- Page 1 Terbly FS300 Follow Spot USER MANUAL...
-
Page 2: Table Of Contents
KEEP THIS MANUAL FOR FUTURE NEEDS Contents 1. FEATURES..............................2 2. FIXTURE OVERVIEW ..........................3 3. GENERAL GUIDELINES ..........................3 3.1) Important safety warns ........................3 3.2) GENERAL GUIDELINES ........................4 4. INSTALLATION INSTRUCTIONS......................5 4.1) Installing or replacing the lamp ......................5 5. -
Page 3: Features
Thank you for your patronage. We are confident that our excellent products and service can satisfy you. For your own safety, please read this user manual carefully before installing the device. In order to install , operate, and maintain the lighting safety and correctly. We suggest that the installation and operation should be done by the verified technician and follow the instruction strictly. -
Page 4: Fixture Overview
2. Fixture Overview 1: Dimming 2: Color Temperature Iris Frost Framing 6: Adjust beam angle 7: Colored papers 8: Fuse 9: Power supply 10: Power switch 11: Hand 12: Lamp bracketrear metal panel 13: Lens 3. GENERAL GUIDELINES 3.1) Important safety warns This device has left the factory in perfect condition. -
Page 5: General Guidelines
If the device has been exposed to temperature changes due to environmental changes, do not switch it on immediately. The arising condensation could damage the device. Leave the device switched off until it has reached room temperature. This device falls under protection-class I. Therefore it is essential that the device be earthed. If protection screen,lens or ultraviolet screen in the fixture is apparently damaged or is damaged to exceed their own effective degree, such as cracked and gashed, it must be replaced. -
Page 6: Installation Instructions
Do not shake the device.Avoid brute force when installing or operating the device. While choosing the installation-spot, please make sure that the device is not exposed to extreme heat, moisture or dust. Please don't project the beam onto combustible substances.The minimum distance between light-output from the projector and the illuminated surface must be more than 3 meter. - Page 7 Before replacing the lamp let the lamp cool down, because during operation, the lamp can reach very high temperature. During the installation of halogen lamps do not touch the glass bulbs bare handed. Always use a cloth to handle the lamps during insertion and removal. Do not install lamps with a higher wattage.
-
Page 8: Instructions
Layout Drawings: 5. Instructions 5.1 Dimming/color temperature adjustment instruction 1）Dimming: linear dimming-Intensity 0% to 100%. Instruction: dimming according to silkscreen instruction by slider. 2）Color temperature:linear adjustment from 3200K to 6800K. Instruction: adjust color temperature according to silkscreen instruction by slider. 3）Iris: adjust Min. -
Page 9: Cleaning And Maintenance
5.2 Beam angel adjustment instruction adjust beam angle: linearly adjusting beam angel from small to big Instruction: move sliders on both sides to focus and zoom. (Attn: must keep both sides move to same value ) 6. CLEANING AND MAINTENANCE The following points have to be considered during the inspection: 1) All screws for installing the devices or parts of the device have to be tightly connected and must not be corroded. -
Page 10: Technical Specifications
installer and any safety problems have to be removed. In order to make the lights in good condition and extend the life time, we suggest a regular cleaning to the lights. 1) Clean the inside and outside lens each week to avoid the weakness of the lights due to accumulation of dust.
