Summary of Contents for Mixpresso ST-503A
- Page 1 Espresso Coffee Machine INSTRUCTION MANUAL Model: ST-503A Please read this Instruction Manual and the safety instructions before operating the appliance!
-
Page 2: Table Of Contents
Homemaker content espresso maker with capsules Safety precautions Notes on this operating manual Congratulation on your purchase! Unpacking Starting up This Homemaker capsule coffee machine is manufactured with great care. – Before using for the first time – Capsule type can be used If you look it after properly it will reward you –... - Page 3 Please take time to read these safety precautions carefully before – Choose a dry, stable and level support surface not immediately connecting your machine to the power supply. It is essential to follow them underneath the power point, at least 60 cm away from the and the operating instructions.
-
Page 4: Notes On This Operating Manual
Notes on this operating manual This operating manual cannot cover all possible circumstances. For further information or in case of problems not adequately covered in this operating manual, please contact kmart. Please keep this operating manual safe and pass it on to the next user. Unpacking −... -
Page 5: Starting Up
Starting up Before using for the first time Caution: improper handling of electrical equipment is dangerous and can be lethal. Please pay attention to the safety precautions in this manual, in particular the following: • Danger of scalding: beware of hot water •... -
Page 6: Overview Of Machine Parts And Controls
Overview of machine parts and controls Short espresso button No. name handle Lungo coffee button bu ons Dispenser Drip tray set wall Water tank cover Adjustable dispenser spout water tank (2 positions) (removable) Power cord Main switch Used capsule container Drip tray cover drip tray (removable) -
Page 7: Flushing Out The Machine/Internal Piping
Fill/refill water tank Flushing out the machine and internal piping Before using for the first time or after long pauses (e.g. holidays) the machine must be flushed out. This short procedure can flush Fill water tank to maximum level. out and cleans the internal piping thoroughly. There are two ways to fill the water tank: directly into the machine, by using for Plug in the appliance and turn it on. -
Page 8: Brewing Coffee
Press the lungo coffee button, wait for the 5. The selected button will blink and the machine is brewing coffee, appliance to complete the flush out. dispensing will stop automatically when reaching the default brewing – Before pressing the button, make sure that: time (25s for espresso, 40s for lungo ),default setting can be –... -
Page 9: Programming Coffee Volume
when programming process is finished, leave the machine for 30 Programming the coffee volume. seconds for cool down prior to open handle. CAUTION: Be sure there is enough water in – Beware of hot steam: danger of scalding! the tank before programming coffee volume. -
Page 10: Cleaning
Cleaning Emptying the capsule container and drip tray The capsule container holds around 10 Clean the coffee machine used capsules. – Always pull out the power plug before we recommend emptying the used cleaning the machine capsule container and the drip tray –... -
Page 11: Decalcification
Decalcification Decalcification / Maintenance Drinking water varies according to region. The lime particles in hard drinking water are deposited as residues in the machine and can block the piping and cause damage. To prevent this, be sure to decalcify the machine at the very least after making 300 to 400 cups of coffee or, in any case if the output falls significantly or, after one or two months. -
Page 12: Factory Reset
Factory reset Steaming out / Storage / Transport In case you want to have the default setting of the machine, please follow Steaming out below instruction – Prior to long periods of disuse or for storage a. Turn off the machine. or transport at temperatures b. -
Page 13: Troubleshooting
Trouble Shooting PROBLEM CAUSE SOLUTION No coffee is brewed. The water tank is empty. Fill water in water Follow first use Preheat cup / mug. - Descale. cup / mug is cold. The coffee is not hot enough. - Scale build-up in machine. - For cold machine, brewing a cup of water to warm up the circuit. -
Page 14: Technical Data
Technical data: Rated Voltage: 220-240V AC Rated Frequency: 50Hz Rated Power: 1,260W N.W./G.W.: 3.1/3.5 kg appr. Pump Pressure: Max. 19 Bars Water Tank Capacity: 0.8L Size: 118mm(W)* 365mm(L) * 250mm(H) Protection Class:... - Page 15 2/3 cup of coffee espresso with cappuccino 1/3 frothed milk foam. 1/3 cup of coffee espresso latte with 2/3 warmed milk. 1/3 warmed milk with 1/3 coffee espresso macchiato with 1/3 frothed milk foam on top. mocha Half espresso with half chocolate. 2/3 cup of coffee espresso with iced cappucino 1/3 cold frothed milk foam.
