System, Shared Key, Auto, WPA/WPA2 and WPA-PSK/WPA2-PSK. Select Open System, Shared Key or Auto for WEP data encryption feature. Open System and Shared Key requires the user to set a WEP key to exchange data with other wireless clients that have the same WEP key.
  • Page 14 IV. Site Survey This screen allows the user to scan for available wireless networks (wireless clients and Access Points). It also allows the user to establish wireless communications with an available wireless network. Available Network – displays the wireless networks (wireless clients and access points) that are within range.
  • Page 15 Add: Adds a profile. The following screen will appear. The user can enter the necessary information required for accessing Access Points or Wireless Router. V. About This screen displays information about the 300Mbps Wireless N USB 2.0 Adapter, such as the Driver and Utility version. When a new version of the utility becomes available for upgrade, users will be able to identify by version numbers.

  • Page 16: Technical Specifications

    TECHNICAL SPECIFICATIONS Hardware Interface USB 2.0 Compliant Standards IEEE 802.11n draft v1.0, IEEE 802.11b and IEEE 802.11g Antenna Integrated Printed Antenna LED Indicator Activity Power Receive Mode: 260mA Consumption Transmit Mode: 420 mA Supported OS Windows 2000, XP, Vista Dimensions 80 x 30 x 12 mm (3.1 x 1.2 x 0.5 inches) (LxWxH) Weight...

  • Page 17: Limited Warranty

    Three years If a product does not operate as warranted above during the applicable warranty period, TRENDnet shall, at its option and expense, repair the defective product or deliver to customer an equivalent product to replace the defective item. All products that are replaced will become the property of TRENDnet.
