- Page 1 EXPERIENCE THE ASPEN TOUCH Aspen ATM-173R Series Touch Monitor Product Manual...
- Page 2 The information contained in this document is subject to change without notice and should not be construed as a commitment or obligation by Aspen Touch Solutions. Aspen Touch Solutions assumes no responsibility for any errors that may appear in this document, and does not make any expressed or implied warranty with regard to this document, including, but not limited to, any implied warranty of merchantability or fitness for a particular purpose.
-
Page 3: Table Of Contents
Aspen ATM-173R Series Touch Monitor Product Manual Table of Contents Usage Notice ............. . 2 Introduction . -
Page 4: Usage Notice
Congratulations on your purchase of an Aspen Touch Solutions touchmonitor. This manual covers all models of the Aspen Touch Monitor 17" (ATM-173R) series of touchmonitor products. Aspen has brought together a team of experienced developers from the touch industry to create what we believe to be the finest touchmonitors available in the industry today. -
Page 5: Data Connection
Connections and Installation Begin your installation by selecting a data connection. With the ATM-173R monitors, you may use either a serial or USB data connection. All other ATM-173R series models use USB only. Choose the appropriate data cable from the accessory kit included with your monitor. -
Page 6: Osd Controls
Display Setup and On Screen Display Connect and secure cables to the display and the computer, except for the USB cable. The AC cordset provided with your display should be appropriate for your region. If the proper cordset has not been provided, you may use any cordset with an IEC320 connector at the appliance end to connect to the external power supply of your touch display. -
Page 7: Osd Menu And Functions
The complete menu of the OSD is shown in the table below. The Main Menu icon for each menu is shaded, and the individual functions within the group follow: OSD Menu and Function Contrast and Brightness Contrast Controls the display contrast Brightness Controls the display brightness Video Adjustment... - Page 8 Power/OSD Lock/Unlock There is no menu graphic for this feature. The Power/OSD lockout menu is separate from the main OSD. Access this feature by first pressing the MENU button to access the main OSD. While the main OSD is displayed, press and hold the MENU button. The main OSD will disappear. While continuing to hold the MENU button down, momentarily press the POWER button.
-
Page 9: Driver Installation
• If you are using a USB data interface, disconnect it from the computer before proceeding. Connect the touch- screen cable if using a serial interface (ATM-173R only). Insert the disk in your drive. If AutoRun does not start the installation, double click the “Setup” program in the CDROM folder. - Page 10 • Find the Aspen Touchscreen Settings icon in Control Panel, and use the features under the appropriate tabs to configure the operation of the touchscreen for your application, and if necessary, to calibrate the touchscreen to the display image. • The MSR, if present, is configured for keyboard emulation by default. It should work identically to keyboard wedge readers in all applications.
-
Page 11: Specifications
Contrast Ratio Scanning Frequency Horizontal Vertical Video Input Video Bandwidth Input Video Format Plug and Play ATM-173R, ATM-17RM, ATMM-173R ATM-173RO, ATM-173RMO, ATMM-173R 17" Color AMTFT LCD Dark Gray (ATMM: Beige) 5-wire resistive Horizontal 13.3" (338 mm) Vertical Horizontal 16.5" (418mm) - Page 12 HD15(VGA) DVI-D 24pin Standard USB series “B” receptacle (detachable USB cable) Standard DB9 F Serial (ATM-173R only) (detachable serial cable) 3 Track Reader with Power and Error Indicator Light 2 x 20 VFD Display with Dual Axis (tilt & swivel)
- Page 13 Product Agency Approvals Safety Ergonomics Low Emission Warranty UL, cUL, CSA 22.2 No.950 3rd Ed. EN60950 Low Voltage Directive 93/68/EEC EK 1-1TB 2000 FCC/B EN 55022: Class B 1998 EN 55024: 1998 MPR II 1990: 8/MPR 1990:10 3 Year, 24 Hour Advance Replacement...
-
Page 14: Glossary
Glossary AMTFT—Active Matrix Thin Film Transistor. This is the type of liquid crystal display panel used in essentially all computer flat panel displays today. Calibrate—For touchscreens, “calibrate” is the common term for the process that is really “video alignment.” A touchscreen and its controller have a coordinate system that are usually not identical to the coordinate system of the video display of the host computer. -
Page 15: Mounting Template
Native resolution—The resolution of a digital flat panel display that actually describes how many pixels are in each row and column of the display, and which is the resolution that the display is optimized for. Your 17" Aspen touch monitor has a native resolution of 1280 x 1024, which means that the LCD panel has 1280 pixels on each row, and has 1024 rows. -
Page 16: Warranty
Aspen Touch Solutions, Inc. Product Warranty Aspen warrants that the Products will conform to the Specifications and be free from defects in material and workmanship for three (3) years from date of shipment. Customer shall report any claimed defect in writing to Aspen immediately upon discovery, and in any event, within the warranty period. - Page 17 Experience the Aspen Touch. www.aspentouchsolutions.com 31207 Keats Way, Suite 104 Evergreen, Colorado 80439 tel: 303.468.4130 fax: 303.468.4131 toll free: 877.427.7393 web: www.aspentouchsolutions.com email: info aspentouchsolutions.com...
- Page 18 Template will print on one sheet of 11" x 17" paper.
