Introduction
Congratulations on becoming the owner of a 6205 ADSL USB Modem. You will now be able to surf the
Internet via the modem's state-of-the-art ADSL connection.
This document will show you how to set up the 6205 ADSL Modem, and how to customize its
configuration to get the most out of this product.
Features
•
The 6205 ADSL Modem offers up to 8 Mbps downstream and 800 kbps upstream.
•
A plug-and-play USB port provides Internet connectivity to your PC.
•
The 6205 ADSL Modem supports Windows 98FE/SE, Windows 2000, Windows ME, and
Windows XP.
System Requirements
In order to use the 6205 ADSL Modem for Internet access, you must have the following:
•
ADSL service subscription from your Internet Service Provider (ISP).
•
One computer containing a free USB (Universal Serial Bus) port.
•
USB driver provided in this package
Caution:
Do not open the housing!
Use only the cables provided with this device and do not perform any
modifications on them
Review the Important Safety Instructions on page 12
Copyright © 2005
Zhone Technologies, Inc.
6205-A2-ZZ42-00
6205 ADSL USB Modem
Installation Instructions
Document Number 6205-A2-ZZ42-00
December 2005
December 2005
1
Advertisement
Table of Contents
Summary of Contents for Cable & Wireless 6205
- Page 1 December 2005 Introduction Congratulations on becoming the owner of a 6205 ADSL USB Modem. You will now be able to surf the Internet via the modem’s state-of-the-art ADSL connection. This document will show you how to set up the 6205 ADSL Modem, and how to customize its configuration to get the most out of this product.
-
Page 2: Package Contents
Package Contents Your 6205 ADSL Modem package includes: 6205 ADSL Modem CD-ROM Containing User’s Guides and Drivers RJ11 Phone Cable Y-Adapter USB Cable Two Microfilters December 2005 6205-A2-ZZ42-00... -
Page 3: Front Panel
Data transfer over ADSL line Rear Panel The rear panel contains the ports for the unit's data and power connections. Port Description USB port, for connection to your PC LINE RJ11 port, for connection to your ADSL line 6205-A2-ZZ42-00 December 2005... -
Page 4: Usb Driver Installation
USB Driver Installation 1. Insert the provided CD. The CD should automatically start the driver installation. If autorun is disabled, double-click “Setup.exe” in the root directory of the CD. 2. Click on Next when the welcome screen appears. December 2005 6205-A2-ZZ42-00... - Page 5 4. Choose the proper driver type: Freedom Plug & Play or Freedom Prepago/Nocturno. Then click on Next. 6205-A2-ZZ42-00 December 2005...
- Page 6 When a message appears telling you to plug in your modem, connect the modem to your PC using the supplied USB cable. (See Connecting the Cables on page 8.) Click on OK. 6. The installation completion message appears. Click on OK. December 2005 6205-A2-ZZ42-00...
- Page 7 Your user name is: • Your phone number + a + @freedomprepago for Prepago, or • Your phone number + @freedomnocturno for Nocturno. For example: Prepago Nocturno Contact Cable & Wireless if you have not been supplied a password. 6205-A2-ZZ42-00 December 2005...
-
Page 8: Connecting The Cables
Plug the microfilter into one side of the Y-adapter. • Plug another phone cable into the other jack of the Y-adapter and the LINE jack of the modem. DO NOT CONNECT THE USB CABLE TO THE UNIT UNTIL THE DRIVER INSTALLATION IS COMPLETE. December 2005 6205-A2-ZZ42-00... -
Page 9: Usb Driver Uninstallation
USB Driver Uninstallation 1. Click on Uninstall from Windows Start menu. 2. When the confirmation dialog appears, click on OK. 6205-A2-ZZ42-00 December 2005... - Page 10 3. Click on Next to remove the driver. 4. Unplug your USB modem and click on OK. December 2005 6205-A2-ZZ42-00...
-
Page 11: Device Status
Device Status This chapter describes how to obtain 6205 system information when you double-click the small triangle icon on the right-bottom of the taskbar. After you click the icon, you’ll see the status page, which will tell you that the modem is idle, handshaking or operational. -
Page 12: Important Safety Instructions
— Do not use the telephone to report a gas leak in the vicinity of the leak. Customer Support If you require assistance with your modem, call our toll-free number: 800-5555. *6205-A2-ZZ42-00* *6205-A2-ZZ42-00* December 2005 6205-A2-ZZ42-00...
