RISK OF ELECTRIC SHOCK CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
FCC WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.
purpose of the polarized or grounding-type polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult electrician...
Page 5
Mattel. We have taken great care to make sure your unit was in perfect working order when it left our factory. It has been designed to give you many years of enjoyment and trouble-free operation. Read this manual before operating this unit to become familiar with its features.
GETTING STARTED • Operate controls and switches as described in the manual. • Before turning on the power, make certain that the AC Power cord is properly installed. • Store your CDs in a cool area to avoid damage from heat. •...
Top of Unit FM Telescopic Antenna CD Compartment SKIP/SEARCH n Button PLAY/PAUSE ®p Button SKIP/SEARCH o Button STOP (X) Button REPEAT Button PROG. Button Carrying Handle 10. Barbie LED Indicator 11. BAND (AM/FM/ FM ST.) Switch 12. TUNING Control 13. CD Door OPEN Tab...
Page 8
Front/Side of Unit Display POWER Indicator REPEAT Indicator Left Speaker Battery Compartment (Bottom of Unit) FM ST. Indicator PLAY/PROG. Indicator Right Speaker GEMSTONE FUN Button 10. AC Power Jack (Rear of Unit) 11. HEADPHONE Jack 12. AUX IN Jack 13. FUNCTION (AUX/RADIO/ OFF/CD) Switch 14.
This boombox requires either six (6) “C” size batteries (not included) or an AC power cord (included). BATTERY INSTALLATION 1. Remove the Battery Compartment door on the bottom of the unit by pressing down on the 2. Insert six (6) “C” size batteries (not included) according to the polarity diagram inside the Battery Compartment (as shown below).
Page 10
AC OPERATION To operate the unit using AC power, connect the small end of the AC power cord to the AC power jack on the rear of the unit and insert the plug into an AC outlet having 120V AC, 60Hz only. The batteries are automatically disconnected when the AC power cord is connected.
LISTENING TO THE RADIO Slide the FUNCTION switch to the RADIO position to turn the unit on and select Radio mode; the POWER indicator will light. Adjust the VOLUME control as desired. ANTENNAS AM–This unit has a built-in ferrite rod antenna, which provides adequate reception in most areas.
TO INSERT AND PLAY A CD Slide the FUNCTION switch to the CD position to turn the unit on and select CD mode; the POWER indicator will light. Open the CD compartment lid by lifting the CD Door OPEN tab. Insert a disc onto the center spindle (label side up) and push down gently to make sure it is securely on the spindle.
Page 13
When the disc is through playing, it will stop. Press the STOP ( to stop the disc before it is finished. TO PAUSE PLAYBACK Press the PLAY/PAUSE ®p button to pause playback; the track number will blink and the disc will continue to spin.
Page 14
CD PLAYBACK NOTES: • This unit is capable of playing standard CDs or 3” singles; no adapter is required. • If a disc is inserted incorrectly, dirty, damaged or not present at all, “no” will appear in the display. • Although this unit can read CD-R and CD-RW discs, in addition to normal CDs, the playability of those discs may be affected by the type of software that was used to create the discs, as well as the blank media you are using.
Page 15
TO REPEATEDLY PLAY BACK ONE TRACK While either in CD Stop or Playback mode, press the REPEAT button once; the REPEAT indicator will flash. TO REPEATEDLY PLAY BACK ALL TRACKS While either in CD Stop or Playback mode, press the REPEAT button twice;...
Page 16
TO PROGRAM THE MEMORY (UP TO 20 TRACKS) While in CD Stop mode, press the PROG. button; the PLAY/PROG indicator and “01” (the program number) will blink. Press the PLAY/PAUSE button 1 to begin Programmed playback; the PLAY/PROG indicator will blink. Adjust the VOLUME control ...
Page 17
See what you can do with your GEMSTONE FUN button! Step 1 Step 2 Press the GEMSTONE FUN button on the front of your Bloombox Barbie has a surprise just for you! Just follow the instructions below and see what you can do with your GEMSTONE FUN button! SURPRISE! Your Barbie indicator will flash in alternating...
CARING FOR COMPACT DISCS • Treat the compact disc carefully. Handle the compact disc only by its edges. Never allow your fingers to come in contact with the shiny, unprinted side of the compact disc. • Do not attach adhesive tape, stickers, etc. to the compact disc label.
If you experience a problem with this unit, check the chart below before calling for service. SYMPTOM CD will not play. FUNCTION switch not set to CD. Disc inserted incorrectly. AC power cord not connected. CD skips while CD compartment playing and/or not closed.
Page 20
LIMITED WARRANTY (Valid in the United States) Emerson Radio Corp. warrants manufacturing defects in original material, including original parts and workmanship, under normal use and conditions, for a period of ninety (90) days from the date of original purchase in the U.S. With your dated proof of purchase, we will provide repair service at no charge for labor and parts at an authorized Depot Repair Facility, or replace the product in our discretion.
Page 21
Consumer Electronics, Home Appliances and Home Office Products Thank you for choosing EMERSON SYNNEX Canada Limited gives the following express warranty to the original consumer purchaser or gift recipient for this EMERSON product, when shipped in its original container and sold or distributed in Canada by SYNNEX Canada Limited or by an Authorized EMERSON Dealer: SYNNEX Canada Limited warrants that this product is free, under normal use and maintenance, from any defects in material and workmanship.
