Kerio Operator Box 1000/3000 Series

1 Purpose

This document is a quick guide for safely installing and implementing Kerio Operator Box 1000
and 3000 Series PBX appliances.

2 General safety instructions

• The appliance should be placed on a flat surface or securely mounted horizontally in rack
enclosure.
• Do not attempt to open or disassemble the appliance for any reason.
• Strictly follow the installation instructions (see section 4).
• Do not place the device near a heat source.
• Place the appliance in a ventilated space, making sure that the appliance fans and vents are
unobstructed at all times.
• Do not expose the appliance to liquids of any kind. In the event of liquid intrusion, unplug
the appliance immediately.
• Verify that the voltage and frequency of the power socket matches the values printed on
the power adapter before plugging in the appliance. Use only the power adapter supplied
with the appliance.
• Do not place any items on top of the power cable. Keep the power cable away from walk-
ways or other areas where it could pose a tripping hazard.

3 Device Description

Kerio Operator Box types:
• Kerio Operator 1000 Series — Sub 1U table mountable appliance (see figure 1).
• Kerio Operator 3000 Series — 1U rack mountable appliance (see figure 2).
Control
Serial port
USB ports
Gigabit Ethernet ports
Figure 1 Kerio Operator Box 1210
Figure 2 Kerio Operator Box 3210
Used for connecting to a console with a serial cable
Input for USB devices
Used for connecting to the Internet and the network with an
Ethernet cable
Table 1 Kerio Operator
2
Description
