Thank you very much for purchasing one of our amplifiers. Please read
this manual before using the amplifier. When using this product, always
follow the instructions contained in this manual, and pay attention to the
safety information.
37 Brook Avenue Maywood, NJ 07607
Amplifiers
DA-14
DA-26
DA-112
DA-3400
MDS-14
Instruction Manual
TEL: (201)368-9171
DA-16
DA-43A
DA-1200
DA-6200
Fax: (201)569-1626
Web: www.ikegami.com
Advertisement
Table of Contents
Summary of Contents for Ikegami DA-14
- Page 1 IKEGAMI Amplifiers DA-14 DA-16 DA-26 DA-43A DA-112 DA-1200 DA-3400 DA-6200 MDS-14 Instruction Manual Thank you very much for purchasing one of our amplifiers. Please read this manual before using the amplifier. When using this product, always follow the instructions contained in this manual, and pay attention to the safety information.
- Page 2 To reduce the risk of electric shock, do not remove the cover. No parts inside the product can be serviced by the user. If your product needs service contact Ikegami Electronics (U.S.A.) Inc. at (201)368-9171 Usage Environment Avoid using or storing this product in areas such as those listed below. Doing so could damage the product or cause it to malfunction.
- Page 3 This manual covers the DA-43 family, the DA-43, DA-26 and the DA-112. It also covers the DA-14/16 family and the DA-3400 series distribution amplifiers. Connections: MADE IN USA UNGNDED. 12-18VDC POWER INPUT INPUT INPUT INPUT VIDEO SOURCE DA-43/DA-4300 (One channel shown used) Any unused inputs and outputs can be left open and unterminated and will not affect the other signals being fed in and out of the unit.
- Page 4 DA-43A Setup options for suitcase jumper There is one suitcase jumper located behind each input BNC Suitcase Jumper Positioning 75 ohm Coax 100 ohm UTP CAT-5 d) Reinstall the cover and connect the power. To Install a BNC connector on the CAT-5 cable: Push and crimp 1 pair from CAT-5 cable Placement in system: The DA-43A should be placed as near the end of a system as possible.
- Page 5 Usually you will find that the problem is caused by one feed only and by using a DA-20 or a Hum bucking transformer at the monitor location, the problem will go away. 37 Brook Avenue Maywood, NJ 07607 TEL: (201)368-9171 Fax: (201)569-1626 Web: www.ikegami.com...
- Page 6 DA-14/16 Series: The DA-14 and the DA-16 are 1 in and 4 out for the DA-14 and 1 in and 6 out for the DA-16. These DA's have a standard input terminated in 75 ohms. Any unused outputs can be left unterminated.
-
Page 7: Limited Warranty
Limited Warranty: Ikegami Electronics warrants this product and all accessories provided with it to be free of defects in material and workmanship for a period of 5 years after the original date of purchase. This warranty does not cover damage to the product resulting from accident, misuse or modification.
