19-0677; Rev 0; 11/06
USB-to-COM Port Adapter Board User Guide

General Description

The USBTO232 is an adapter board that converts a
PC's USB port into a standard COM port. A COM port is
also known as the standard serial port that uses
Recommended Standard 232 (RS-232).
The USBTO232 is included with selected Maxim EV kits
and EV systems that were originally designed for the
PC COM port and later updated to also support the
USB port. Data sheets for EV kits and EV systems that
can use the USBTO232 have been updated to reflect
compatibility and also provide ordering information.
Use of the USBTO232 in applications other than those
EV kits specified by Maxim is not supported.
Important: Before using the USBTO232, see the Quick
Start section of this data sheet to correctly install the
USB driver for the appropriate Windows
system.
Windows is a registered trademark of Microsoft Corp.
DESIGNATION
QTY
0.01µF ±10%, 50V X7R ceramic
C1
1
capacitor (0603)
TDK C1608X7R1H103K
47pF ±5%, 50V COG ceramic
C2, C3
2
capacitors (0603)
TDK C1608C0G1H470J
0.1µF ±10%, 16V X7R ceramic
C4–C8, C11,
capacitors (0603)
7
C12
TDK C1608X7R1C104K
4.7µF ±10%, 6.3V X5R ceramic
C9
1
capacitor (0603)
TDK C1608X5R0J475K
1µF ±10%, 6.3V X5R ceramic
capacitor (0603)
C10
1
TDK C1608X5R0J105K
Red LED (0603)
D1
1
Panasonic LNJ208R8ARA
Green LED (0603)
D2
1
Stanley Electric BG1111C-TR
Panasonic LNJ314G8TRA
40Ω @ 100MHz, 1.5A ferrite bead
FB1
1
(0805)
Steward MI0805K400R-10
H1
1
8-pin header
JU1, JU2, JU3
3
3-pin headers
________________________________________________________________ Maxim Integrated Products
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim's website at www.maxim-ic.com.
®
operating
DESCRIPTION
o USB Powered
o USB Driver for Windows 98SE/2000/XP Operating
Systems
o USB and I/O Power LED Indicators
o Two GPIO LED Indicators
o USB Cable Included
o 8-Pin Signal Header
o Proven PCB Layout
o Fully Assembled and Tested

Ordering Information

PC
PART
INTERFACE
USBTO232+
USB
+ Denotes lead-free and RoHS compliance.
DESIGNATION
QTY
USB type B right-angle female
P1
1
receptacle connector
Assmann AU-Y1007-R
Short DB9 right-angle male
P2
1
receptacle connector (without
cable-locking screws)
270Ω ±5% resistors (0603)
R1, R2
2
(use lead-free parts only)
USB-to-UART converter
U1
1
FTDI FT232RL (28-pin SSOP)
U2
1
MAX213EEAI+ (28-pin SSOP)
—
3
Shunts
—
1
USBTO232+ PCB
—
1
USB high-speed A-to-B 6ft cable
Component Supplier
SUPPLIER
PHONE
TDK
847-803-6100
Note: Indicate the Maxim EV kit that you are using when con-
tacting this component supplier.
Features
OPERATING SYSTEMS
SUPPORTED
Windows 98SE/2000/XP
Component List
DESCRIPTION
WEBSITE
www.component.tdk.com
1
