STEP 1 :
nETWORk COnnECTiOnS
Attach the Ensemble's network port to a LAN
1
on your router. You can use the Neutrik Ethercon
connector (supplied) with an Ethernet cable of
the appropriate length (not supplied.)
Attach the Control's network port to a LAN port
2
on your router. You can use an additional Neutrik
Ethercon connector with your own Ethernet cable
here as well.
Make sure the wAN /Internet port of this router
3
connects to the rest of your network, or to your
Cable/ modem.
dSL
depending on the make and model of your router,
!
crossover Ethernet cable(s) may be required
to make valid connections to your Ensemble and
Control components.
Meridian Audio Ltd, Latham Road, Huntingdon, Cambridge PE 29 6 YE , United Kingdom
L A N
W A
N
b le
e m
e n s
3
2
Connects to
1
Control 10
Connection to
PICTUREd BELOw
the internet
port
L
Tr ig g
e r
C o m
R
m s
S p ea
ke r
Li nk
D ig it
al O u
t
P o w e
r In
2
Connect to a
LaN port on your
network router
PICTUREd ABOVE
| www.meridian - audio.com
STEP 2 :
AudiO COnnECTiOnS
Option 1 : Your Ensemble component
1
features 4 stereo analogue outputs.
Attach the output labelled "Zone 1"
to an input on your audio system.
Option 2 : Your Ensemble also
2
features a single / digital audio
S PdIF
output. This connection is accessed
as "Zone 5" in the on-screen interface
and can be used as an alternative to
the analogue outputs. Use a digital
coaxial cable to connect this to an
/ digital input on your audio
S PdIF
system, or an digital input on
S / PdIF
Meridian digital Active loudspeakers.
Option 3 : Your Control 10 also
3
features an S / PdIF digital audio
output. This can be connected to an
S / PdIF input on your audio system,
or on Meridian digital Active loud-
speakers. The Control 10 also in-
cludes a SpeakerLink output, which
can be connected to Meridian digital
Active loudspeakers.
a . S / Pdif digital audio output
B . Meridian SpeakerLink audio output
. Meridian Comms (for integrating your
C
Control 10 with a Meridian system )
d . Meridian trigger and analogue inputs
(included for future use )
As a precaution, please lower the
!
volume and/or power down any
external audio components before
making new audio connections.
Meridian Audio Ltd, Latham Road, Huntingdon, Cambridge PE 29 6 YE , United Kingdom
b l e
e m
e n s
1
b l e
e m
e n s
2
L
Tr ig g
er
C om
R
m s
S pe ak
er
Li nk D ig it
al O ut
P ow er
In
D
C
B
A
3
| www.meridian - audio.com
