Meridian Soloos Control 10 Quick Start Manual page 2

STEP 2 :
NETwork CoNNECTioNS
Attach the Twinstore's network port to a LAN
1
on your router. You can use the Neutrik Ethercon
connector (supplied) with an Ethernet cable of
the appropriate length (not supplied.)
Attach the Control's network port to a LAN port
2
on your router. You can use an additional Neutrik
Ethercon connector with your own Ethernet cable
here as well.
Make sure the wAN /Internet port of this router
3
connects to the rest of your network, or to your
Cable/ DSL modem.
Depending on the make and model of your router,
!
crossover Ethernet cable(s) may be required
to make valid connections to your Ensemble and
Control components.
Meridian Audio Ltd, Latham Road, Huntingdon, Cambridge PE 29 6 YE , United Kingdom
L A N
W A
N
3
2
Connects to
1
Control 10 Connection to
the Internet
PICTURED BELOw
port
L
Tr ig g
e r
C o m
R
m s
S p ea
ke r
Li nk
D ig it
al O u
t
P o w e
r In
2
Connect to a
LAN port on your
network router
PICTURED ABOVE
| www.meridian - audio.com
1
Connects to
a power outlet
3
STEP 3 :
PowEr CoNNECTioNS
Connect the power supplies ( provided) to the
1
rear of each Ensemble, and Control device.
Connect an IEC power cable to each supply.
2
Plug each power cable into a surge-protected
3
power strip.
Power-on each component by rocking its
4
rear-panel power switch.
All external power supplies are auto-sensing,
!
and use universal voltage power supplies.
Rackmount devices with internal power supplies
!
are not auto sensing and must be set to the
proper local voltage...
AC 115 V AC 230 V
NORTH AMERICA EUROPE, ASIA
Meridian Audio Ltd, Latham Road, Huntingdon, Cambridge PE 29 6 YE , United Kingdom
4
2
Detachable
Power Suply
ONE FOR EACH
COMPONENT
4
L
Tr ig ge
r
C om
R
m s
S pe ak
er
Li nk
Di gi ta
l O ut
Po w er
In
1
Attaches to
a power supply
PICTURED ABOVE
| www.meridian - audio.com
